PR-D7
GB
Version 1

Advertisement

   Related Manuals for Sangean PR-D7

   Summary of Contents for Sangean PR-D7

  • Page 1 PR-D7 Version 1...
  • Page 2: Important Safety Instructions

    Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the instructions. Do not install near any heat sources such as radiators, heat reg- isters, stoves or other apparatus (including amplifiers) that pro- duce heat.
  • Page 3 Protect the power cord from being walked on or pinched par- ticularly at plug, convenience receptacles, and the point where they exit from the apparatus. Only use attachments/accessories specified by the manufac- turer. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
  • Page 5: Lcd Display

    Controls Speaker Band Selection LCD Display Charge LED indicator Alarm by radio Alarm by buzzer Power/Auto shut off button Volume Control Tuning Control Station Scan and Time Set Station Presets Battery Compartment FM Telescopic Antenna Headphone socket DC In socket LCD Display Radio Band Station Frequency...
  • Page 6: Battery Operation Using Alkaline Batteries

    Battery operation using alkaline batteries . Remove the battery cover on the back of the unit by sliding the cover in the direction of the arrow. 2. Insert 6 x AA ( UM3, LR6 ) alkaline batteries into the spaces in the compartment.
  • Page 7: Battery Operation Using Rechargeable Batteries

    Battery operation using rechargeable batteries . Remove the battery cover on the back of the unit by sliding the cover in the direction of the arrow. 2. Insert 6 x rechargeable AA ( UM3 ) batteries into the spaces in the compartment.
  • Page 8 In addition, the calculation of charging time is based on the capac- ity of the rechargeable battery and charging current power output of the charger. The two examples in the below table are for your reference only. PR-D7(p6) Capacity Charging Current Charging Time...
  • Page 9: Setting The Clock

    Using the supplied AC power adaptor The supplied AC adaptor is 2 Volts DC output 500 mA center pin positive. . Insert the adaptor plug into the DC IN socket on the left hand side of the radio. 2. Plug the adaptor into a standard 3A mains socket outlet. Whenever the adaptor is plugged into the radio and switched on the mains, the batteries are automatically disconnected.
  • Page 10: Operating The Radio

    Operating the radio This radio is equipped with three tuning methods – Scan tuning, Manual tuning and Memory presets recall. Scan tuning . Press the Power button to turn on the radio. 2. Select the required waveband by pressing the Band button. For FM band fully extend and rotate telescopic aerial to get best reception.
  • Page 11: Storing Stations In Preset Memories

    Manual tuning / station searching . Press the Power button to turn on the radio. 2. Select the required waveband by pressing the Band button. Adjust the antenna as described above. 3. A single press on either the Tuning Up or Down button will change the frequency in the following increments: FM: 50 or 00 kHz AM (MW): 9 or 10 kHz...
  • Page 12: Setting The Radio Alarm

    Recalling stations from preset memories . Press the Power button to turn on the radio. 2. Select the required waveband. 3. Momentarily press the required preset button, the preset number and station frequency will appear in the display. Setting the radio alarm When the radio alarm is selected, the radio will turn on and play the chosen radio station at the chosen alarm time.
  • Page 13 . The radio alarm can be set either radio is on or off. 2. Press and hold the radio alarm button for 2 seconds, the radio will show radio alarm symbol followed by a beep. 3. Display Hour will flash, using Tuning up/Down button to select the hour then press button again to confirm hour setting.
  • Page 14 Setting the HWS (Humane Wake System) buzzer alarm A beep will activate when selecting the HWS alarm. The alarm beep will increase in volume every 5 seconds for one minute fol- lowed by one minute silence before repeating the cycle. The HWS alarm will sound for an hour until turning off by pressing the Power button.
  • Page 15: Snooze Function

    Snooze function . Whilst the alarm is activated, press any buttons except the Power button will activate the snooze function. The radio or HWS buzzer alarm will be silenced with interval of 5 minutes. 2. The display will flash both the snooze symbol and the alarm symbol.
  • Page 16: Software Version

    Software version The software display cannot be altered and is just for your refer- ence. . Turn off the radio. 2. Press the Band/step button for 2 seconds until the software version number (e.g. P01) shown on the display. Time format 3.
  • Page 17: Specifications

    Specifications Power Requirements AC Power adaptor: DC 2V 500 mA center pin positive Batteries: 6 x UM-3 ( AA size, LR6 ) Battery life: Approx. 38 hours of listening for 4 hours a day at normal volume using alkaline cells. Frequency Coverage: FM 87.50 –...
