OPERATION

Instructions relating to heating (*) are applicable only to "HEAT & COOL MODEL " (Reverse Cycle).
To start/stop operation
To set the operation mode
Operation mode setting
Room temperature setting
Lower
Rise
Fan speed setting
ECONOMY OPERATION
En-5
9374343072-04_OM.indb Sec1:5
9374343072-04_OM.indb Sec1:5
Press the START/STOP button.
Operation lamp
Air conditioner ON: Lit brightly
Air conditioner OFF: Not lit
Press the MODE button to set the operation mode.
If DRY is selected, the fan speed will be set to AUTO.
AUTO
COOL
Press the SET TEMP. buttons to set the room temperature.
Temperature setting range
AUTO ............................................... 64 to 88 °F
COOL/DRY ....................................... 64 to 88 °F
* HEAT ................................................ 60 to 88 °F
Press the FAN button to set the fan speed.
AUTO
HIGH
Press the ECONOMY button to start or stop ECONOMY
OPERATION.
For details on the function, refer to page 11.
DRY
FAN
*HEAT
MED
LOW
QUIET
9/2/2010 2:59:01 PM
9/2/2010 2:59:01 PM
