Heatiator RAVE4013I-C Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model:
RAVE4013I-C
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instructions
and the manufactured home construction and safety standard,
Title 24 CFR, Part 3280 or Standard for Installation in Mobile
Homes, CAN/CSA Z240MH, in Canada.
This appliance is only for use with the type(s) of gas indicated
on the rating plate.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13
Owner's Manual
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
Installation and Operation
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAVE4013I-C and is the answer not in the manual?

Questions and answers

Related Manuals for Heatiator RAVE4013I-C

Summary of Contents for Heatiator RAVE4013I-C

  • Page 1 Technologies suggests NFI certifi ed or factory trained This appliance is only for use with the type(s) of gas indicated professionals, or technicians supervised by an NFI on the rating plate. certifi ed professional. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 2: Congratulations

    INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX XXXXXXXX XXXXXXXX (Serie): (Serie): Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 3: Table Of Contents

    D. Electrical Service and Repair ..... . 49 E. Junction Box Installation......49 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 4 D. Contact Information ......70  = Contains updated information. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 5: Limited Lifetime Warranty

    Limited 3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645D 01-16-13 Page 1 of 2 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 6 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645D 01-16-13 Page 2 of 2 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 7: Listing And Code Approvals

    • A 110-120 VAC circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 8: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 9: User Guide

    - A decorative fi rescreen. - Adjustable safety gate. DECORATIVE DOORS (NOT SHOWN) SECTION 2.D. FIXED GLASS ASSEMBLY (NOT SHOWN) SECTION 14.E. CLEAR SPACE SECTION 2.C. Figure 2.1 General Operating Parts Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 10: Clear Space

    Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one. For more information refer to the instructions supplied with your decorative door or front. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 11: Lighting Instructions (Ipi)

    See installation and operating instructions accompanying appliance. For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 12: After Fireplace Is Lit

    Wall above appliance feels hot to No action necessary. This appliance ships with a non-combustible material attached. Specifi ca- the touch. tions of the attached non-combustible material are listed in Section 1.E. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 13: Maintenance And Service

    (consult with your dealer) • Inspect draft shield to verify it is not damaged or missing. • Refer to Section 14.E for glass removal and replacement instructions. • Reinstall door or decorative front. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 14: Maintenance Tasks-Qualifi Ed Service Technician

    fl ashlight, voltmeter, indexed drill bit set, and a manometer. • Verify burner is properly secured and aligned with pilot or igniter. • Clean off burner top, inspect for plugged ports, corrosion or deterioration. Replace burner if necessary. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 15: Installer Guide

    (SECTIONS 7 and 8) CEILING FIRESTOP ON FLOOR OF ATTIC (SECTION 8.C) FRAMING HEADED OFF IN CEILING JOISTS (SECTION 8.C) FRAMING/HEADER (SECTION 5) WALL SWITCH GAS LINE (SECTION 11) Figure 4.1 Typical System Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 16: Design And Installation Considerations

    Electric drill and bits (1/4 in. magnetic) Plumb line Safety glasses Level Reciprocating saw Manometer Flat blade screwdriver 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300ºF minimum continuous exposure rating) Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 17: Framing And Clearances

    Unlike many traditional, single sided Heatilator fi replaces, clearance around air openings and for service access. the RAVE4013I-C is recessed into surround framing. The left and right nailing tabs were designed to ensure the fi replace is Due to high temperatures, the appliance should be locat- recessed to the correct location within the framing materials.

  • Page 18: Constructing The Appliance Chase

    1-1/2 in. nominal, such as with formed steel systems, then it may be necessary to adjust the adjacent framing dimensions so that the non- combustible board and wallboard joints are centered on the framing. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 19: Clearances

    Appliance Appliance Appliance (Vent Pipe) (Height) (Depth) (Width) Inches 8-5/8 42 1/4 18-1/4 Millimeters 1073 1270 * Adjust framing dimensions for interior sheathing (such as sheetrock) Figure 5.2. Clearances to Combustibles Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 20: Mantel And Wall Projections

