ACV Prestige 24-32 Specification

Prestige Solo - System boiler
The Prestige Solo is designed to operate as either a
heating only unit, or, for optimum heating and hot
water performance, can be linked to one of the
SmartLine range.
Prestige Solo
1. Chimney connection (concentric tubes ø 80/125mm)
2. Burner, premix and modulating
3. Heat exchanger, stainless steel
4. Pump, central heating
5. Electrical panel (the control boxes on the rear are optional)
6. Control panel
30 High efficiency condensing boilers
Prestige 24-32
High efficiency domestic wall
mounted gas condensing boiler.
Stainless steel construction with
self-cleaning flue ways.
The prestige can accommodate within its control
centre, temperature regulation/full burner modulation
via room thermostat, climate control with an outside
sensor (optional), and with a combination of outside
sensor and room thermostat.
Prestige Excellence - Combination boiler
Incorporated within the jacket, is a 62 litre (total
capacity) stainless steel Tank-in-Tank. The Prestige 32
Excellence delivers 224 litres of hot water at 40°C in ten
minutes. The Prestige range offers the same anti-
scaling, legionella and bacteria risk reduction as all our
ACV Domestic Hot Water products.
Prestige Excellence
1. Chimney connection (concentric tubes ø 80/125mm)
2. DHW pump with integrated air vent
3. Pump, central heating
4. Electrical panel (the control boxes on the rear are optional)
5. Control panel
6. Burner, premix and modulating
7. Manual air vent
8. Water heater 62 litres
9. Heat exchanger, stainless steel
10. Hot water storage tank, stainless steel
11. Expansion vessel
12. Bracket for expansion vessel
