Coil Elements
• When an element is on, it will cycle on and off to maintain
the heat setting.
° Coil elements are self-cleaning. Do not immerse in water.
TO remove: When cool, raise
element. Carefully pull out and
away from receptacle.
To replace:
Insert element
terminals into receptacle. Guide
the element into place. Press
down on the outer edge of
element until it sits level on drip
bowl.
TERMINALS
Drip Bowls
The drip bowls under each surface element catch boilovers
and must always be used. Absence of drip bowls during
cooking may damage wiring.
To prevent the risk of electric shock or fire, never line drip
bowls with aluminum foil.
Drip bowls will discolor (blue/gold stains) or craze over time if
overheated. This discoloration or crazing is permanent. This
will not affect cooking performance.
Manual Clean Oven Control
(select models)
BAKE
BROIL
TIMER
CLOCK
CANCEL
AorY
Use for baking and roasting.
Use for broiling and top browning.
Sets timer.
Use to set time-of-day clock.
Cancels all operations except timer and dock.
Enters or changes time, oven temperature.
Sets HI or LO broil.
Using the Touchpads
° Press the desired pad.
• Press the A or T pad to enter time or temperature.
• A beep will sound each time a function pad is pressed. There
is no beep for the ,_ or V pad.
• A double beep will sound if a programming error occurs.
Important: Four seconds after pressing the A or V pad, the
time or temperature will automatically be entered. If more than
30 seconds elapse between touching a function pad and the A
or V pad, the function will be canceled and the displaywill return
to the previous display.
Setting the Clock
1. Press the CLOCK pad.
° The clock time cannot be set if the control is
programmed for a bake, broil or timing operation.
2. Set the correct time of day using the A or V pads. If the A
or V pad is not pressed within 30 seconds, the program
will cancel. Press the Clock pad and begin again.
Setting the Timer
The timer can be set from one minute (:01) up to 99 hours
and 59 minutes (99:59). Time will be displayed in minutes and
not in seconds. THE TIMER DOES NOT CONTROL THE
OVEN.
1. Press the TiNiER pad. TIMER
° 0:00 will light and the colon C) will flash in
the display.
2. Press the A or V pad until the desired time is
displayed.
° The timer will begin as soon as the time is set.
• The flashing colon indicates that a timing
operation is in progress. _he colon will not
flash if the time of day or oven temperature is
displayed.)
• Two short beeps signal the end of the operation. %:00"
will appear in the display.
If desired, press the CLOCK pad and the time of day
will briefly reappear in the display during a timing
operation.
If desired, press the BAKE or BROIL pads and the
current temperature setting will briefly reappear in the
display during a timing operation.
To cancel the timer operation:
Press and hold the TINiER pad for several seconds.
11