    Non-Combustibles Above Appliance 1/2 IN. FACTORY-SUPPLIED NON-COMBUSTIBLE BOARD Note: For non-combustible fi replace fi nish material (marble, stone, etc) specifi cations refer to Section 13.C. Figure 5.7 Front Side Finishing Detail Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 21 3-1/2 IN. NON-COMBUSTIBLE BOARD SHIPPED WITH APPLIANCE 1 IN. 1 IN. AIR SPACE Figure 5.8 Non-Combustible Zone Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 22: Termination Locations

    Over 16/12 to 18/12 ..........7.0 Over 18/12 to 20/12 ..........7.5 Over 20/12 to 21/12 ..........8.0 * 3 foot minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 23 Figure 6.3 Minimum Clearances for Termination • Vinyl protection kits are suggested for use with vinyl siding. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 24: Vent Information And Diagrams

    • When penetrating a combustible ceiling, a ceiling fi restop must be installed. Horizontal • Horizontal runs of vent do not require vertical rise; Figure 7.1 horizontal runs may be level. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 25 V + H MAX. = 40 ft. (12.2 m) termination caps are not approved for use with pro- pane (LP) fuel. May lead to elevated glass temper- ature that may cause tempered glass breakage. Figure 7.4 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 26 CAUTION: The SLP-HRC-SS and SLP-HRC-ZC-SS termination caps are not approved for use with pro- pane (LP) fuel. May lead to elevated glass temper- ature that may cause tempered glass breakage. INSTALLED HORIZONTALLY Figure 7.5 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 27 CAUTION: The SLP-HRC-SS and SLP-HRC-ZC-SS termination caps are not approved for use with pro- pane (LP) fuel. May lead to elevated glass temper- ature that may cause tempered glass breakage. Figure 7.6 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 28 (LP) fuel. May lead to elevated glass temper- ature that may cause tempered glass breakage. INSTALLED HORIZONTALLY INSTALLED HORIZONTALLY Figure 7.7 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 29 fl ame height. If the vent confi guration has a total ver- tical of 15-44 feet, an exhaust restrictor may be needed. The exhaust restrictor can be located in the appliance manual bag. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 30 Note: There MUST be a 25% reduction in total H when using fl ex vent except when using the simple up and out installation (see Figure 7.3). Figure 7.11 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 31 Note: There MUST be a 25% reduction in total H when using fl ex vent except when using the simple up and out installation (see Figure 7.3). INSTALLED HORIZONTALLY Figure 7.12 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 32 Maximum= 40 ft. (12.2 m) Note: There MUST be a 25% reduction in total H when using fl ex vent except when using the simple up and out installation (see Figure 5.3). Figure 7.13 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 33: Coaxial To Colinear Venting

    CAUTION! DO NOT use any fl ue restrictor when vent- ing with the DV-46DVA-GCL adapter and LINK-DV30B kit. This may result in poor fl ame appearance, sooting, pilot malfunction, or overheating. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 34 INLET AIR VENT PIPE EXISTING CHIMNEY To minimize cold air drafts, seal with non-combustible insulation. DIRECT VENT FIREPLACE Minimum 10 ft. 3.05 m Maximum 40 ft. 12.2 m HEARTH FLOOR Figure 7.16 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 35: Vent Clearances And Framing

    * Shows center of vent framing hole for top venting. The center of the hole is one (1) in. (25.4 mm) above the center of the horizontal vent pipe. Figure 8.2 Wall Penetration Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 36: Install The Ceiling Firestop

    INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM 3 FASTENERS PER SIDE CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 8.5 Installing the Attic Shield Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 37: Install Attic Insulation Shield

    • Bend all tabs inward 90° around the top of the shield. These tabs must be used to prevent blown insulation from getting between the shield and vent pipe, and to maintain air space clearance. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 38: Appliance Preparation

    fi replace. For all venting applications, ensure that the pipe gasket is in place before attaching any pipe section. This gasket is shipped in place around the starting collar. See Figure 9.2. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 39: Securing And Leveling The Appliance

    Figure 9.3 shows the fireplace installed on the floor. However, this fireplace can be elevated off the floor provided that the fi replace is properly supported by framing materials and the ceiling clearances are maintained. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 40: Installing Vent Pipe (Slp Pipe)

