Specifications; Power Consumption; Low Battery Warning - Excell DIGITAL HIGH PRECISION WEIGHING SCALES User Instructions

EXCELL PRECISION CO., LTD.

2. SPECIFICATIONS

The available capacities for selection are different and depend on various models:
Capacity
3 kg (6 lb)
6 kg (12 lb)
7.5 kg (15 lb)
15 kg (30 lb)
30 kg (60 lb)
75 kg (60 lb)
150 kg (150 lb)
300 kg (600 lb)
600 kg (1200 lb)
Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F)
Power Source: AC 110V/220V (±10%) + DC 6V/4.5AH Rechargeable Battery
Display: LCD, 6 digits, 25 mm (Height), EL backlight

3. POWER CONSUMPTION

1. The power consumption is around DC 20 mA (system + load cell), the rechargeable battery
can be used up to 200 hours.
2. The power consumption is around DC 67 mA (system + load cell + backlight), the
rechargeable battery can be used for 60 hours approximately.
3. The power consumption is around DC 71 mA (system + load cell + backlight + RS-232), the
rechargeable battery can only be used for 56 hours approximately.

4. LOW BATTERY WARNING

Please note when the
recharged.
v The scale will power off automatically without recharging after the low battery symbol
shows upon for 20 to 30 hours (3 to 5 hours if the backlight is active) on the display. As a
recommendation, the scale must be fully recharged before operating the scale again.
V1.0
symbol is shown on the display, the internal battery needs to be
5
Division
0.2 g (0.0005 lb)
0.2 g (0.0005 lb)
0.5 g (0.001 lb)
1 g (0.002 lb)
2 g (0.005 lb)
5 g (0.01 lb)
10 g (0.02 lb)
20 g (0.05 lb)
50 g (0.1 lb)
OIML: -10°C ~ 40°C (14°F ~ 104°F)
SM2020010426
