Transport GS14
/ / /
B5121G14S2
Revision 1.02
Copyright © TYAN Computer Corporation, 2006. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from TYAN
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following:
TYAN and Transport GS14 (B5121G14S2) are trademarks of TYAN Computer
Corporation.
Intel and combinations thereof are trademarks of Intel Corporation.
Phoenix BIOS is a trademark of Phoenix Technology.
Microsoft and Windows are trademarks of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
ATI, ATI RAGE is a trademark of ATI Technologies Incorporated.
Winbond is a trademark of Winbond Electronics Corporation.
Information contained in this document is furnished by TYAN Computer Corporation
and has been reviewed for accuracy and reliability prior to printing. TYAN assumes no
liability whatsoever, and disclaims any express or implied warranty, relating to sale
and/or use of TYAN products including liability or warranties relating to fitness for a
particular purpose or merchantability. TYAN retains the right to make changes to
product descriptions and/or specifications at any time, without notice. In no event will
TYAN be held liable for any direct or indirect, incidental or consequential damage, loss
of use, loss of data or other malady resulting from errors or inaccuracies of information
contained in this document.
WARNING: This product should be serviced only by qualified service engineers. Do not
remove the chassis cover or attempt to service this product unless you are qualified to do
so. Once the chassis cover is removed there is a risk of electric shock which could lead
to serious injury or death.
1
http://www.TYAN.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TYAN Transport GS14 (B5121G14S2
Summary of Contents for TYAN Transport GS14 (B5121G14S2
- Page 1 Winbond is a trademark of Winbond Electronics Corporation. Information contained in this document is furnished by TYAN Computer Corporation and has been reviewed for accuracy and reliability prior to printing. TYAN assumes no liability whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability.
-
Page 2: Table Of Contents
Making the Connection ..............28 For 32-bit OS................. 31 For 64-bit OS................. 32 Chapter 3 Software Installation ................33 Installation Instructions for Windows..........33 Windows Installation Notes............33 Chipset Driver ................33 VGA Driver ................... 34 Intel Matrix Storage Manager............34 http://www.TYAN.com... - Page 3 Replacing the Fan ................56 Replacing the USB Board.............. 57 Replacing the LCD Module............58 Replacing the Power Supply............59 Replacing the Motherboard ............60 Chapter 7 Appendix....................61 Caution Texts Concerning Lithium Batteries ......... 61 Technical Support................... 62 http://www.TYAN.com...
-
Page 4: Before You Begin
1.2. Slots and openings in the cabinet are provided for ventilation. Do not block or cover these openings. Do not push objects of any kind into cabinet slots or openings. http://www.TYAN.com... -
Page 5: Chapter 1 Introduction
1× LCD module (pre-installed) 1× fan assembly 40*28 mm (pre-installed) 1× USB board (pre-installed) 2× fan assembly 40*56 mm (pre-installed) 1× power supply 1U ATX 300 W (pre-installed) 1× riser board 32-bit / 33 MHz (pre-installed) 1× fan holder (pre-installed) http://www.TYAN.com... - Page 6 1× secondary serial ATA power cable 1× power Y-cable 2× power cord (USA and Germany) 4× rubber feet 1× TYAN driver CD 1× B5121 User’s Manual 1× Rail Kit Inspect all the items. If any item is damaged or missing, notify your dealer immediately.
- Page 7 4) 1 x pair of Ear bracket (Please refer to the above picture for them) 5) 1 x pair of Handle Kit 6) 1 x Packing Kit (Including 1 x Box, 2 x Sponge, 1 x End cap ) 7) 1 x Instruction Sheet http://www.TYAN.com...
