SPECIFICATIONS AND OPTIONS

I Specifications
• GENERAL
• Frequency coverage
Transmit
Receive
* Frequency range that may be subject to licensing conditions.
• Mode
• Channel spacing
• Current drain (at 13.8 V)
• Power supply requirement
• Frequency stability
• Dimensions
(Projection not included)
• Weight
• TRANSMITTER
• Output power
• Modulation system
• Max. frequency deviation
• Spurious emissions
• RECEIVER
• Receive system
• Sensitivity (20 dB SINAD)
• Squelch sensitivity
• Intermodulation rejection ratio : More than 68 dB
• Spurious response rejection ratio: More than 70 dB
• Adjacent channel selectivity : More than 70 dB
• Audio output power
24
:
156.025–157.425 MHz
(156.00–161.450MHz)*
156.025–162.025 MHz
(156.00–163.425MHz)*
: FM (16K0G3E)/DSC (16K0G2B)
: 25 kHz
: TX high 6.0 A max.
Max. audio 1.2 A max.
: 13.8 V DC
: ±1.5 kHz (–20°C to +60°C)
: 153(W) × 67(H) × 141.6(D) mm
: 900 g
: 25 W and 1 W
: Variable reactance phase modulation
: ±5.0 kHz
: Less than 0.25 µW
: Double conversion superheterodyne
: Less than –2 dBµ EMF (typical)
: Less than 0 dBµ EMF
: 2 W at 10% distortion with a 4 Ω load

I Options

• DS-100 (#02) DSC CONTROLLER
When the DS-100 (#02) is installed, the transceiver conforms to DSC
class D for marine digital communications.
• MB-69 FLUSH MOUNT
For mounting the transceiver to a panel.
• SP-5 EXTERNAL SPEAKER
A large, external speaker for superior audio output.
• SP-10 EXTERNAL SPEAKER
A compact, external speaker for easy installation.
All stated specifications are subject to change without notice or
obligation.
