Sangean WR-1 User Manual

Hide thumbs
Also See for WR-1
Manual - 12 pages
User manual - 11 pages
Brochure - 1 page

Advertisement

WR-1
GB
Version 1

Advertisement

   Related Manuals for Sangean WR-1

   Summary of Contents for Sangean WR-1

  • Page 1 WR-1 Version 1...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 3 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
  • Page 4 Features (1) AM/FM 2 bands. (2) Wooden cabinet made of MDF in real cherry or walnut or other optional wood veneer. (3) Soft and precision tuning. (4) Rotary tuning and volume control. (5) Tuning LED indicator. (6) Detachable power cord. (7) Headphone socket.
  • Page 5 (10) 3 inches 7W full range heavy-duty magnet speaker. (11) Dynamic Bass compensation for rich bass. (12) External AM antenna terminal to connect outdoors AM antenna (USA version only). (13) External F type FM antenna terminal to connect outdoors FM antenna. (14) Internal/External FM antenna switch to select built-in or external antenna.
  • Page 6 DC 12 V 1A...
  • Page 7: Power Your Radio

    Controls Power and AM/FM band switch Volume Control Speaker Dial scale Dial indicator Tuning Control AC power cord socket 12V DC input socket ( ideal for vehicles/boats ) Headphone socket REC out socket Aux in socket External/Internal antenna switch F-type external antenna terminal AM external antenna terminal (USA version only ) Tuning LED indicator Power your radio...
  • Page 8: Operating Your Radio - Fm

    Operating your radio FM 1. Connect the Antenna The radio comes with built-in AM/FM antenna. To improve FM reception, insert the end of the supplied FM wire antenna into the F-type antenna terminal and adjust the wire for best reception. A 75 ohm coaxial cable of outdoor antenna may also be attached to the terminal.
  • Page 9: Headphone Use

    Operating your radio AM 1. Connecting the antenna The radio comes with built-in AM antenna which should be enough for normal listening. To improve the AM reception, you may connect the outdoor AM antenna with AM antenna terminal (USA version only). 2.
  • Page 10: Specifications

    REC out socket The radio can be used as a separate tuner by connecting this input to Hi-Fi system (amplifier) or using this input to make recording in mono from audio program. Specifications Frequency Coverage: FM 87.50 - 108 MHz 520 - 1710 kHz Power: AC 120 V/60 Hz/25W or AC 230 V/50 Hz/25W Internal Antenna System:...
  • Page 11 Aux in socket: 3.5 mm dia. Stereo jack. Input sensitivity: IN 150mV Output 7W @100Hz Input impedance: 47 Kohm REC OUT: output impedance: 2.2Kohm DC IN: 12V/1A center pin positive (operational voltage 9-14V) Accessories: FM F-terminal antenna wire AC Power Cord F to PAL terminal adapter (European version only) Dimension: 240(W) x 114 (H) x 169.5 (D) mm Weight: 2.35 KG.
