  • Page 1: Operating Manual

    CONSERVE ESTE MANUAL PARA SU FUTURA CONSULTA CONSERVARE IL PRESENTE MANUALE PER FUTURE CONSULTAZIONI ΦΥΛΑΞΤΕ ΤΟ ΕΓΧΕΙΡΙΔΙΟ ΓΙΑ ΜΕΛΛΟΝΤΙΚΗ ΑΝΑΦΟΡΑ GUARDE ESTE MANUAL PARA CONSULTA FUTURA РУКОВОДСТВО ДЛЯ СПРАВОК В БУДУЩЕМ BU KILAVUZU, DAHA SONRA BAŞVURMAK ÜZERE SAKLAYIN PART NO. 9378589100...
  • Page 2: Table Of Contents

    CONTENTS ADJUSTING THE DIRECTION OF AIR SAFETY PRECAUTIONS ........2 CIRCULATION ............13 FEATURES AND FUNCTIONS ....... 3 SWING OPERATION ..........14 NAME OF PARTS ........... 4 ECONOMY OPERATION ........14 PREPARATORY OPERATION ........ 6 CLEANING AND CARE ......... 15 OPERATION ............
  • Page 3: Features And Functions

    SAFETY PRECAUTIONS This appliance is not intended for use by persons (including children) with reduced ● CAUTION physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 4: Name Of Parts

    NAME OF PARTS Indoor unit 1 Air fi lter (in air intake grille) 2 Airfl ow direction fl aps 3 Air intake grille 4 Remote controller (wired) 5 Control panel (OPTION) 6 Remote control signal receiver 7 MANUAL AUTO button When the MANUAL AUTO button ●...
  • Page 5 NAME OF PARTS Remote controller 1 START/STOP button C Horizontal airfl ow direction and 2 SET TEMP. (temperature) button Swing button 3 MODE button D MAINTENANCE (FILTER RESET) 4 FAN button button 5 ECONOMY button E Operation lamp 6 TIMER MODE (CLOCK AD- F Timer and Clock indicator JUST) button G Operation mode indicator...
  • Page 6: Preparatory Operation

    PREPARATORY OPERATION Set the current day and time Press the DAY button and select the current day. appears around the selected day. Press the TIMER MODE (CLOCK ADJUST) button for 2 seconds or more. The time indicator on the remote controller will fl ash. Press the SET TIME (<...
  • Page 7: Operation

    OPERATION Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). To start/stop operation Press the START/STOP button. Operation lamp Air conditioner ON: Lit brightly Air conditioner OFF: Not lit To set the operation mode Operation mode setting ●...
  • Page 8 OPERATION Room temperature sensor selection This function is locked at the factory. In order to detect the room temperature correctly, consult authorized ser- • vice personnel when using this function. Indoor unit Press the ECONOMY button for more than 2 seconds to select whether the room temperature is detected at the indoor unit or the remote controller.
  • Page 9: Timer Functions

    TIMER FUNCTIONS OFF timer (See page 9.) Use this timer function to stop air conditioner operation. The timer operates and air conditioner operation stops after the set time has passed. The timer can be set up to 24 hours in advance. ON timer (See page 9.) Use this timer function to start air conditioner operation.
  • Page 10: Weekly Timer

    WEEKLY TIMER Weekly timer setting Press the TIMER SET button for Press the TIMER MODE button to select the weekly timer. 2 seconds or more. Day of the week setting ● Press the DAY button to select the day of the week, and then press the TIMER SET button to confi...
  • Page 11 WEEKLY TIMER WEEKLY timer operation To start To cancel ● ● When the weekly timer is selected, the • Press the TIMER DELETE button to ex. Operating time 7:00-18:00 timer starts automatically. cancel the timer mode. • The timer mode can also be The operating time for the current day canceled by changing the timer is displayed.
  • Page 12: Temperature Set Back Timer

    TEMPERATURE SET BACK TIMER Temperature SET BACK timer setting SET BACK If there is no existing SET BACK tempera- ture setting, “- -” will be displayed for the temperature. Press the SET BACK button to change to the SET BACK con- Press the TIMER SET button fi...
  • Page 13: Adjusting The Direction Of Air Circulation

    ADJUSTING THE DIRECTION OF AIR CIRCULATION Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). Start air conditioner operation before performing this procedure. To set the operation mode Vertical air direction adjustment ● Press the START/STOP button to start the air conditioner, and then pro- ceed as follows.
  • Page 14: Swing Operation

    SWING OPERATION Begin air conditioner operation before performing this procedure. To select/stop swing operation Press the vertical airfl ow direction and swing button for more than 2 seconds. (Stop the setting by pressing for more than 2 seconds again.) About Swing Operation The swing operation may stop temporarily when the air con- ●...
  • Page 15: Cleaning And Care

    CLEANING AND CARE Before cleaning the unit, be sure to stop the unit and disconnect the power supply. ● CAUTION Turn off the electrical breaker. ● A fan operates at high speed inside the unit, and personal injury could result. ●...
  • Page 16: Troubleshooting

    TROUBLESHOOTING Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the electrical WARNING breaker, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source. Always be sure to turn off the electrical breaker to ensure that power is completely off.
  • Page 17: Operating Tips

    TROUBLESHOOTING Symptom Items to check See Page CHECK ONCE Does not operate at all: Has the circuit breaker been turned off? ● MORE Has there been a power failure? — ● Has a fuse blown out, or a circuit breaker been tripped? ●...
  • Page 18 OPERATING TIPS Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL” (Reverse Cycle). Mode operation AUTO (in COOLING model): When AUTO (automatic changeover) operation fi rst selected, the fan will operate at very low speed for about a few ●...
  • Page 19: Self-Diagnosis

    OPERATING TIPS AUTO Restart In Event of Power Interruption Should the power supply to the air conditioner be interrupted Use of other electrical appliances (electric shaver, etc.) or ● ● by a power failure, the air conditioner will restart automatically nearby use of a wireless radio transmitter may cause the air in the previously selected mode once the power is restored.
