- Page 1 Elo TouchSystems 2240L 22-inch LCD Touchmonitor User Guide...
-
Page 2: User Guide
Elo TouchSystems 2240L 22-inch LCD Touchmonitor User Guide Revision C SW600546 Elo TouchSystems 1-800-ELOTOUCH www.elotouch.com... - Page 3 IntelliTouch, APR (Acoustic Pulse Recognition), Elo TouchSystems, TE Logo, and Tyco Electronics are trademarks. Other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Elo TouchSystems claims no interest in trade- marks other than its own. Elo TouchSystems 2240L User Guide...
-
Page 4: Table Of Contents
Care and Handling of Your Touchmonitor ............... 28 Warning ..........................29 Waste Electrical and Electronic Equipment (WEEE) Directive ........29 Appendix B: Technical Specifi cations ..........30 2240L Specifi cations ......................31 Regulatory Information ....................33 Warranty ........................... 37 Elo TouchSystems 2240L User Guide... -
Page 5: Chapter 1: Introduction
See Appendix A (page 27) for information on touchmoni- tor safety. Before setting up and turning on your touchmonitor, read through this manual, especially Chapter 2 (Installation and Setup), and Chapter 3 (Operation). Elo TouchSystems 2240L User Guide... -
Page 6: Chapter 2: Installation And Setup
C H A P T E R INSTALLATION AND SETUP This chapter discusses how to install and set up the LCD touchmonitor and how to install Elo TouchSystems driver software. Elo TouchSystems 2240L User Guide... -
Page 7: Unpacking Your Touchmonitor
DVI-D Cable Power Cable (appearance of cable (not included with differs according to some European or region) Asian models) OSD Remote Control Box Mounting Brackets TouchTools CD and Quick Accessory (optional) (quantity: four) Install Guide Elo TouchSystems 2240L User Guide... -
Page 8: Connecting The Cables To The Touchmonitor And Computer
Connect the other end to your computer. Connect one end of the OSD remote control box connector to the rear panel of the monitor and the other end to your computer. Press the power button to turn the monitor on. Elo TouchSystems 2240L User Guide... -
Page 9: Installing The Touch Driver
TouchTools or APR CD: Click Start > Run. Click the Browse button to locate the EloCd.exe program on the CD-ROM. Click Open, then OK to run EloCd.exe. Follow the directions on the screen to complete the driver installation. Elo TouchSystems 2240L User Guide... -
Page 10: Monitor Overview And Dimensions
Monitor Overview and Dimensions (IntelliTouch Model) Note: Detailed mechanical illustrations can be found at: www.elotouch.com Elo TouchSystems 2240L User Guide... - Page 11 Monitor Overview and Dimensions (Surface Capacitive Model) Elo TouchSystems 2240L User Guide...
-
Page 12: Monitor Mounting And Orientation
Alternatively, the monitor may be mounted in the portrait orientation. For this orientation, the cable connection panel may be on either side, as shown in the illustrations below. Rear View of Monitor—Portrait Orientation Cable Connection Elo TouchSystems 2240L User Guide... - Page 13 Monitor Mounting and Orientation (continued) Landscape Orientation Angle Views The mounting orientation can be up to a 90° angle from vertical, as shown in the illustrations below. Elo TouchSystems 2240L User Guide...
- Page 14 Monitor Mounting and Orientation (continued) Portrait Orientation Angle Views The mounting orientation can be up to a 90° angle from vertical, as shown in the illustrations below. Elo TouchSystems 2240L User Guide...
- Page 15 Monitor Mounting and Orientation (continued) Mounting to 100 mm VESA Mount—Landscape Orientation Requires four (4) M4 thread hole Phillips head attaching screws (8 mm depth) Note: Dimensions are in millimeters. Detailed mechanical illustrations can be found at: www.elotouch.com Elo TouchSystems 2240L User Guide...
- Page 16 Monitor Mounting and Orientation (continued) Mounting to 100 mm VESA Mount—Portrait Orientation Requires four (4) M4 thread hole Phillips head attaching screws (8 mm depth) Note: Dimensions are in millimeters. Detailed mechanical drawings can be found at: www.elotouch.com Elo TouchSystems 2240L User Guide...
-
Page 17: Chapter 3: Operation
LCD damage may result. To enable the touchmonitor, change the computer video mode so it is within the allowable vertical frame rate range shown under “Input Video Range” on page 32. Elo TouchSystems 2240L User Guide... -
Page 18: Rear Panel Control Buttons For On-Screen Display (Osd)
Rear Panel Control Buttons for On-Screen Display (OSD) The rear panel control buttons for on-screen display (OSD) adjust- ments allow you to change settings on the monitor screen. There are fi ve buttons: MENU SEL (select) (power switch) Elo TouchSystems 2240L User Guide... - Page 19 1) Automatically adjusts the image on the screen (this function not available for European models) 2) Selects adjustment choices from the OSD menus Power Switch turns monitor on and off Note: After any values have been adjusted, the monitor automatically saves the changes. Elo TouchSystems 2240L User Guide...
-
Page 20: On-Screen Display (Osd) Remote Control Box Accessory (Optional)
OSD is currently displayed on screen) 2) Increases value of OSD adjustment choice 3) Selects OSD choice counterclockwise MENU Displays/exits the OSD Menus After any values have been adjusted, the monitor automatically saves the changes. Elo TouchSystems 2240L User Guide... - Page 21 2 seconds. A window will appear displaying “Power Unlock.” Continue to hold the buttons down for another 2 seconds and the window toggles to “Power Lock.” NOTE: By default, the OSD screen will disappear if no input activities are detected for 30 seconds. Elo TouchSystems 2240L User Guide...
