Page 1: Installation Instructions
Installation instructions User guide Dishwasher DW60 ‘classic range’ models NZ AU SG... -
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions Introducing your dishwasher Using your dishwasher Wash programme chart Caring for your dinnerware Dishwasher standards test Loading Detergent Rinse aid Care and cleaning Fault codes Troubleshooting Warranty and service Important! SAVE THESE INSTRUCTIONS The models shown in this user guide may not be available in all markets and are subject to change at any time. -
Page 4: Safety And Warnings
Safety and warnings Important safety precautions For your safety, follow basic precautions when using your dishwasher, including the following: Please read all instructions before operating your dishwasher. The information in this user guide must be followed to minimise the risk of fire or explosion, or to prevent property damage, personal injury or loss of life. -
Page 5: Installation
Safety and warnings Installation This dishwasher must be installed and positioned in accordance with the ‘Installation instructions’ before it is used. Installation and service should be performed by a qualified technician. If the power supply cord is damaged, it must be replaced by the manufacturer or Authorised Service Centre or a similarly qualified person in order to avoid a hazard. -
Page 6: Installation Instructions
Installation instructions Before you start These instructions are intended as a guide only. It is the responsibility of the plumber and electrician to ensure that each installation complies with the Government and local government by-laws. Check packaging and dishwasher immediately for signs of transport damage. If the appliance is damaged, do not put into use but contact your Fisher &... - Page 7 Plumbing Drainage The recommended method of installation is shown in diagrams 1,2 and 3. The diagrams are designed to eliminate problems that occur with combined sink – dishwasher waste systems. The standpipe must have a minimum diameter of 38 mm and stand 750mm above the floor. A drain hose support is provided to hold the drain hose in place in the standpipe (See diagrams 1 and 2).
- Page 8 Installation instructions Water inlet connections The dishwashers all have a single valve water connections. We recommend a cold water connection to give the best wash performance and energy efficiency. Important! The appliance should be connected to the water main using a new hose set. Old hose sets should not be used.
- Page 9 If the electrical socket to which the appliance must be connected is not appropriate for the plug, replace the whole cable, rather than using adaptors as they could cause overheating and burns. Important! The dishwasher plug must be accessible even when the appliance is installed as a built-in unit so that maintenance can be done safely.
-
Page 10: Introducing Your Dishwasher
Introducing your dishwasher Dishwasher interior Upper rack Top spray arm Lower rack Bottom spray arm Washing filter Detergent and rinse aid dispenser Water inlet hose Drain hose Power supply cord Cutlery basket Fig. 1 Dishwasher interior... -
Page 11: Control Panel
Power Programme button Programme indicator Power Reset button Delay start Time remaining indicator Heater indicator Quick start Remove all food scraps and load the dishes. Add detergent. Check rinse aid. Check that there is nothing obstructing the spray arms. Close the door. Turn the POWER button ON. -
Page 12: Interrupting The Programme
Using your dishwasher Interrupting the programme Models DW60CD Press the Power button. Open the door slowly. Important! There is a risk of being sprayed with hot water. Do not open the door fully until the spray arm has stopped rotating. If the door is left open during the wash cycle the dishwasher will beep ten times every thirty seconds. - Page 13 Delay Start (models DW60CDW2 and DW60CDX2 only) This feature can delay the start of a wash programme from 1 – 12 hours. To activate the delay start: Turn your dishwasher ON. Press the Delay button. The Delay indicator will flash and the Time remaining indicator will change to ‘1h’...
-
Page 14: Wash Programme Chart
Wash programme chart Model: DW60CSW1 and DW60CSX1 Wash programmes – when to use HEAVY DUTY NORMAL Dishes with Heavily soiled normal soils pots, pans and for optimum dishes. wash and dry performance. Hot pre-wash. Cold pre-wash. Wash Wash 55 °C. 70 °C. - Page 15 Model: DW60CDW2 and DW60CDX2 Wash programmes – when to use HEAVY DUTY NORMAL Dishes with Heavily soiled normal soils pots, pans and for optimum dishes. wash and dry performance. Hot pre-wash. Cold pre-wash. Cold pre-wash. Wash Wash 55 °C. 70 °C. Extended wash Cold rinse.
