Page 1: Installation Instructions
Installation instructions User guide Gas cooktops CG604 models NZ AU... -
Page 3: Table Of Contents
Contents Safety and warnings Installation instructions Introduction Using your cooktop Care and cleaning Troubleshooting Warranty and service Important! SAVE THESE INSTRUCTIONS The models shown in this User Guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our website www.fisherpaykel.com or... -
Page 4: Safety And Warnings
Always disconnect the cooktop from mains power supply before carrying out any maintenance operations or repairs. In the room where the cooktop is installed, there must be enough air to allow the gas to burn correctly, according to the current local regulations. - Page 5 Safety and warnings Particular attention shall be given to the relevant requirements regarding ventilation. This product should not be sealed into the bench with silicone or glue. Doing so will make future servicing difficult. Fisher & Paykel will not be liable for costs associated with releasing such a product, nor for repairing damage that may be incurred in doing this.
- Page 6 This appliance becomes hot during use. Do not touch the cooktop components, burners, trivets/pan supports or the base when hot. Before cleaning, turn the burners off and make sure the whole cooktop is cool. Failure to do so may result in serious injury. Explosion Hazard Do not store fl ammable materials such as gasoline near the cooktop.Do not...
-
Page 7: Operation
Do not use an asbestos mat or decorative covers between the flame and the saucepan as this may cause serious damage to your cooktop. Do not place aluminium foil or plastic dishes on the cooktop burners. Do not let large saucepans or frying pans overlap the bench as this can deflect heat onto your benchtop and damage the surface. -
Page 8: Installation Instructions
Installation instructions This cooktop has been designed and constructed in accordance with the following codes and specifications: AGA101 (AS 4551) Approval Requirements for Domestic Gas cooking appliances AS/NZS 60335-1 General Requirements for Domestic electrical appliances AS/NSZ 60335-2-6 Particular Requirements for Domestic electrical cooking appliances AS/NSZ 1044 Electromagnetic Compatibility Requirements. - Page 9 Installation instructions Clearances Installation clearances and protection of combustible surfaces shall comply with the current local regulations e.g. AG 601 (AS 5601) - Gas Installations code. Fig. 2 Fig. 3...
- Page 10 Each cooktop is provided with an installation kit including brackets and screws for fastening the top to fixture panels from 2 to 4 cm thick. Turn the cooktop upside down and fasten the brackets “F and R” to the appropriate socket holes, without tightening the screws “B” for the moment.
- Page 11 Gas supply The connection must be executed by an authorised person according to the relevant standards. Before connecting the appliance to the gas main, mount the brass conical adaptor onto the gas inlet pipe, upon which the gasket has been placed (figures 5 and 6). Conical adaptor and gasket are supplied with the appliance (packed with conversion kit for use with Natural gas or Universal LPG).
- Page 12 Installation instructions After connecting the gas supply, check the piping and connections for leaks using a soap and water solution. The presence of bubbles indicates a leak, tighten or replace connections as appropriate. Important! Do not use any naked flame to check for leaks. The operation of the appliance MUST be tested before leaving.
- Page 13 Important! If the cooktop is suitable for use with Natural gas and must be converted for use with Universal LPG, before connecting to gas main remove the appliance gas regulator and replace with test point adaptor (see fig. 5, 6)
- Page 14 Installation instructions Minimum burner setting adjustment When changing from one type of gas to another, the minimum tap output must also be cor- rect, considering that in this position the flame must be about 4 mm long and must remain lit even when the knob is turned sharply from the maximum to the minimum position.
-
Page 15: Electrical Requirements
Important! Installation must be carried out according to the manufacturer's instructions. Incorrect installation may cause harm and damage to people, animals or property, for which the manufacturer accepts no responsibility. Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains. - Page 16 Installation instructions Important! Replacing the power cord must be done by a qualified electrician in accordance with the instructions supplied by the manufacturer and in compliance with established electrical regulations. Electric diagrams key Ignition switch Ignition coil Terminal block Spark electrode Fig.
-
Page 18: Introduction
About your new cooktop Thank you for buying a Fisher & Paykel gas cooktop. Once it is installed and ready to use, you will want to know everything about it to make sure you get excellent results right from the start. - Page 19 Fig.1 CG604 with rapid burner (no flame failure safety feature) Fig.2a CG604 with wok burner ( with flame failure safety feature) Fig.2b CG604 with wok burner (no flame failure safety feature) Auxiliary burner Semi-rapid burner Rapid burner Wok burner Cooktop controls...
-
Page 20: Using Your Cooktop
Using your cooktop Gas burners The knob (Fig. 3) controls the flow of gas through the safety tap. closed valve maximum aperture or flow minimum aperture or flow You can choose to cook at any heat between and OFF. Fig. 3a Burner knob and symbols (models without flame failure safety feature) Fig. - Page 21 Flame failure safety feature (some models only) Some cooktop models have a flame failure safety device. These models have a flame failure probe as well as the ignitor (see Fig 5).
-
Page 22: If The Cooktop Does Not Light
Using your cooktop If the cooktop does not light If the cooktop does not light, check that: The cooktop is plugged in and the electricity is switched on. The gas is turned on. Flame failure models only: You have held down the knob for at least ten seconds. - Page 23 Choosing a burner Use flat-bottomed pans, and make sure that they match your burner, as shown in the following table. A small pot on a large burner is not efficient. Diameters of pans which may be used on the cooktop Burners Auxiliary...
- Page 24 The wok stand MUST BE PLACED ONLY over the pan support for the wok burner. CORRECT WRONG Fig. 7 Incorrect use of wok on burner Fig. 8 Correct use of wok on wok stand over burner Important! The cooktop becomes very hot during operation. Keep children well out of reach.
-
Page 25: General Advice
Daily Monthly Every 3-4 years Before you begin cleaning you must ensure that the cooktop is switched off. Clean the cooktop regularly – do not let stains become burnt on. Allow the appliance to cool down before cleaning. Avoid leaving acidic substances (lemon juice, vinegar etc.) on the surfaces. - Page 26 It is very important to check that the burner flame spreader and the cap have been correctly positioned. Failure to do so can cause serious problems. Note: To avoid damage to the electric ignition do not try to light the cooktop when the burners are not in place.
- Page 27 Replacing the wok burner To replace the wok burner: Fit the burner ring to the housing as shown by the arrow in fig. 11. Make sure the burner is not able to rotate (fig. 12) Fig. 11 Fitting the burner ring to the housing. Fig.
- Page 28 Toothbrush and methylated spirits. Probe (in Toothbrush and methylated spirits. models with flame failure safety valves) Important Always allow cooktop parts to cool completely before cleaning them. Always apply minimal pressure with abrasive cleaners. Clean spills regularly before they become burnt on.
-
Page 29: Troubleshooting Chart
The gas pressure may not be at the correct level. Check with your service person or installer. Your cooktop may not be set up for the gas you are using. Check this with your service person or installer. Check the burner parts are clean and dry. Check the assembly and make sure the burner cap is sitting flat. -
Page 30: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance, please refer to the Service &... - Page 32 You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available. www.fisherpaykel.com NZ AU Gas cooktop installation and user guide Published: 11/2007 F&P Part No. 599371 C Elba Part No. 1102964 - ß4...
