PART NO. 103-9724
LOCATION: On PTO Guard
PART NO. 103-8425
LOCATION: - On front console,
Under Seat
- On driveshaft

2. SPECIFICATIONS

2.1 MODEL NUMBER:

2.2 ENGINE:

2.2.1 Engine Specifications: See your Engine Owner's Manual
2.2.2 RPM: Full Speed: 3600 RPM (No Load) Idle: 1500 RPM

2.3 FUEL SYSTEM

2.3.1 Capacity: 7.5 gal (28 L)
2.3.2 Type of Fuel: Regular unleaded gasoline, 87 octane or higher
2.3.3 Fuel Filter: Kohler units: In-line 15 Micron Kohler P/N 2405002.
2.3.4 Fuel Shut-Off Valve: 1/4 turn "in-line" valve by fuel filter.

2.4 ELECTRICAL SYSTEM

2.4.1 Charging System: Flywheel Alternator
2.4.2 Charging Capacity: 15 amps
2.4.3 Battery Type: BCI Group U1
2.4.4 Battery Voltage: 12 Volt
2.4.5 Polarity: Negative Ground
PART NO. 103-9032
LOCATION: On Back of Seat
PART NO. 103-9034
LOCATION: On Rear of LH Drive
NAV20KC, NAV27KC
- 10 -
Wheel Fender
