Owner's Manual

Installation and Operation

Model:
CASTILE-MBK
CASTILE-PMH
CASTILE-CLG
CASTILE-CCR
• Important operating and
maintenance instruc-
tions included.
Please read this entire manual
before installation and use of this
pellet fuel-burning room heater.
Failure to follow these instructions
could result in property damage,
bodily injury or even death.
•
Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• Do not overfire - If any external part starts to
glow, you are overfiring. Reduce feed rate.
Overfiring will void your warranty.
• Comply with all minimum clearances to com-
bustibles as specified. Failure to comply may
cause house fire.
CAUTION
Tested and approved for wood pellets and shelled
field corn fuel only. Burning of any other type of fuel
voids your warranty.
www.quadrafire.com
CASTILE PELLET STOVE
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and
•
follow these instruc-
tions for safe installa-
tion and operation.
WARNING
Tested and
Listed by
Leave this manual with
•
party responsible for use
and operation.
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot
during operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high
temperatures.
• Do NOT operate with protective barriers open or
removed.
• Keep clothing, furniture, draperies and other
combustibles away.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult local building, fire officials or authorities having
jurisdiction about restrictions, installation inspection,
and permits.
250-6422D
R
Beaverton
O-T L
Oregon USA
C
OMNI-Test Laboratories, Inc.
WARNING
CAUTION
October 11, 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CASTILE CASTILE-CCR and is the answer not in the manual?

Questions and answers

Related Manuals for Quadra-Fire CASTILE CASTILE-CCR

Summary of Contents for Quadra-Fire CASTILE CASTILE-CCR

  • Page 1: Installation And Operation

    CASTILE PELLET STOVE Owner’s Manual Installation and Operation Model: CASTILE-MBK CASTILE-PMH Beaverton Tested and O-T L CASTILE-CLG Oregon USA Listed by CASTILE-CCR OMNI-Test Laboratories, Inc. CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • Important operating and •...