-
Page 8: Specifications
NOS (Network O/S) Support • • FCC Class A Windows 2003 Server 64-bit and 32-bit • • CE (Declaration of Conformity) Windows XP • • UL/cUL Linux RHEL ES 3.0 • • Linux RHEL 4.0 • Fedora Core 3 / Core 4 http://www.TYAN.com... -
Page 9: System View
Hard Disk Drive Indicator Each of the two ports connects a USB device. USB Ports LCD Screen Displays messages and values entered. Allow you to enter network configuration information, reboot the system, Control Buttons and power down the system. http://www.TYAN.com... -
Page 10: Rear View
Connects the LAN cable for internal network connection. Connects a serial device. Serial Port VGA Port Connects an external CRT monitor. Each of the two ports connects a USB device. USB Ports Expansion Slot Allow you to install a PCI card. http://www.TYAN.com... -
Page 11: Chapter 2 Hardware Installation
Cabinet Cover CPU and Heatsink System Assembly Hard Disk Drive DIMM Start Cabinet Rails and Ears Rack Mounting Cabinet into the Rack Locking Tab http://www.TYAN.com... -
Page 12: System Assembly Flowchart
The following flowchart shows the basic procedures of system assembly: START CONNECT HARD DISK DRIVE CABLE AND POWER CORD REMOVE CABINET COVER CHECK IF ALL PARTS ARE PROPERLY CONNECTED INSTALL CPU AND HEATSINK REPLACE CABINET COVER INSTALL SYSTEM MEMORY FINISH INSTALL HARD DISK DRIVE http://www.TYAN.com... -
Page 13: System Assembly
1. Remove two screws from the back of the system. Pull the cover backward to detach 2. To replace the cover, slide the cover forward and replace the two screws. Installing the CPU Your system supports socket-T LGA775 Intel Pentium 4 processor. 1. Remove the cabinet cover (see previous section). http://www.TYAN.com... - Page 14 2. Find the socket-T on the motherboard. 3. Remove the black plastic protective cover on top of the socket-T (keep this for future use in case you will need it). http://www.TYAN.com...
- Page 15 CAUTION: The CPU fits only in one correct orientation. Improper insertion of the CPU into the socket may bend the pins on the socket-T and cause damage to the motherboard. 6. Apply some thermal grease on top of the CPU to aid in heat dissipation. http://www.TYAN.com...
- Page 16 8. Place the heatsink assembly on top of the CPU and align the four points of the heatsink socket. Secure with four screws following a diagonal sequence. CAUTION: The heatsink must be installed, otherwise the CPU and/or motherboard will overheat and be damaged. 9. Replace the cabinet cover. http://www.TYAN.com...
-
Page 17: Installing System Memory
Slots Mode DIMM1 DIMM2 DIMM3 DIMM4 Single Channel Populated Populated Populated Populated Dual Channel Populated Populated Populated Populated Populated Populated Populated Populated Follow this procedure to install a DIMM: 1. Open the cabinet cover (see previous section). http://www.TYAN.com... - Page 18 DIMM into the socket. Finally push the retaining clips inwards to lock the DIMM in place. NOTE: The DIMM modules will fit in only one orientation. Do not touch the memory module’s connectors. Handle only by the edges. WARNING: DIMM modules become extremely hot during operation. 4. Replace the cabinet cover. http://www.TYAN.com...
-
Page 19: Installing A Hard Disk Drive
Operating temperature: must be able to operate in environments up to 55 °C Operating humidity: 10 % to 90 % (non-condensing) IDE and SATA hard disk drives cannot be used in combination for RAID function 1. Remove the cabinet cover (see previous section). http://www.TYAN.com... - Page 20 ( ) , connect the other end to the rear of hard disk drive 2 ( ) (see chapter 5 for adding a second hard disk drive), and insert the data cable into the wire clip ( ) . Connect the single end of the included power Y-cable to the power http://www.TYAN.com...
- Page 21 Serial ATA power cord ( ) , and the other end of the Serial ATA power cord to hard disk drive 2 ( ) . Connect the other dual end of power Y-cable to hard disk drive 1. 6. Replace the cabinet cover. http://www.TYAN.com...
