Check-Weighing Configuration - Excell DIGITAL HIGH PRECISION WEIGHING SCALES User Instructions

EXCELL PRECISION CO., LTD.

1. CHECK-WEIGHING CONFIGURATION

F8 (Hold) affects access to F4. If F8 is set, access to F4 is denied.
^ /
Press the
ACTION
Press the key to enter the
check weighing configuration
Press the key to enter the
low limit value. Press the
key to confirm the setting
Set the "High limit value"
Press key to enter the high
limit value. Press the
confirm the setting
Set the "buzzer" operation
Press the key to set the
buzzer. Press the
confirm the setting
The scale returns to the
weighing mode.
︿ key = Upward key (0~9 digit entry)
key = Confirmation key
(move the cursor one step to the right)
V1.0
or key to select the F4 function
T
6
STABLE
6
STABLE
6
STABLE
key to
6
STABLE
6
STABLE
key to
6
STABLE
DISPLAY
Press the
kg
for 5 times to clear
.
the configuration
settings
kg
.
kg
.
kg
.
kg
kg
16
the display shows
DESCRIPTION
key
6
STABLE
Press the key
Buzzer Setting
A
A 0 = When the weight is stable
the buzzer sounds and the High,
OK or Low icon is displayed.
1 =. The High, OK or Low icon
is displayed irrespective of the
stability of the weight. The
buzzer sounds only when the
weight is stable.
2 = The buzzer sounds and the
High, OK or Low icon is
displayed irrespective of the
stability of the weight.
B 0 = The buzzer does not sound.
1 = The buzzer sounds at the
OK status.
2 = The buzzer sounds when
the weight of the object is lower
or equal to the low limit value,
or higher than the high limit
value.
SM2020010426
.
kg
