Stand Height and Angle Adjustments

The Remote Stand features 2 height and 1 angle adjustments, allowing
comfortable positioning of the Remote worksurface.
1) The upper section of the Remote has six inches of vertical adjustment. This
2) The angle of the Remote head is adjustable through a sweep of 10%, down
3) The monitor shelf Is designed to carry a 15" TFT style video monitor. The
Remote Manual
places the worksurface from 30.7" to 36.7" above ground.
Loosen the lever on the side of the Remote pillar to raise or lower the
entire upper section. Pneumatic assist is provided to ease the raising
of the upper section.
Tighten the lever to keep this height adjustment.
from horizontal.
Loosen the lever at the top of the Remote pillar to adjust the angle of
the Remote head.
Tighten the lever to keep this angle adjustment.
shelf is attached to the back of the Remote pillar on a mounting bracket with
two screws. Six screw holes are provided, allowing for 4 mounting positions
in a range of 3" vertical.
Use the included Velcro strips to attach the monitor to the monitor
shelf.
10"
2
1
Page 13
Monitor Shelf
3
Angle Adjustment
Lever
6" Adjustable
Height