-
Page 22: Adding A Cd Drive
With a Ultra ATA/100 Hard Disk Drive Installed 1. Remove the cabinet cover (see the previous section in this chapter). 2. Unplug the data cable and power cord from the rear of the IDE hard disk drive. http://www.TYAN.com... - Page 23 3. Connect the unplugged data cable ( ) and power cord ( ) to the rear of the CD drive. http://www.TYAN.com...
-
Page 24: Without A Ultra Ata/100 Hard Disk Drive Installed
The ambient temperature around the system (which may be higher than the room temperature) is within the limits specified in section 1.2. There is sufficient airflow around the unit. Electrical circuits are not overloaded. The equipment is properly grounded. Do not place any objects on top of the system. http://www.TYAN.com... -
Page 25: Cabinet Slides And Ears
2. Detach the inner slide from the outer slide by pressing on the release latch ( ) and pulling apart the inner slide from the outer slide ( ) . Do the same for the other slide. http://www.TYAN.com... - Page 26 4. Attach a post slide mount adapter to the front end of the outer slide by securing 2 sets of hex screws and hex nuts together. 5. Attach a post slide mount adapter to the rear end by moving the inner rails to expose the screw holes. Do the same for the other outer slide. http://www.TYAN.com...
-
Page 27: Cabinet Into The Rack
Locking Tab To prevent the system chassis from sliding on its rails, secure the system cabinet to the rack with a screw on each of the mounting ears ( ) (optional – refer to the figure above). http://www.TYAN.com... -
Page 28: Setting Up The System
2. Connect one end of a Category 5 Ethernet cable to the LAN2 connector on the system and the other end to the network socket that connects to the clients. http://www.TYAN.com... - Page 29 7. Press the power button to turn on the system. The hard disk drive spins up, the fan turns on, and the LCD screen lights up. A number of status messages are displayed on the screen during the boot process. CAUTION: It is important to follow the proper power-down procedure for turning off the system. http://www.TYAN.com...
-
Page 31: For 32-Bit Os
OS default None SuSE Linux None OS default OS default OS default None None Enterprise Server 9 FreeBSD 5.4 None OS default None OS default None None Debian Linux 3.1 None OS default OS default OS default None None http://www.TYAN.com... -
Page 32: For 64-Bit Os
NOTE: The driver CD may have been updated after this User’s Manual was completed. If your CD is different from that described in this chapter, refer to the README files on the CD. These files contain the latest information from the software supplier. http://www.TYAN.com... -
Page 33: Chapter 3 Software Installation
2. Run the infinst_auto.exe program in the \Drivers\Intel ICH6R Chipset\ directory. 3. Follow the onscreen instructions to complete the installation. 4. When finished installing, choose the “Yes” option to reboot and click “Finish” to restart your system. The driver should now be loaded. http://www.TYAN.com... -
Page 34: Vga Driver
2. Run the Autorun.exe program in the \Drivers\NIC\Intel_82562GT\ directory. 3. Follow the onscreen instructions to complete the installation. 4. When finished installing, choose the “Yes” option to reboot and click “Finish” to restart your system. The driver should now be loaded. http://www.TYAN.com... -
Page 35: Broadcom 5721 Lan Driver
Point the folder to \Drivers\LCD\Windows\driver\ LCDDriverchecked.inf and confirm to install this driver. 3. Run the Install.bat program in the \Drivers\LCD\Windows\Service\ directory. 4. Restart your system, the driver should now be loaded. For more details, refer to the documents in the \Drivers\LCD\Windows\ directory. http://www.TYAN.com... -
Page 36: Installation Instructions For Linux (Redhat/Fedora/Suse)
/tmp, including the folder dripkg. 6. Change to the driver src directory: cd e1000-5.2.16/src/. 7. Type cd dripkg. 8. Type ./install.sh. 9. Type startx. 10. Click on Start Main Menu–>System Settings–>Display–>Advanced–>Video Card Configure–>Select “Intel 810”. The driver should now be loaded. http://www.TYAN.com... -
Page 37: Intel 82562Gt Nic (Network Interface Card) Driver
