Exmark FMD524 Setup Instructions

Loose Parts
Use the chart below to verify that all parts have been shipped.
109-8511
Part #
103-1309
109-8510
Part #
—
—
Uncrate the Unit
Remove the mower deck from the crate.
Note: Reference the tractor setup instructions for
components required to complete deck installation.
Installing the Mower Deck to Turf
Tracer Units
1. Locate the drive wheel release valves on the rear
corner of the hydrostatic pumps.
2. With a 5/8 inch wrench, turn both valves one turn
counterclockwise to release the drive system.
3. Roll the tractor to the mower deck assembly and
allow the tractor assembly to tip backward until the
rear of the engine deck contacts the ground.
4. Carefully remove the two hairpins and spacers from
the front deck support pins and lower the front of
the deck to the ground.
5. Carefully remove the two hairpins from the rear deck
support pins and lower the rear of the deck to the
ground. See Figure 1.
6. Install the mower deck support frame to tractor
engine deck and secure using eight 3/8-16 x 1 1/4
inch screws, eight spring disc washers and eight
whizlock nuts from bolt bag. See Figure 1.
Note: Place spring disc washer cone side against
bolt head (cupped side away from head) and install
to outside of support frame as shown in Figure 1.
© 1997–2007—Exmark Mfg. Co., Inc.
P.O. Box 808
Beatrice, NE 68310
Dealer Pack
Description
Warranty Registration Form
Literature Pack
Description
Manual, Operator's
Manual, Parts
FMD524/FMD604
Qty.
1 Fill out warranty registration form.
Qty.
1
Read before operating the machine.
1
Install with whizlock nuts to the inside of engine
deck. Tighten until spring washers are flat.
7. Position tractor with mower deck support frame in
place, over the mower deck.
When mower deck is not installed or the two
front support rod hairpins are removed from
the mower deck, the unbalanced weight of the
tractor or tractor with mounted mower deck
support frame may cause the front of the unit to
rise suddenly. If the unit rises suddenly, injury
may occur.
Securely hold down the front end of the unit
when the mower deck is not installed or the
support rod hairpins are removed.
8. Align and re-install the mower deck support pins
into the support frame. Install the two spacers and
hairpins onto the front support pins and the two
hairpins and spacers onto the rear support pins. See
Figure 1.
Setup Instructions
For Serial Nos. 720,000 & Higher
Use
Use
Caution
Part No. 4500-177 Rev. A
Printed in the USA.
All Rights Reserved
