- Page 1 WR-11BT 中文 Version 1...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 3 Only use attachments/accessories specified by the manufacturer. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
- Page 5 Controls Power and AM/FM band switch Volume Control Speaker Dial scale Dial indicator Tuning Control AC power cord socket 12V DC input socket ( ideal for vehicles/boats ) Headphone socket REC out socket Aux in socket External/Internal antenna switch F-type external antenna terminal NFC detection area Tuning LED indicator...
-
Page 6: Power Your Radio
Power your radio AC operation Before you plug the AC cord into the radio, be sure the AC voltage is correct. Insert the plug on the end of the supplied power cord into the AC power socket on the back of the radio. DC operation For outdoors use, you can power the radio by using 2V DC input socket from a DC power supply (example, from the power supply of... - Page 7 Operating your radio AM . Connecting the antenna The radio comes with built-in AM antenna which should be enough for normal listening. To improve the AM reception, you may connect the outdoor AM antenna with AM antenna terminal (USA version only). 2.
- Page 8 You can now play the music in your Bluetooth-enabled device via WR-BT. Note: 1) If there are 2 Bluetooth devices searching for WR-11BT, it will show its availability on both devices. However, if one device links with the WR-BT first, then the other Bluetooth device won't find the WR-11BT on its list.
- Page 9 Pair with your Bluetooth device before If your Bluetooth device already paired with WR-BT previously, the unit will memorize your Bluetooth device, but it does not support the automatic reconnection, reconnect with this product following the steps above. WR-BT can memorize up to 8 sets of Bluetooth device, when the memory exceed this amount, the earliest paired device will be cancelled from the radio.
- Page 10 Pairing and playing your device via NFC WR-11BT is equipped with wireless NFC (Near Field Communication) feature, allowing playing NFC-enabled devices to pair and play the music. For non-NFC devices, please refer to the above sections for standard Bluetooth pairing.
-
Page 11: Headphone Use
Disconnecting your NFC-enabled device To disconnect your device, simply touch it again on the top of the unit. The LED light for Bluetooth icon will then start to flash indicating deactivation of Bluetooth. Headphone use Headphone use with this radio should be fitted with a 3.5 mm jack plug. -
Page 12: Specifications
REC out socket The radio can be used as a separate tuner by connecting this input to Hi-Fi system (amplifier) or using this input to make recording in mono from audio program. Specifications Frequency Coverage: FM 87.50 - 08 MHz AM 520 - 70 kHz Power: AC 120 V / 60 Hz / 25 W (USA version) AC 230 V / 50 HZ / 25 W (European version) - Page 13 Aux in socket: 3.5 mm dia. Stereo jack. Input sensitivity: IN 300mV Output 7 W @ 00 Hz Input impedance: 47 Kohm REC OUT: output impedance: 2.2 Kohm DC IN: 12 V / 1 A center pin positive (operational voltage 9-14 V) External diameter: 5.5 mm Internal diameter: 2.0 mm Accessories:...
