Description:
Wheelock's patented Series RSSR Strobes
with Red Lens have low current draw with
outstanding performance, reliability and cost-
effectiveness. The Series RSSR Strobes are
UL Listed under Standard 1638 for Emergency
signaling. All strobes use a Xenon flashtube
enclosed in a rugged Lexan® red lens
dependable visual signaling. Strobes may be
synchronized when used with the Series SM
or DSM Sync Module(s) or Wheelock's
POWERPATH™ Power Supplies with
Wheelock's Patented Sync Protocol.
Wheelock's Series RSSR Strobes employ an
integral, Strobe Mounting Plate that makes it
easy to mount to a variety of backboxes. The
strobes can be mounted to single-gang,
double-gang, 4" square, 100mm European
backboxes or the SHBB surface backbox. An
attractive cover plate is provided for a clean,
finished appearance on all models.
Applications:
Surpression Notification
Process Notification
Emergency Notification
Copyright 2004 Wheelock, Inc. All rights reserved.
Helping People Take Action
SERIES RSSR STROBES
Features:
•
Appprovals Include: UL 1638 (Indoor)
•
Low current draw
•
Available with 75 or 110cd wall or ceiling
mount
•
24 VDC with 16-33 volt operating range
•
Synchronize with Wheelock SM, DSM Sync
Modules or Wheelock's
POWERPATH™ Power Supplies
•
Patented Strobe Mounting Plate for single
gang, double gang, 4" square 100mm
European backboxes
•
Available in Red or White
•
Can be Special Ordered with virtually any
lettering (call Customer Service)
SM
WITH
RED
LENS
RSSR with
Optional Lettering
RSSR with
No Lettering
Advertisement
Related Manuals for Wheelock Series RSSR
Summary of Contents for Wheelock Series RSSR
- Page 1 Wheelock’s patented Series RSSR Strobes with Red Lens have low current draw with outstanding performance, reliability and cost- effectiveness. The Series RSSR Strobes are UL Listed under Standard 1638 for Emergency signaling. All strobes use a Xenon flashtube enclosed in a rugged Lexan® red lens dependable visual signaling.
-
Page 2: General Notes
All candela ratings represent minimum effective Strobe intensity. • Series RSSR Strobe products are listed under UL 1638 (for Emergency Signaling) for indoor use with a temperature range of 32°F to 120°F (0°C to 49°C) and maximum humidity of 85% RH. - Page 3 For wiring information on the PS-12/24-8CP and PS-12/24-8MP Power Supplies refer to Installation Instructions P84515 and P84333. Wheelock products must be used within their published specifications and must be PROPERLY specified, applied, installed, operated, maintained and operationally tested in accordance with their installation instructions at the time of installation and at least twice a year or more often and in accordance with local, state and federal codes, regulations and laws.
- Page 4 All visual appliances shall incorporate a Xenon flashtube enclosed in a rugged Lexan® red lens. The Series RSSR Strobes with Red Lens shall be of a low current design. Series RSSR Strobe Appliances with Red Lens shall incorporate circuitry for synchronized strobe flash and shall be designed for compatibility with Wheelock’s Series SM, DSM Sync Module(s) or Wheelock’s PS-12/24-8MP and PS-12/24-8CP Power Supplies with Wheelock’s...
