FREEZER CO PAR E T
WIRE SHELVES
TO REHOVEWIRE SHELVES:
° Completely unload the shelf or remove
basket.
" Lift up the rear of the shelf slightly.
° Pull the shelf straight out.
TO LOCKTHE SHELF INTO
ANOTHER POSITION:
• Tilt up the front edge of the shelf.
° Lift up the rear of the shelf.
° Insert the hooks into the desired frame
openings.
° Let the shelf settle into place.
Be sure the shdf is levd and securdy
locked at the rear before reloading it with
food.
FREEZER J: LEVATOR TM
SHELf
This shelf can be
adjusted up or
down without
being unloaded.
To adjust the
height, pull out
the knob on the handle built into the shelf
front. Turn the handle clockwise to raise
the shelf and counterdod<wise to lower
the height of the shelf.
TO REHOVE SHELF:
° Completely unload the shelf.
° Slide the sheff out until it stops.
° Push up the tabs under the outside
edges of the shelf behind the bracket
and continue pulling the shelf out, clear
of the frame.
TO REINSTALL SHELF:
• Align the shelf into the guides on the
frame,
° Pushthe shelf all the way back.(It is not
necessary to push up the tabs for rein-
stallation).
in ordinary use,the Elevator
TM
shelf frame
assembly does NOT require removal.
In the unlikely event that the assembly
needsremoval,it is important to follow the
correct removal procedure. See page 7.
WURE FREEZER
To load or
retrieve items
from a freezer
drawer for j
ward.
E
TO REHOVE:
• Pull out the drawer out until it stops.
• Tilt up the front of the basket.
• Lift it completely out.
TO REPLACE:
° Place basket on extended tracks.
• Placetabs on basket sides under tabs on
track. Drawers should sit fiat on track.
° Push drawer all the way in.
ICE DRAWER
(Nonodispenser Models)
The automatic icemaker keeps this
drawer stocked with ice. To retrieve ice,
pu[[ open the drawer.
TO REHOVE:
• Pull out the drawer until it stops.
• Reach into the drawer compartment
and move the wire lever arm on the ice-
maker into the up (OFF) position.
• Lift the front of the drawer up.
° Pull the drawer completely out.
TO REINSTALL:
• Align the drawer sides onto the
matching side rails.
• Reach into the drawer compartment
and move the wire lever arm on the ice-
maker into the down (ON) position.
° Push the drawer in.
10
