MODEL NUMBER

6157WUA
©2005 Maytag Services
RANGE
When requesting service or ordering parts, always
provide the following information:
- Product Type
- Model Number
- Part Number
- Part Description

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6157WUA and is the answer not in the manual?

Questions and answers

Related Manuals for Maytag 6157WUA

Summary of Contents for Maytag 6157WUA

  • Page 1: Repair Parts

    RANGE Repair Parts List MODEL NUMBER 6157WUA When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services...
  • Page 2 Section: TOP ASSEMBLY Model: 6157WUA C15-279...

  • Page 3: Top Assembly

    Section: TOP ASSEMBLY Part No. Description Series Qty 1 N 7712P186-60 PANEL, MANIFOLD (BLK) Note: PANEL, MANIFOLD 7112P102-60 CLIP, SPEED Note: CLIP 7602P119-60 CLOCK (BLK) Note: CLOCK N 7118P015-60 SCREW, HOUSING Note: SCREW 3801F332-45 BRACKET Note: BRACKET, CLOCK N 4005F415-51 COVER, MAINFOLD (REAR) Note: COVER, MAINFOLD (REAR) 7403P067-60 SWITCH, ROCKER (BLK) Note: SWITCH, ROCKER...
  • Page 4 Section: GAS CONTROLS Model: 6157WUA C13-138...

  • Page 5: Gas Controls

    Section: GAS CONTROLS Part No. Description Series Qty 1 N 7513P160-60 PIPE, MANIFOLD 2 N 7502P217-60 VALVE, TOP BURNER 7403P279-60 SWITCH, IGNITER 7404P087-60 THERMOSTAT 4005F433-51 COVER, VALVE 7101P280-60 SCREW W/WASHER (BLK) 7507P087-60 FITTING, ORIFICE Note: ORIFICE (REAR 9,200 BTU) 3412D018-09 SEALED BURNER ASSY.
  • Page 6 Section: BODY Model: 6157WUA C14-396...
  • Page 7 Section: BODY Part No. Description Series Qty 4002F188-80 BACK, MAIN 2 N 2618F095-74 PANEL, SIDE (LT-ALM) Note: (LT-ALM) 2 N 2618F096-74 PANEL, SIDE (RT-ALM) Note: (RT-ALM) 4011F224-80 BOX, BURNER 8010P088-60 SPACER, MAIN TOP (RT) Note: (RT) 8010P087-60 SPACER, MAIN TOP (LT) 7118P013-60 SCREW Note: SCREW, SPACER 6 N 4022W004-45...
  • Page 8 Section: OVEN/BASE Model: 6157WUA C12-178...
  • Page 9 Section: OVEN/BASE Part No. Description Series Qty 4003W028-80 BASE, MAIN 7101P316-60 LEG, LEVELING 3801F218-51 BRACKET, ANTI-TIP 3404F018-51 TRACK, DRAWER (RT) 3404F021-51 TRACK, DRAWER (LT) Note: (LT) 8016P010-60 GLIDE, BROILER TRACK 8004P024-60 SPACER, SIDE PANEL 7101P334-60 SCREW Note: SCREW, SPACER 7801P040-60 RACK 2201F077-19 FRONT, BROILER...
