  • Page 1 NSTRUCTION ANUAL TED 200-T ORTABLE XYGEN ONITOR TYPE B EQUIPMENT: Equipment providing a particular degree of protec- tion against electric shock, particularly regarding— • allowable LEAKAGE CURRENT • Reliability of the protective earth connection (if present). P/N MC41901.02 04/09/99 ECO #99-0159...
  • Page 2 Teledyne Electronic Technologies, 16830 Chestnut Street, City of Industry, CA 91749–1580...
  • Page 3 Teledyne warrants that the goods are free from defects of material and of construction for a period of 2 years from the date of shipment from Teledyne. The Class T-7 Micro- Fuel Cell is warranted for one year from the date of shipment from Teledyne. The...

  • Page 4: Table Of Contents

    2.2.2.1 Gasses That Induce Reading Error ........2-7 2.2.2.2 Care After Use in Nitrous Oxide......... 2-8 2.2.3 Sterilization ................2-8 Do's & Don'ts ..................2-9 Maintenance and Troubleshooting TED 200-T Overall Maintenance ............. 3-1 Battery Maintenance ................. 3-1 Sensor ....................3-2 Troubleshooting ................3-2 Appendices Specifications ..................
  • Page 5 How To Use This Manual This manual is designed to walk you through the initial set-up of the TED 200-T. After you have used it to initially install your monitor, it becomes a quick reference guide to help you with specific questions or operating problems.
  • Page 6 Teledyne Analytical Instruments...

  • Page 7: Introduction 1

    The TED 200-T is designed to monitor up to 100 % oxygen concentration in medical gas mixtures. Because it is microprocessor-based, the TED 200-T has a unique combination of features and is very easy to use through a touch panel designed for minimal operator interface.

  • Page 8: Theory Of Operation

    Anesthesia • Respiratory Therapy • Neonatal Care. Theory of Operation The TED 200-T can be divided into two major functional groups: • the T-7 Sensor and • Signal Processing. The analyzer uses Teledyne Electronics Technologies Class T-7 oxygen sensor. The current output from the sensor is fed into the electronic signal processor, where it is used to calculate the oxygen gas concentration and display it on the LCD screen.

  • Page 9: Signal Processing

    Using a microprocessor allows for easier setting of alarms, auto- matic calibration, and self-diagnosis. When the battery runs low or the unit needs recalibration, the TED 200-T tells you so. The oxygen level is calculated and then displayed on the liquid crystal display (LCD) on the front panel.
  • Page 10 1 Introduction Teledyne Analytical Instruments...

  • Page 11: Operations 2

    CAL, ALARM TEST and OFF keys must be pressed twice in order to activate them. The ON/OFF key needs to be pressed once in order to turn on the TED 200-T, but must be pressed twice to turn it off.

  • Page 12: Battery Installation Or Replacement

    2 Operations Sensor cable receptacle Battery compartment Figure 2: TED 200-T rear view 2.1.1 Battery Installation or Replacement Note: Four “AA” alkaline batteries must be installed in the unit before the TED 200-T will operate. Each time new batteries are installed, the display will flash AIR CAL.

  • Page 13: Sensor Installation Or Replacement

    TEST key once. The display should show BATTERY HRS LEFT as 999. 2.1.2 Sensor Installation or Replacement Note: The T-7 oxygen sensor must be installed before the TED 200-T can be operated. For sterilization procedures, see page 2.8: Sterilization. Note: When a new sensor is installed, typically, the unit is suitable for use immediately after installation.

  • Page 14: Calibration

    3. Plug the other end of the coiled cable into the receptacle located on the right- hand side panel of the TED 200-T. This jack will only fit one way, so do not force it.

  • Page 15: Alarms

    It is very important that air (21 % oxygen) calibration be performed every time the batteries are disconnected or replaced in the TED 200-T. The microprocessor cannot perform its task properly without this data. After 10 seconds a reading of 20–22% oxygen will be displayed. CAL IN 100% will flash for a period of 5 seconds, during which time the reading of 20–22 will con-...

  • Page 16: Use

    Note: Prior to use, always test the batteries and alarms; check calibration, the sensor for leaks and damage, and the alarm settings. The TED 200-T can be used to monitor gas mixtures for oxygen in two basic modes: 1. In breathing circuits or other instances where gases are flowing in tubing circuits.

  • Page 17: Anesthetic Gases

    T-7. Exposing the sensor to air or gases that do not contain anesthetic agents for a period of time equal to or greater than the exposure interval will eliminate the reading error in most cases. Teledyne Analytical Instruments...

