Grizzly H7827 Instructions

Damage to your eyes, lungs, and ears could
result from using a drill press without
protective gear, such as safety glasses,
a respirator, and

Specifications

•
Size . . ....................... .23
•
Aluminum.Insert.T-Slots
•
Wooden.T-Slots ............................................ 1
•
Weight . . .............................................. 10
•
Construction .............. Melamine-Coated.MDF
•
Color ...................................................... White
Inventory
(Refer to Figures 1 & 2)
•. Table . . ........................................................... 1
•
Fence . . .......................................................... 1
•
Fence.Stop ................................................... 1
•
Knobs ........................................................... 5
•
Clamp.Assemblies
Installation
1.
File.down.any.nicks.or.burrs.in.the.drill.press.
table,.clean.the.surface.and.wipe.a.light.coat.
of.machine.oil.on.the.table.to.prevent.rust.if.
any.condensation.should.occur.
2. Place. the. Model. H7827. table. onto. the. drill.
press. table,. align. the. clamps. as. shown. in.
Figure 2,.and.snug.the.clamps.in.place.
WARNINg: NO PORTION OF THIS MANUAL MAy BE REPRODUCED IN ANy SHAPE
OR FORM WITHOUT THE WRITTEN APPROvAL OF gRIzzLy INDUSTRIAL, INC.
hearing protection.
⁄ ".W.x.11 ⁄ ".D.x.3".T
3 7
4 8
............................... 2
1
. . ...................................... 2
CoPyrIgHT.©.MAy,.2009.By.grIzzly.InDuSTrIAl,.InC.
.#Cr11853..PrInTeD.In.CHInA.
MODEL H7827 DRILL
optional
Mortising
Attachment
Figure 1.
press.table.and.optional.mortising.attachment.
⁄ .lbs.
2
Qty
Clamp.Assembly
If you need help with your new item, call our Tech
Support at: (570) 546-9663.
PRESS TABLE
INSTRUCTIONS
Drill.press.fitted.with.Model.H7827.drill.
Installed.table.
Figure 2.
Fence.Stop
Knob
Fence
Table
