ACV TER 57 Specification

Typical Installation
Three TER boilers providing full heating and hot water
capabilities in conjunction with a Jumbo 1000 hot water
storage tank.
38 High efficiency electric boilers
TER
Floor standing, high output,
three phase electric boiler.
Use as a primary heat source
or emergency back up.
Product Features
• Steel heating body and removable stainless
steel heating elements
• Six standard models of 57.6 to 259 kW
• Four power stages – controlled by a stage delay
timer
• Can easily be de-rated to provide less output if
required
• Fully wired power and control circuits
• 50mm rigid polyurethane foam insulation
• Stove enamelled casing
• Control panel including thermostats, thermometer,
indicators and on/off switch
• Very little maintenance required
• Can also be used in multiple boiler installations
