WEEKLY TIMER

Weekly timer setting
1
Press the TIMER MODE button to select the weekly timer.
3
Day of the week setting
1
Press the DAY button to select the day of the week, and then press the
TIMER SET button to confi rm the setting.
For ALL, all of the days can be set together when a
each day.
4
Time setting
ON-1
Press the SET TIME (< >) buttons to set the time, and then press the TIMER SET
button to confi rm the setting and proceed to the next ON or OFF time setting.
Up to 2 times ON and OFF times can be set per day.
Press the DAY button to complete the time setting and return to the day of the
week setting.
5
3
Repeat steps and
To complete the weekly timer settings, press the
TIMER SET button for 2 seconds or more.
NOTES
• The operating time can be set in 30-minute increments only.
• The OFF time can be carried over to the next day.
• The ON timer and the OFF timer functions cannot be set using the weekly timer. Both an ON and OFF time must be
set.
9374343072-04_OM.indb Sec1:8 9374343072-04_OM.indb Sec1:8
SU MO TU WE TH FR SA
3 6 9 12 15 18 21
ALL
2
2
1
OFF-1 ON-2
4
.
SU MO TU
appears around
3
OFF-2
To delete the operating time
If the TIMER DELETE button is pressed
during steps
for the selected day will be deleted.
If all the days are selected, the operating
times for all of the days will be deleted.
2
Press the TIMER SET button for
2 seconds or more.
WE TH FR SA
SU MO TU WE TH FR SA
3 6 9 12 15 18 21
When the operating time is set, the
mark appears.
SU MO TU WE TH FR SA
3 6 9 12 15 18 21
ex. The timer is set for 7:00-18:00.
3 4
or , the operating time
En-8
