USB cable
Use this cable to connect the OCTA-CAPTURE to the USB connector of your computer.
* Please use only the included USB cable . If you require a replacement due to loss or damage,
please contact the nearest Roland Service Center, or an authorized Roland distributor, as listed
on the separate sheet titled "Information . "
License agreement
This is a license agreement allowing you to use certain software that is copyrighted by Roland
Corporation.
You must read this before opening the envelope containing the included CD-ROM.

Rack mount angle

If you want to install the OCTA-CAPTURE in an
19-inch rack, please use the included rack mount
adaptors.
1. Remove the silver-colored screws from the
left and right sides of the OCTA-CAPTURE
(three screws on each side) .
2. Fasten the rack mount adaptors to the OCTA-CAPTURE using the screws you removed
in step 1 .
Be sure to attach the rack mount adaptors using the screws you removed.
3. Remove the four rubber feet from the bottom of the OCTA-CAPTURE .
You'll need to provide the following items
The external amplifier, speakers, or headphones that you'll need in order to listen to sounds
that are output via the OCTA-CAPTURE are not included. Nor is there included a microphone
for connection to the OCTA-CAPTURE to input audio. You'll need to obtain these items
separately.
You can use an MD or DAT digital recorder to record digital audio, but a cable for connecting
your digital device to the OCTA-CAPTURE is not included. You'll need to obtain this separately.
Rack mount angle