-
Page 16: Caring For Your Dinnerware
Caring for your dinnerware The combination of high temperatures and dishwasher detergent may cause damage to some items if they are washed in your dishwasher. Remember, if in doubt about any items to be washed in the dishwasher, follow the instructions from the manufacturer of the items, or wash them by hand. -
Page 17: Dishwasher Standards Test
This dishwasher is tested to AS/NZS 2007 standards for both wash and dry performance. The following are loading pattern diagrams, detergent quantities and rinse aid quantities used for the dishwasher. Wash programme Detergent quantities Rinse aid setting Maximum place setting Recommended loading pattern - The height-adjustable top basket must be in the uppermost position. -
Page 18: Loading
Loading Take care when loading dishes to ensure that there is enough space and room for the water to reach all areas, particularly the cup racks. If there are any items blocking the spray arms’ paths or the wash water, then the performance will be ineffective. Before placing the dishes in the dishwasher, remove larger food particles to prevent the filter from becoming clogged. - Page 19 Loading How to load the upper rack The upper rack is designed to hold items like glasses, cups, saucers, plates, small bowls and shallow pans. Position these items so that they cannot be moved during the wash. Upper rack adjustment for models DW60CSW1 and DW60CSX1 The upper rack can be adjusted for height by using the rollers located on both sides of the rack (see below).
-
Page 20: Detergent
Detergent Important! Never sprinkle or pour detergent directly onto any item in the dishwasher. Hand washing liquids, soap, laundry detergents or disinfectants will damage your dishwasher. Filling the detergent dispenser Press the button on the top of the dispenser to open the cover. Pour the detergent for the wash cycle into the larger main detergent compartment. -
Page 21: Filling The Rinse Aid Dispenser
We highly recommend the regular use of liquid rinse aid to give the best drying results. Rinse aid gives a streak-free, sparkling clean look to glass and chinaware. In addition it prevents metal from tarnishing. The rinse aid dispenser is located on the inside panel of the door. Filling the rinse aid dispenser Open the dispenser by turning the cap in an anticlockwise direction. -
Page 22: Care And Cleaning
Care and cleaning After each wash, turn off the water supply to the dishwasher and leave the door ajar 30°, so that moisture and odours are not trapped inside. Important! The door should not be left in the fully open position as this could present a tripping hazard. Before cleaning or performing maintenance, always remove the power plug from the wall socket. - Page 23 Care and cleaning Cleaning the drain filters and spray arms Regular inspection and maintenance of your dishwasher helps to prevent problems from occurring. You should carefully inspect your dishwasher regularly. Check that no grease or scale has accumulated on the inside of your dishwasher. If you discover any deposits, clean them thoroughly with warm water on a soft, lint-free cloth.
-
Page 24: Fault Codes
Fault codes Please read the following pages before you call for service. You can correct many of your dishwasher’s problems yourself, using the checklists on the following pages. Problem Fault code First 2 programme indicators flashing 1 and 3 programme indicator lights flashing 1 and 4... -
Page 25: Troubleshooting
Problem Dishwasher will not start. Lower spray arm rotates with difficulty. Lid of detergent dispenser cannot be closed. Remnants of detergent stuck inside dispenser. Indicator lights do not extinguish after washing has finished. Water remains inside dishwasher after wash has ended. - Page 26 Troubleshooting Problem Knocking or rattling sound during wash. Unclean dishes. Plastic items are discoloured. Not enough detergent. White stains are left on dishes; glasses have a milky appearance. Dishes, cutlery have not dried. Selected programme did not Probable cause Spray arm knocking against dishes. Stop cycle and reposition Dishes have been stacked incorrectly.
- Page 27 Problem Glasses have dull appearance. Rinse aid set too low. Tea stains or traces of lipstick have not been completely removed. Traces of rust on cutlery. Glasses clouded and discoloured; coating cannot be removed. Smears left on glasses and cutlery. Probable cause Not enough detergent.
-
Page 28: Warranty And Service
Warranty and service Manufacturer’s warranty When you purchase any new Fisher & Paykel whiteware Product you automatically receive a two year Manufacturer’s Warranty covering parts and labour for servicing. Fisher & Paykel undertakes to Repair or, at its option, replace without cost to the owner either for material or labour any part of the Product, the serial number of which appears on the Product, which is found to be defective within TWO YEARS of the date of purchase. -
Page 29: Customer Care
Customer care Check the things you can do yourself. Refer to your User Guide and check: your appliance is correctly installed you are familiar with its normal operation If after checking these points you still need assistance please refer to the following: New Zealand If you need assistance...* Call your Fisher &... - Page 32 Copyright © Fisher & Paykel 2007. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
