Page 1: Gas Cooktop
JET: CG602Q, CG602M, CG902Q, CG902M TITAN: CG901, CG901M Gas cooktop User guide NZ & AU... -
Page 3: Table Of Contents
Contents Introducing your cooktop/hob Temperature control Flame Failure safety feature Cookware Cleaning Safety & warnings Frequently asked questions Trouble shooting Warranty Customer care Recipe Important! It is important that the User Guide should be retained with the appliance for future reference. -
Page 4: Introducing Your Cooktop/Hob
Introducing your cooktop/hob Now that your new cooktop is installed and ready to use, you will want to know everything about it to ensure excellent results right from the start. This booklet will introduce you to the features and special talents of your cooktop/hob. We recommend you read the whole book before you start using your cooktop, for the sake of safety as well as success. -
Page 5: Temperature Control
If the cooktop/hob does not light Check that you know how the flame failure device works (refer to page 4). Check that the power is switched on allowing the electronic ignition to work. -
Page 6: Flame Failure Safety Feature
Letting go of the burner knob too soon will extinguish the flame. Your cooktop has two probes at the back of the burners, one will be the spark electrode and the other is the flame failure probe. -
Page 7: Cookware
Cookware Using a wok When using a wok on the centre burner, simply turn over the pan support. One side provides a flat surface for flat based pots while the other side has stems specifically designed to support a wok. Care should be taken when using a large wok that other pots are not pushed sideways enough to become unstable or deflect heat onto nearby walls. -
Page 8: Cooking Tips
Best results are obtained by placing the skillet over the large skillet burner on the Jet 9 series gas cooktop or over the left hand burners on the Titan models. Always use medium to high temperatures and heat the skillet well before cooking on it. Oil the food with Olive Oil Spray prior to cooking, not the skillet, to avoid splattering and smoking. -
Page 9: Hints And Tips
Chinese broccoli, long beans and asparagus. The wok burner is primarily designed for woks but may be used with 17- 23cm diameter pots with care. When using a wok only use the circular wok stand supplied with your Jet cooktop. Wok on raised... -
Page 10: Cleaning
Cleaning Apply soapy water with a soft sponge or cloth only when the cooktop is cool. Soaking stubborn stains under the soapy cloth for a few minutes will help make them easier to remove. Do not use steel soap pads as this may dull the appearance of the appliance over time. - Page 11 Repositioning the pan supports Titan models The Flip top wok support goes in the centre over the wok burner. The other two pan supports are interchangeable but need to be rotated to match the rounded corners of the base insert. Rounded corners Correct pan support orientation - Titan models Re-assembling your wok burner...
-
Page 12: Safety & Warnings
Do not use an asbestos mat between the flame and the saucepan as this may cause serious damage to your cooktop. Do not place aluminium foil or plastic dishes on the cooktop burners. Do not let large saucepans or frying pans overlap the bench as this can deflect heat onto your benchtop and damage the surface. -
Page 13: Abnormal Operation
Electrical supply cord If the electrical supply cord is damaged, it must only be replaced by an authorised person. Ensure that the electrical connection plug is accessible after installation. Marine craft & caravan installation Where this appliance is installed in marine craft or in caravans, it shall not be used as a space heater. -
Page 14: Frequently Asked Questions
Yes, there are a number of factors which could be causing this 1. If you use bottled gas this may indicate you are getting near the end of the bottle. 2. Your cooktop may not be suited to the gas you are using, check with your service person/installer. -
Page 15: Trouble Shooting
Check the burner parts are assembled correctly and that the burner cap is sitting flat on the burner. Your cooktop has a safety feature called ‘flame failure’ . When lighting a burner, it is necessary to hold down the knob for 5 seconds until it is properly engaged. -
Page 16: Warranty
Warranty When you purchase any new Fisher & Paykel whiteware Product you automatically receive a 2 year Manufacturer’s Warranty covering parts and labour for servicing. Fisher & Paykel undertakes to Repair or, at its option, replace without cost to the owner either for material or labour any part of the Product, the serial number of which appears on the Product, which is found to be defective within TWO YEARS of the date of purchase. -
Page 17: Customer Care
Customer care Before you call for service or assistance ... Check the things you can do yourself. Refer to your User Guide and check... Your product is correctly installed You are familiar with its normal operation If after checking these points you still need assistance, please refer to the following or contact us through our website: In New Zealand if you need assistance ...* Call your Fisher &... -
Page 18: Recipe
Recipe Beef bourginon (Serves 2 - 4) The Simmermat is perfect for stews and soups. Long slow cooking at a gentle simmer gives meat dishes that are tender and full of flavour. Try this variation on a French classic. 450g chuck or stewing steak, cubed 4 tbsp oil 200g tiny onions or 2 large onions, chopped 200g carrot, peeled and cut into large slices... - Page 20 Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available. www.fisherpaykel.com NZ AU Gas cooktop user guide Published: 12/2003 Part No. 531927 A...
