User Reference
RS-422 to RS-232 Converter
RS-232
K422-99
K
SYSTEMS
RS-422
Remote Manual
Connect directly to the
Pilot Computer port
labeled "Remote".
(If KVM Extender is installed, this
converter must be moved to the
port marked "|O|O|" on the KVM
Receiver)
Connect to the provided
RS-422 cable from the
Remote.
Page 10
©1999 Euphonix, Inc.