  • Page 18: Care After Use In Nitrous Oxide

    A vacuum must not be drawn on the sensor during the sterilization process. The TED 200-T itself cannot be liquid sterilized or autoclaved. The surface of the case may be wiped with isopropyl alcohol and allowed to air dry. In extreme cases, a mild detergent may be used.

  • Page 19: Do's & Don'ts

    Use cleaning agents or liquids in the cable receptacles or around the battery compartment. • Place the TED 200-T unit itself in a water vapor-saturated environment. • Expose the LCD to excessive sunlight. • Expose the TED 200-T to a condensing water environment such as a mist tent. Teledyne Analytical Instruments...
  • Page 20 2 Operations Teledyne Analytical Instruments 2-10...

  • Page 21: Maintenance And Troubleshooting 3

    Should the remaining battery life reach 24 hours, the alarms will activate and the screen will display LOW BATTERY. Note: The TED 200-T is designed to automatically check its battery life once per hour. When setting the HI/LO alarms or checking the batteries, the unit will freeze the oxygen reading momentarily.

  • Page 22: Sensor

    If the batteries are still not replaced, the LED and beeper will drain the remaining power and go completely dead. If the TED 200-T will not be used for a period of 30 days or more, the batteries should be removed prior to storage.
  • Page 23 Symptom What to Do A new sensor will not calibrate A new sensor must be A) Wait 1–2 minutes and try in air. The TED 200-T display allowed to stabilize prior to again. flashes REPLACE SENSOR calibration. B) Oxygen concentration at the...
  • Page 24 See Appen- dix: Discrepancy in Read- ings. A) Disconnect the batteries The unit appears to have a The TED 200-T is and inspect the contacts momentary or intermittent equipped with an elec- and wires for damage or condition which causes the tronic "watch dog,"...
  • Page 25 5-second normal. period for activation. See Chapter 1.0: Introduction or Chapter 2.0: Set-Up. NOTE: In the event that none of these procedures produce desired results, remove the batteries and return the unit to Teledyne for repair. Teledyne Analytical Instruments...
  • Page 26 3 Maintenance and Troubleshooting Teledyne Analytical Instruments...

  • Page 27: Appendices

    Warm up time: Typically 20 minutes or less A.2 Spare Parts List PART NO. DESCRIPTION A51327 Micro-Fuel Cell T-7 with flow diverter P/N A50057 “AA” size alkaline battery Teledyne Analytical Instruments...

  • Page 28: Optional Accessories

    Note: Orders for replacement parts should include the model number, serial number, and range of the analyzer for which the parts are intended. ORDERS SHOULD BE SENT TO: TELEDYNE ELECTRONIC TECHNOLOGIES Sensor Technologies 16830 Chestnut Street City of Industry, CA 91749-1580...

  • Page 29: Repair Service

    This is why it is important to calibrate the TED 200-T oxygen sensor at regular intervals. It is recommended that the unit be calibrated prior to each use or every 8 hours.

  • Page 30: Humidity

    The information obtained from the TED 200-T should never be used to make adjustments to the primary life- support system, but should only be used as an indication that the primary device may require service and/or calibration.
  • Page 31 Appendices The BATT TEST control of the TED 200-T immediately determines if the batteries need replacing. The TED 200-T should momentarily be removed from the application area and be checked for calibration and sensor integrity. If the TED 200–T can be calibrated, the unit can be assumed to be in good working order and capable of providing readings to specification.
  • Page 32 Appendices Teledyne Analytical Instruments...

  • Page 33: Material Safety Data Sheet

    Section I – Product Identification Product Name: Micro–Fuel Cells Mini–Micro–Fuel Cells, all classes Super Cells, all classes except T–5F Oxygen Sensors, all classes. Manufacturer: Teledyne Electronic Technologies/Analytical Instruments Address: 16830 Chestnut Street, City of Industry, CA 91748 Phone: (626) 934-1500 Technical Support: (626) 934-1673...
  • Page 34 NTP Annual Report on Carcinogens: Not listed LARC Monographs: Not listed OSHA: Not listed Other health hazards: Lead is listed as a chemical known to the State of California to cause birth defects or other reproduc- tive harm. Teledyne Analytical Instruments...
  • Page 35 NOTE: The above information is derived from the MSDS provided by the manu- facturer. The information is believed to be correct but does not purport to be all inclusive and shall be used only as a guide. Teledyne Elec- tronic Technologies shall not be held liable for any damage resulting from handling or from contact with the above product.
