P
ORTABLE
I
NSTRUCTION
Sales Order Number:
Instrument Serial Number:
HIGHLY TOXIC AND OR FLAMMABLE LIQUIDS OR GASES MAY BE PRESENT IN THIS MONITORING SYSTEM.
PERSONAL PROTECTIVE EQUIPMENT MAY BE REQUIRED WHEN SERVICING THIS SYSTEM.
HAZARDOUS VOLTAGES EXIST ON CERTAIN COMPONENTS INTERNALLY WHICH MAY PERSIST FOR A
TIME EVEN AFTER THE POWER IS TURNED OFF AND DISCONNECTED.
ONLY AUTHORIZED PERSONNEL SHOULD CONDUCT MAINTENANCE AND/OR SERVICING. BEFORE
CONDUCTING ANY MAINTENANCE OR SERVICING CONSULT WITH AUTHORIZED SUPERVISOR/MANAGER.
M
ODEL
TURBO 2
TURBO 2 P
T
RACE
A
NALYZER
DANGER
Teledyne Analytical Instruments
O
XYGEN
M
ANUAL
P/N M44412
01/11/2012
Advertisement
Table of Contents
Related Manuals for Teledyne TURBO2
Summary of Contents for Teledyne TURBO2
- Page 1 HAZARDOUS VOLTAGES EXIST ON CERTAIN COMPONENTS INTERNALLY WHICH MAY PERSIST FOR A TIME EVEN AFTER THE POWER IS TURNED OFF AND DISCONNECTED. P/N M44412 ONLY AUTHORIZED PERSONNEL SHOULD CONDUCT MAINTENANCE AND/OR SERVICING. BEFORE 01/11/2012 CONDUCTING ANY MAINTENANCE OR SERVICING CONSULT WITH AUTHORIZED SUPERVISOR/MANAGER. Teledyne Analytical Instruments...
- Page 2 Teledyne or an authorized service center. We assume no liability for direct or indirect damages of any kind and the purchaser by the acceptance of the equipment will assume all liability for any damage which may result from its use or misuse.
-
Page 3: Table Of Contents
Cell Replacement ..............12 Cell Warranty ..............13 Transduction and Temperature Compensation ....13 Pump Removal/Installation ..........14 Appendix Specifications ..............15 Spare Parts List ..............15 Drawing List ................ 16 Material Safety Data Sheet ..........17 Teledyne Analytical Instruments... - Page 4 Teledyne Analytical Instruments...
-
Page 5: Introduction
Portable Trace Oxygen Analyzer TURBO Introduction The Teledyne Analytical Instruments Model TURBO is a portable trace oxygen analyzer which does not need an external power source to operate, and can be reliably calibrated without the use of additional calibra- tion gases. -
Page 6: Features
8-hour duty cycle. An integral charging circuit and a detachable power cord are provided so that the batteries may be recharged from any 50 or 60 cycle, 105 to 125 volt (90 to 110 volt optional), outlet. Teledyne Analytical Instruments... - Page 7 (½A: 110V; ¼A: 220V), and quick-connect fittings for bringing the sample into and out of the sensor assembly. See Figs. 2 and 3. Pump: The TURBO P has an integral pump used to help draw sample through the analyzer. Teledyne Analytical Instruments...
- Page 8 TURBO Portable Trace Oxygen Analyzer Teledyne Analytical Instruments...
-
Page 9: Supporting Equipment And Services
Since the cell is a partial pressure sensitive device, any oxygen readings taken under these conditions would be erroneous. In addition, vacuums in excess of one-third of an atmosphere may damage the cell. Teledyne Analytical Instruments... -
Page 10: Power Service
The TURBO can be optionally furnished with 220 VAC, 50 or 60 Hz charging power or 100 VAC, 50 or 60 Hz charging power. Teledyne Analytical Instruments... -
Page 11: Operation
To extend cell life and minimize the time required to make the next analysis, the instrument should always be purged with sample or an inert gas prior to being taken out of service for standby or storage. Teledyne Analytical Instruments... -
Page 12: Calibration
CAL mark on the meter scale. Be sure to relock the control after the adjustment is made. 5) Immediately after step 4, disconnect the tubing-equipped calibration fitting, and plug in either the sample or a source of inert gas. Teledyne Analytical Instruments... -
Page 13: Positive Pressure Sampling
If a flowing sample is connected to the manifold without the vent fitting in place, the pressure in the manifold will rise and equal the sample pressure immediately, possibly causing a manifold leak. Teledyne Analytical Instruments... -
Page 14: Atmospheric Pressure Sampling
The pump power switch is located on the back panel of the analyzer. During calibration and normal operation, set the flowmeter to midrange, and turn the pump on during step 3 of the calibration procedure. Teledyne Analytical Instruments... -
Page 15: Maintenance
If the instrument is stored with the Range Selector Switch in the OFF position (charge cord disconnected), the period of time between charge periods is extended from one month to four months. However, do not leave it longer than this time period. Teledyne Analytical Instruments... -
Page 16: Routine Maintenance
3. Remove the 3 wing nuts on top of the cell block and remove the cell cap. Carefully remove the old cell from the cell cap and dispose of it in accordance with local regulations (see the Material Safety Data Sheet at the end of the manual). See Figure 3. Teledyne Analytical Instruments... -
Page 17: Cell Warranty
Transduction and Temperature Compensation The Micro-fuel Cell used in the TURBO has an inherent positive temperature coefficient, the effects of which have been minimized through the implementation of a thermistor compensation circuit. Teledyne Analytical Instruments... -
Page 18: Pump Removal/Installation
3. Connect the tagged pump inlet and outlet tubings to the pump assembly. 4. Connect the pump motor wires to the circuit terminals. 5. Replace the instrument cover plate and then insert and tighten the cover plate mounting screws. Teledyne Analytical Instruments... -
Page 19: Specifications
Pump Assy. (for Pump Option) A minimum charge is applicable to spare parts orders. IMPORTANT: Orders for replacement parts should include the part number and the model and serial number of the system for which the parts are intended. Teledyne Analytical Instruments... -
Page 20: Drawing List
TURBO Portable Trace Oxygen Analyzer Send orders to: TELEDYNE ANALYTICAL INSTRUMENTS 16830 Chestnut Street City of Industry, CA 91748 Telephone: (626) 934-1500 TWX: (910) 584-1887 TDYANYL COID Fax: (626) 961-2538 Web: www.teledyne-ai.com or your local representative Drawing List (TURBO C-45254 Outline diagram... -
Page 21: Material Safety Data Sheet
Micro-Fuel Cells Product Name: Product Name: Mini-Micro-Fuel Cells, all classes Super Cells, all classes except T–5F Electrochemical Oxygen Sensors, all classes. Manufacturer: Manufacturer: Manufacturer: Teledyne Analytical Instruments Manufacturer: Manufacturer: Address: Address: Address: Address: Address: 16830 Chestnut Street, City of Industry, CA... - Page 22 OSHA: Not listed Other health hazards: Other health hazards: Other health hazards: Other health hazards: Other health hazards: Lead is listed as a chemical known to the State of California to cause birth defects or other reproductive harm. Teledyne Analytical Instruments...
- Page 23 The information is believed to be correct but does not purport to be all inclusive and shall be used only as a guide. Teledyne Analytical Instruments shall not be held liable for any damage resulting from handling or from contact with the above product.