    WARNING! Risk of Fire or Explosion! DO NOT break silicone seals on slip sections. Use care when removing termination cap from slip pipe. If slip section seals are broken during removal of the termination cap, vent may leak. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 41: Assemble Slip Sections

    Figure 10.6 Securing Horizontal Pipe Sections • Only outer pipes are sealed, sealing the inner fl ue is not required. • All unit collar, pipe, slip section, elbow and cap outer fl ues shall be sealed. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 42: Disassemble Vent Sections

    • Remove shingles or other roof covering as necessary to cut the rectangular hole for the support box. Cut the hole 1/8 in. (3 mm) larger than the support box outline. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 43: Install Metal Roof Flashing

    • Caulk the overlap seam of any exposed pipe sections that are located above the roof line. Figure 10.14 Assembling the Storm Collar Around the Pipe Figure 10.14 Assembling the Storm Collar Around the Pipe Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 44: Install Vertical Termination Cap

    • Once the pipe section and the termination cap have been connected, slide the wall thimble up to the interior wall surface and attach with screws provided. See Figure 10.16. Figure 10.16 Wall Thimble Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 45: Install Horizontal Termination Cap

    HEAT SHIELD EXTENDED 1-1/2 IN. (38 MM) MIN. HEAT SHIELD OVERLAP WALL SHIELD FIRESTOP SLIP SECTION CAN BE EXTENDED INNER VENT SHEATHING OUTER VENT INTERIOR EXTERIOR Figure 10.17 Venting through the wall Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 46: Gas Information

    3. Set the valve bracket on the front lip of the fi rebox bot- tom. Turn “off” the ball valve. Disconnect gas valve from the gas fl ex ball valve assembly at the pressure fi tting. See Figure 11.4. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 47: Gas Connection

    • In CANADA: Reduce burner orifi ce 10% for elevations cessed from the front of the fi replace when valve assembly between 2000 feet and 4500 feet. Above 4500 feet, is installed. consult local gas utility. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 48: Electrical Information

    3 volt system. remote control receiver are placed on the fi rebox bottom. GAS VALVE CONTROL MODULE DC ADAPTER CONTROL MODULE GROUND BATTERY PACK Figure 12.1 Valve Cavity Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 49: Electrical Service And Repair

    6. Reinstall the junction box. 7. Reposition the junction box heat shield such that it is positioned over the junction box. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 50: Finishing

    Unlike many traditional, single-sided Heatilator fi replaces, this fi replace is recessed into surround framing. The left and right nailing tabs were designed for the RAVE4013I-C model as a means to ensure the fi replace is recessed to the correct location within the framing materials.
  • Page 51 Note: Refer to Section 13.C regarding installation details associated with the Inside and Overlap Fit methods. The RAVE4013I-C must be fi nished using either the Deco or Illusion decorative fronts. See Figures 13.11 and 13.12. The fi nal fi replace installation can be accom- plished by either the Overlap Fit or Inside Fit method.
  • Page 52 12 inch intervals along the joint length. • The wall-board joints should be fi nished with a Taping Coat, followed by at least two subsequent Finish Coats of joint compound. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 53: Mantel And Wall Projections

    (Acceptable on both sides of opening) Sheathing MAX. 14 IN. MIN. MEASUREMENT FROM TOP OF FIREPLACE OPENING 1 IN.MIN. 4 IN. MAX. Figure 13.5 Clearances To Non-Combustible Mantels Or Other Non-Combustibles Above Appliance Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 54: Facing Material

    Both the Deco and Illusion decorative fronts can be in- stalled with an “Overlap” or “Inside Fit” method: Overlap Requirement: See Figure 13.8 and 13.9 Inside Fit requirement: See Figure 13.10. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 55 0 - 4 IN. 3/4 IN. 20-1/2 IN. APPLIANCE OPENING (HEIGHT) 3 IN. 0 - 4 IN. DRYWALL OR EQUIVALENT (1/2 IN.) Figure 13.10 Inside Fit Method (Deco Decorative Front Only) Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 56: Decorative Fronts

