- Page 1 Elo TouchSystems 2243L, 2244L Touchmonitor User Manual User Manual – 2243L, 2244L SW601560 Rev C Page 1 of 20...
- Page 2 Copyright © 2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company. All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Tyco Electronics.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 - Introduction ................4 Chapter 2 – Installation ................5 Chapter 3 – Mounting ................9 Chapter 4 – Operation ................10 Chapter 5 – Technical Support ............... 14 Chapter 6 – Safety & Maintenance ............ -
Page 4: Chapter 1 - Introduction
Chapter 1 - Introduction Product Description Your new touchmonitor combines Elo TouchSystems’ reliable performance with the latest developments in touch technology and display design. This combination of features creates a natural flow of information between a user and the touchmonitor. This touchmonitor incorporates a 24-bit color, active matrix thin-film-transistor LCD panel to provide high quality display performance. -
Page 5: Chapter 2 -Installation
Chapter 2 –Installation Unpacking the Touchmonitor Open the carton and verify the following items are present: Touchmonitor with protective sheet for its face Elo TouchTools CD & User Manuals CD Quick Install Guide Japanese language regulatory information pamphlet ... - Page 6 Installing the Touch Technology Software Drivers Some software installation is required for your touchmonitor to work with your computer. The drivers for the Windows 7, XP, Vista, WePOS, and 32-bit Server 2003 and 2008 operating systems are provided with your touchmonitor on a CD. Visit the Elo TouchSystems website www.elotouch.com for: ...
- Page 7 For Windows XP, Vista, Server 2003, Server 2008, and WEPOS installations, install the “USB Touchscreen Drivers” when prompted: For Windows 7 installations, check the “Install driver” box under “Elo USB Interfaces – Other Touchscreens” After accepting the end-user license agreement, the drivers will finish installing. Reboot your computer after the install is complete.
-
Page 8: Chapter 3 - Mounting
Chapter 3 – Mounting General Mounting Information The OSD text can be rotated through the OSD menu to better suit your mounting orientation. Side Bracket Mount Threaded holes are provided on the sides of the monitor for mounting using the provided brackets. -
Page 9: Chapter 4 - Operation
Chapter 4 – Operation Power To turn the touchmonitor on or off, press the touchmonitor power button once. The Power Status LED on the OSD controller functions according to the following table: TouchMonitor/Computer Module status LED status SLEEP PULSING The system consumes low power when in SLEEP and OFF modes. For detailed power consumption specifications, refer to technical specifications on the Elo website http://www.elotouch.com Touching the screen will bring the attached host PC out of SLEEP mode (similar to moving the... - Page 10 The APR performance can be customized to better suit your application. Access the “Set APR Preference” window from the Mode tab of the Elo APR driver control panel: Select the usage type best suited for your application, then press Apply. General: No particular optimization (default) Best Signature: APR performance optimized for signature capture applications Point of Sale: APR performance optimized for Point-of-Sale applications...
- Page 11 Video A display’s native resolution is its width and height measured in number of pixels. Generally, for best performance, an image displayed on this monitor will look best when your computer’s output resolution matches this monitor’s native resolution of 1920x1080. For computer output resolutions at non-native resolutions, the monitor will scale the video to its panel’s native resolution.
-
Page 12: Mounting ................................................................................ 9
Moves the image horizontally on the display in single-pixel increments. Default: centered. H-position Only applicable for VGA input video Moves the image vertically on the display in single-pixel increments. V-position Default: centered. Only applicable for VGA input video Switches the scaling method between Full Scaling and Maintain Aspect Ratio. Default: Full Scaling Full Scaling –... - Page 13 All touchmonitor adjustments made through the OSD are automatically memorized as soon as they are entered. This feature saves you from having to reset your choices every time the touchmonitor is unplugged or powered off and on. If there is a power failure, the touchmonitor settings will not default to the factory specifications.
-
Page 14: Chapter 5 - Technical Support
Chapter 5 – Technical Support If you are experiencing trouble with your touchmonitor, refer to the following suggestions. If the problem persists, please contact your local dealer or contact Elo TouchSystems Customer Service. Solutions to Common Problems Problem Suggested Troubleshooting The touchmonitor does not respond when Check that the power cables are correctly attached. -
Page 15: Chapter 6 - Safety & Maintenance
Chapter 6 - Safety & Maintenance Safety To avoid risk of electric shock, follow all safety notices and do not disassemble the touchmonitor. They are not user-serviceable. The slots located on the sides and top of the touchmonitor case are for ventilation. Do not block or insert anything inside the ventilation slots. -
Page 16: Chapter 7 - Regulatory Information
Chapter 7 – Regulatory Information I. Electrical Safety Information: Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. - Page 17 iii) Reorient the affected receiver’s antenna. iv) Plug the digital device into a different AC outlet so the digital device and the receiver are on different branch circuits. v) Disconnect and remove any I/O cables that the digital device does not use.(Unterminated I/O cables are a potential source of high RF emission levels.) vi) Plug the digital device into only a grounded outlet receptacle.
- Page 18 Explanation of Markings (1). In accordance with the SJ/T11364-2006 requirement, the electronic information products are marked with the following pollution control logo. The Environment-Friendly Use Period for this product is 10 years. The product will not leak or mutate under normal operating conditions listed below, so that the use of this electronic information product will not result in any severe environmental pollution, any bodily injury, or damage to any assets.
-
Page 19: Chapter 8 - Warranty Information
Chapter 8 – Warranty Information Except as otherwise stated herein, or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the TouchMonitors, Computer Module, and their components is 3 (three) years. Seller makes no warranty regarding the model life of components. -
Page 20: Product Information
Software drivers TouchMonitor Newsletter Getting in Touch with TE Touch Solutions To find out more about the extensive range of Elo touch solutions, visit our website at www.elotouch.com, or simply call the office nearest you: North America Belgium...
