- Page 1 Digital Blood Pressure Monitor Model UA-787 Instruction Manual ’ Manuel d instructions Manual de Instrucciones Manuale di Istruzioni Bedienungsanleitung 使用手册 WM+PD4001187C...
-
Page 2: Table Of Contents
Contents Dear Customers..............2 Preliminary Remarks ............. 2 Precautions................2 Parts Identification..............3 Symbols................4 Operation Mode..............5 1. Normal Measurement With Storing Data ....... 5 2. Recalling Data.............. 5 3. Clearing Data............... 5 4. Measurement With The Desired Systolic Pressure ..5 Using The Monitor .............. -
Page 3: Dear Customers
Dear Customers Congratulations on purchasing a state-of-the-art A&D blood pressure monitor, one of the most advanced monitors available today. Designed for ease of use and accuracy, this monitor will facilitate your daily blood pressure regimen. We recommend that you read through this manual carefully before using the device for the first time. -
Page 4: Parts Identification
Parts Identification Display MEMORY Button DC Jack START Button (Orange illumination) CLOCK Button Arm Cuff Air Connector Plug Air Hose Battery Cover Air Socket Battery Compartment 1.5V Batteries (R6P, LR6 or AA) Part of Display Systolic Pressure MEMORY Diastolic Pressure Pressure Bar Indicator Pulse Rate WHO Classification Indicator... -
Page 5: Symbols
Symbols Symbols Function / Meaning Recommended Action Standby and Turn the device on. Battery installation guide Direct current Serial number Date of manufacture Type BF: Device, cuff and tubing are designed to provide special protection against electrical shocks. The indicator while measurement is in Measurement is in progress. -
Page 6: Operation Mode
Operation Mode 1. Normal Measurement With Storing Data (Refer to page 9) Press the START button. Blood pressure is measured and data is stored within the device. The device can store the last sixty sets of data in memory automatically. 2. -
Page 7: Using The Monitor
Using The Monitor Installing / Changing The Batteries 1. Slide the battery cover up to open it. Step 2 2. Remove the used batteries and insert batteries into battery compartment as shown, taking care that the polarities (+) and (-) are correct. 3. -
Page 8: Adjusting The Built-In Clock
Using The Monitor Adjusting The Built-in Clock The monitor has a built-in clock. We recommend that you adjust the clock prior to use. 1. Press and hold the CLOCK button until the digits start blinking. CLOCK button 2. Select the year using the START button. Press the CLOCK button to set the current year and move to month/day selection. -
Page 9: Alarm On/Off Mark On The Display
Using The Monitor Alarm ON/OFF Mark On The Display When the alarm is on, a “p” appears on the LCD. To turn the alarm off, simply press the CLOCK button once. The alarm will sound for 1 minute. To stop the alarm sound, press the START button once. -
Page 10: Measurements
Measurements Model UA-787 is designed to detect the pulse and to inflate the cuff to a systolic pressure level automatically. If your systolic pressure is expected to exceed 230 mmHg or you use the optional small cuff, read "Measurement With The Desired Systolic Pressure"... -
Page 11: Measurement With The Desired Systolic Pressure
Measurements Measurement With The Desired Systolic Pressure If your systolic pressure is expected to exceed 230 mmHg or you use the optional small cuff, use this procedure. Place the cuff on the arm (preferably the left arm). At heart level Press and hold the button until a START... -
Page 12: Recalling Memory Data
Recalling Memory Data Note: This device stores the last sixty measurements in memory automatically. The data is retained as long as the batteries are in the device. When you remove the batteries or the batteries are drained, the data will be erased. 1. -
Page 13: What Is An Irregular Heartbeat
What Is An Irregular Heartbeat Model UA-787 blood pressure monitor provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. An irregular heartbeat is defined as a heartbeat that varies by 25% from the average of all heartbeats during the blood pressure measurement. It is important that you be relaxed, remain still and do not talk during measurements. -
Page 14: About Blood Pressure
About Blood Pressure What Is Blood Pressure? Blood pressure is the force exerted by blood against the walls of the arteries. Systolic pressure occurs when the heart contracts. Diastolic pressure occurs when the heart expands. Blood pressure is measured in millimeters of mercury (mmHg). -
Page 15: Troubleshooting
described in this manual to get to know your normal blood pressure. Regular readings give a more comprehensive blood pressure history. Be sure to note date and time when recording your blood pressure. Consult your doctor to interpret your blood pressure data. -
Page 16: Maintenance
Maintenance Do not open the device. It uses delicate electrical components and an intricate air unit that could be damaged. If you cannot fix the problem using the troubleshooting instructions, request service from your dealer or from the A&D service group. The A&D service group will provide technical information, spare parts and units to authorized dealers.
