KVM Extender Hookup Diagram
Pilot Computer
Adapter
RS-422 to RS-
232 Converter
To Remote
Remote Manual
Molded Assy
MOUSE
KAT-6
Receiver
(in Remote Wire Tray)
|O|O|
To Keyboard
To Trackball
All cables routed through
Stand pillar
Transmitter
|O|O|
Input
REMOTE
MOUSE
SCSI
USB
KBD
KEYBOARD
Remote Extender Wire
Tray (in Stand base)
Remote In
Extende
AC In
r
Remote I/O
Connected internally
in Wire Tray
To Video Monitor
Page 12
Remote I/O
5 pin Kybd
Conn (not
used)
TFT
Netwk1
Netwk2
KAT-6
Adapter
©1999 Euphonix, Inc.
CAT 5
cable