- Page 22 OSD Timeout • Adjusts amount of time that the OSD menu is displayed. Language • Selects the language used for the OSD menu from English, French, German, Spanish, Italian, Traditional Chinese, Simplifi ed Chinese, or Japanese. Elo TouchSystems 2240L User Guide...
- Page 23 • Restores original factory settings for all other parameters and video inputs, except language (VGA and DVI). Miscellaneous Sharpness • Adjusts sharpness of video. Display Information • Frequency of the input horizontal/vertical synchronizing signal is indicated. Elo TouchSystems 2240L User Guide...
-
Page 24: Preset Display Modes
The touchmonitor comes with preset settings for commonly used video modes. It automatically adjusts the picture size and centering for any of the video modes listed in Appendix B, 2240L Specifi cations (page 31), under “Preset Display Modes.” Elo TouchSystems 2240L User Guide... -
Page 25: Chapter 4: Troubleshooting
See Chapter 3 and Appendix B for more information on allowable video modes. Make sure the USB or serial cable is Touch doesn’t work securely attached at both ends. Elo TouchSystems 2240L User Guide... -
Page 26: Technical Support
Technical Support To contact technical support online, please go to: www.elotouch.com/go/contactsupport To contact technical support by telephone, please call: 1-800-557-1458 Elo TouchSystems 2240L User Guide... -
Page 27: Appendix A: Touchmonitor Safety
Do not block or insert anything inside the ventilation slots. It is important that your touchmonitor remains dry. Do not pour liquid into or onto your touchmonitor. If your touchmonitor be- comes wet do not attempt to repair it yourself. Elo TouchSystems 2240L User Guide... -
Page 28: Care And Handling Of Your Touchmonitor
• Do not wipe the touchscreen with anything abrasive that could scratch the surface. • To clean the touchscreen, use window or glass cleaner. Put the cleaner on a clean, soft cloth and wipe the touchscreen. Never apply the cleaner directly to the touchscreen. Elo TouchSystems 2240L User Guide... -
Page 29: Warning
Waste Electrical and Electronic Equipment (WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste. It should be deposited at an ap- propriate facility to enable recovery and recycling. Elo TouchSystems 2240L User Guide... -
Page 30: Appendix B: Technical Specifi Cations
APPENDIX TECHNICAL SPECIFICATIONS Elo TouchSystems 2240L User Guide... -
Page 31: 2240L Specifi Cations
1440 x 900 @ 60Hz RB and non-RB 1600 x 1200 @60Hz 1680 x 1050 @ 60Hz 1680 x 1050 Native Resolution Contrast Ratio 1000:1 (typical) Brightness No Touch: Typical 270 cd/m IntelliTouch: Typical 270 cd/m APR: Typical 270 cd/m Elo TouchSystems 2240L User Guide... - Page 32 Altitude: 0 to 3,658 m Storage Conditions Temperature: -20°C to 60°C Humidity: 10% to 90% (no condensation) Altitude: 0 to 12,192 m 352 x 530 x 78 mm Dimensions (HxWxD) Weight 8.48 Kg (unpackaged) 12.59 Kg (packaged) Elo TouchSystems 2240L User Guide...
-
Page 33: Regulatory Information
This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accor- dance with the instructions, may cause harmful interference to radio communications. Elo TouchSystems 2240L User Guide... - Page 34 2) If this equipment appears to cause interference with radio or television reception, or any other device: a) Verify as an emission source by turning the equipment off and on. b) If you determine that this equipment is causing the Elo TouchSystems 2240L User Guide...
- Page 35 (Removing or cutting the power cord ground may increase RF emission levels and may also present a lethal shock hazard to the user.) vii) If you need additional help, consult your dealer, manufacturer, or an experi enced radio or televi- sion technician. Elo TouchSystems 2240L User Guide...
- Page 36 The following Certifi cations have been issued for the monitor: • Argentina S-Mark • Australia C-Tick • • China CCC • China RoHS • • IMERC • Japan VCCI • Korea MIC • Mexico NOM • Russia PCT • Taiwan • • • WEEE Elo TouchSystems 2240L User Guide...
-
Page 37: Warranty
Product to conform to the war- ranty set forth above, then Seller shall, at Seller’s option, either refund to Buyer or credit to Buyer’s account the purchase price of the Prod- Elo TouchSystems 2240L User Guide... - Page 38 Products made or authorized by Buyer. Buyer will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses (including reasonable attorney’s fees) attributable to Buyer’s products or representations or warranties con- cerning same. Elo TouchSystems 2240L User Guide...
-
Page 39: Product Information
B-3010 Kessel-Lo Japan Germany Belgium (800) ELO-TOUCH Tel +49 (0)(89) 60822-0 Tel +32(0)(16)35 21 00 Tel +81(45)478-2161 (800) 356-8682 Fax +49(0)(89) 60822-180 Fax +32(0)(16)35 21 01 Fax +81(45)478-2180 Tel 650-361-4800 elosales@elotouch.com elosales@elotouch.com www.tps.co.jp Fax 650-361-4747 eloinfo@elotouch.com Elo TouchSystems 2240L User Guide...