    991 mm (width). Outside dimension of decorative 44-1/2 in. 1130 mm front (width). Inside dimension decorative front 13 in. 330 mm (height). Outside dimension of decorative 19-1/2 in. 495 mm front (height). Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 57: Appliance Setup

    WARNING! Risk of Fire and Electric Shock! Use ONLY Hearth & Home Technologies-approved optional acces- sories with this appliance. Using non-listed accessories could result in a safety hazard and will void the warranty. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 58: Fixed Glass Assembly

    5. Tilt top of glass towards fi replace and engage both top spring latches Figure 14.2 Air Shutter Air Shutter Settings UPPER SPRING LATCH LOWER GLASS CLIP RAVE4013I-C 3/16 in. 9/16 in. Figure 14.1 Fixed Glass Assembly Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 59: Troubleshooting

    Verify module is securely grounded to metal chassis of appliance. d. Module voltage output / Valve/Pilot Verify battery voltage is at least 2.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 2.7. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 60 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 61: Reference Materials

    Inches Millimeters Location Inches Millimeters 1218 37-3/4 1092 39-1/16 15-3/4 6-5/8 13-1/4 39-5/8 1006 41-3/4 1060 2-3/16 3-9/16 6-7/8 17-1/4 47-1/16 1195 18-1/4 9-5/16 25-7/8 16-3/4 9-3/4 Figure 16.1 Appliance Dimensions Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 62: Vent Components Diagrams

    305 mm 1-1/2 in. 8-7/8 in. 5-1/2 in. 12 in. 38 mm 225 mm 305 mm 146 mm SLP-WS SLP-HVS Wall Shield Firestop Horizontal Pipe Support Figure 16.2 SLP Series Vent Components Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 63 356 mm (101 mm) (97 mm) 5-1/16 in. 10-9/16 in. 8 in. (128 mm) (203 mm) 269 mm SL-2DVP SLP-CCS-BK Adapter Cathedral Ceiling Support Box-Black Figure 16.3 SLP Series Vent Components Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 64 SLP-HRC-SS SLP-HRC-ZC-SS HORIZONTAL TERMINATION CAP 12 IN. 305 mm 7 IN. 178 mm 15-1/2 IN. 394 mm DVP-FBHT SLP90 SL-2DVP DVP-FBHT Figure 16.4 SLP Series Vent Components Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 65 424 mm (424 mm) 12-1/2 IN. SLP-LPC (318 mm) SLP Low Profi le Cap COAXIAL to COLINEAR VENTING LINK-DV30B DVP-2SL DV-46DVA-GCL Flex Liner Kit Adapter Coaxial/Colinear Appliance Connector Figure 16.5 Vent Components Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 66 13-7/8 in. (292 mm) (352 mm) 12-1/4 in. (311 mm) 16 in. (406 mm) DVP-BEK2 PVK-80 (For use with IPI and DSI appliances only.) DVP-HPC Cap Brick Extension Figure 16.6 Vent Components Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 67: Service Parts List

    Base Pan 2292-010 Burner Assembly 2292-007 Glass Door Assembly GLA-SLR 4021-013 Junction box Bracket, Junction Box 2195-154 Qty 2 req 2198-200 Nailing Tab Additional service part numbers appear on following page. 2/13 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 68: Service Parts

    3 Volt Transformer 593-593A 12.11 Battery Pack 593-594A 12.12 Module 593-592 12.13 Bulkhead W/Flex Tube 383-302A 12.14 Grommet 2118-420 12.15 Pilot Bracket 2292-127 Additional service part numbers appear on following page. Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
  • Page 69 Touch Up Paint TUP-GBK-12 Wall Switch Kit WSK-21-W Conversion Kit NG Conversion Kit LP LPK-RAVE-C Pilot Orifi ce NG 593-528 Pilot Orifi ce LP 593-527 Regulator NG NGK-DXF Regulator LP LPK-DXF Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...

  • Page 70: Contact Information

    This product may be covered by one or more of the following patents: (United States) 5601073, 5613487, 5647340, 5890485, 5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945B Printed in U.S.A. - Copyright 2013 Heatilator • RAVE4013I-C • 2293-900 Rev. E • 2/13...
