- Page 1 WR-1 Version 1...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 3 Only use attachments/accessories specified by the manufac- turer. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Unplug this apparatus during lightning storms or when unused for long periods of time.
- Page 4 Features AM/FM 2 bands. Wooden cabinet made of MDF in real cherry or walnut or other optional wood veneer. Soft and precision tuning. Rotary tuning and volume control. Tuning LED indicator. Detachable power cord. Headphone socket. REC out socket can be used as a separate tuner to the Hi-Fi amplifier or record the radio program by using the output.
- Page 5 3 inches 7W full range heavy-duty magnet speaker. (10) Dynamic Bass compensation for rich bass. (11) External AM antenna terminal to connect outdoors AM anten- (12) External F type FM antenna terminal to connect outdoors FM antenna. (13) Internal/External FM antenna switch to select built-in or exter- nal antenna.
-
Page 7: Power Your Radio
Controls Power and AM/FM band switch Volume Control Speaker Dial scale Dial indicator Tuning Control AC power cord socket 12V DC input socket ( ideal for vehicles/boats ) Headphone socket REC out socket External/Internal antenna switch F-type external antenna terminal AM external antenna terminal Tuning LED indicator Power your radio... -
Page 8: Operating Your Radio - Fm
Operating your radio FM Connect the Antenna The radio comes with built-in AM/FM antenna. To improve FM re- ception, insert the end of the supplied FM wire antenna into the F-type antenna terminal and adjust the wire for best reception. A 75 ohm coaxial cable of outdoor antenna may also be attached to the terminal. -
Page 9: Headphone Use
Operating your radio AM Connecting the antenna The radio comes with built-in AM antenna which should be enough for normal listening. To improve the AM reception, you may connect the outdoor AM antenna with AM antenna terminal. Turn on your radio by switching the Power knob to AM position. Rotate the Tuning Control to select the desired station. -
Page 10: Specifications
REC out socket The radio can be used as a separate tuner by connecting this input to Hi-Fi system (amplifier) or using this input to make recording in mono from audio program. Specifications Frequency Coverage: FM 87.50 - 08 MHz 520 - 70 kHz Power: AC 20 V/60 Hz/25W Internal Antenna System:... - Page 11 REC OUT: output impedance: 2.2Kohm DC IN: 12V/1A center pin positive (operational voltage 9-14V) Accessories: FM F-terminal antenna wire AC Power Cord Dimension: 240(W) x 114 (H) x 169.5 (D) mm Weight: 2.35 KG.
