Specifications
• Mulching Kit: Optional
• Bagger: Optional

Dimensions

Overall Width:
52 inch
Deck
Without 49.0 inches
Deck (124.5 cm)
Deflector 53.3 inches
Up (135.4 cm)
Deflector 64.0 inches
Down (163 cm)
Overall Length:
Without deck and floor
pan folded
52 inch Deck
60 inch Deck
72 inch Deck
Overall Height:
Roll Bar - Up
69.2 inches (175.8 cm)
Tread Width: (Center to Center of
Tires, Widthwise)
52 inch Deck 60 inch Deck
41.4 inches 41.4 inches
(105.2 cm) (105.2 cm)
Wheel Base: (Center of Caster Tire to
Center of Drive Tire)
51.2 inches (130.0 cm)
Minimum Turning Radius
55.25 inches (140.3 cm)
60 inch 72 inch
Deck Deck
49.0 inches 53.0 inches
(124.5 cm) (135 cm)
61.4 inches 73.4 inches
(156 cm) (186 cm)
72.0 inches 84.3 inches
(183 cm) (214 cm)
82.3 inches (209.0 cm)
114.3 inches (290.3 cm)
114.3 inches (290.3 cm)
114.3 inches (290.3 cm)
Roll Bar - Down
50.7 inches (128.8 cm)
72 inch Deck
45.4 inches
(115.3 cm)
Curb Weight:
Without deck
52 inch Deck
60 inch Deck
72 inch Deck

Torque Requirements

Bolt Location
Wheel Lug Nuts
Wheel Motor Mounting
Bolts
Wheel Hub Lock Nut
Rollover Protection System
(Roll Bar) Mounting Bolts
Clutch Retaining Bolt
(secured with threadlocker)
16
1163 lb (528 kg)
1555 lb (705 kg)
1600 lb (726 kg)
1660 lb (753 kg)
Torque
90-95 ft-lb (122-129 N-m)
72-77 ft-lb (98-104 N-m)
210-250 ft-lb
(285-339 N-m)
30-35 ft-lb (41-47 N-m)
55-60 ft-lb (75-81 N-m)
