FIGURE 4-17: Status Page with PPPoE Login Disabled
Notes :
If you have chosen the Dynamic IP and disabled PPPoE Login, you can
see the DHCP Release and DHCP Renew buttons:
To release the most current WAN IP address, click DHCP Release.
To renew the WAP IP address, click DHCP Renew.
Status Detail:
Parameter
Host
Name
Domain
PPPoE
Login
LAN
WAN
Shows the name of the device.
Shows the domain name of the device.
Shows the current status of PPPoE Login:
Disabled
▪
Enabled: Connected, Connecting or
▪
Disconnected.
Shows the current IP Address and Subnet Mask of
the device, as seen by users in your internal
network.
Shows the IP Address, Subnet Mask, Default
Gateway, and DNS of the router, as seen by
28
Description