For more details, refer to the documents in the \Drivers\LCD\Linux\ directory. Installation Instructions for FreeBSD 5.4 Intel 82562GT NIC (Network Interface Card) Driver The default operating system NIC driver can be used. Broadcom 5721 Driver Broadcom 5721 does not support FreeBSD. http://www.TYAN.com... -
Page 39: Chapter 4 Bios Setup
The prompt shows up on the screen for only a few seconds. You must press F2 quickly. Use the keyboard to move around and make selections. Keyboard information can be found at the bottom of the screen. A brief description of keyboard usage is listed next: http://www.TYAN.com... -
Page 40: Main Menu
Installed Memory Shows the total memory on your system. Available to OS Shows the total memory available for use by your OS. Used by Devices Shows the total memory used by your system devices. http://www.TYAN.com... -
Page 41: Advanced Menu
Pre-allocated Memory Size select the amount of pre-allocated graphics memory for use by the internal graphics device. Total Graphics Memory sets the amount of the total pre-allocated graphics memory size. Parallel ATA enables or disables Parallel ATA. Serial ATA enables or disables Serial ATA. http://www.TYAN.com... -
Page 42: Security Menu
Virus Check Reminder displays the virus check reminder message during system boot System Backup Reminder displays the system back up reminder message during system boot up. Password on Boot determines if the system will request a password when starting up. http://www.TYAN.com... -
Page 43: Power Menu
Smart mode are reduced noise, reduced wear by increasing the lifetime and reliability of fans, as well as reduced power consumption. Overall, it helps extend the system’s life by minimizing the rate at which the system collects dust. http://www.TYAN.com... -
Page 44: Boot Menu
Exit Discarding Change exits the Setup program without saving any changes. Load Setup Defaults loads the default values for all Setup items. Discard Changes loads previous values for all Setup items. Save Changes saves the changes you have made. http://www.TYAN.com... -
Page 45: Resetting Bios Setup
CAUTION: Jumpers not described in this section are reserved for factory use only. Do not change the default settings. Jumper Definition Setting Description CMOS setting Normal (default) Clear CMOS To clear the RTC and CMOS RAM, set J13 to 2-3 for one second and set it back to 1-2 again. http://www.TYAN.com... -
Page 47: Chapter 5 Expanding The System
Do not attempt to disassemble the system while it is still in the equipment rack. 1. Turn off the power of the system. 2. Disconnect all power cords and cables from the system. 3. Remove two screws from the back of the system. Pull the cover backward to detach http://www.TYAN.com... -
Page 48: Installing An Expansion Card
3. Remove the screw, lift the small retainer, and then the metal slot cover. Keep the cover for future use when you remove the card. Retainer 4. Firmly press the expansion card’s edge connector into the expansion slot and secure the retainer with the screw. 5. Replace the cabinet cover. http://www.TYAN.com... -
Page 49: Adding A Secondary Hard Disk Drive
ATA/100 type) is set to “Slave.” (See the hard disk drive’s document for information.) Please attach the hard bracket to the chassis to prevent enlarging the screw WARNING: holes even if you will not use hard disk drive . 1. Remove the cabinet cover (see the previous section in this chapter). http://www.TYAN.com... - Page 50 2. Locate the bracket for the secondary hard disk drive. Remove the screw from the hard disk drive bracket and detach the bracket from the cabinet. 3. Fit a hard disk drive to the bracket and secure with four screws. http://www.TYAN.com...
- Page 51 HDD power to pin-header cable to the motherboard ( ) and the other end to the hard disk drive ( ) . Connect the included primary IDE data cable to the primary IDE connector on the motherboard ( ) and the other end to the hard disk drive ( ). http://www.TYAN.com...
- Page 52 HDD power to pin-header cable ( ) , insert the power cord into the wire clip ( ) , and connect the other end to the hard disk drive ( ) . 5. Replace the cabinet cover. 6. You can create RAID for the hard disk drives. http://www.TYAN.com...
-
Page 53: Chapter 6 System Parts Replacement
Do not attempt to disassemble the system while it is still in the equipment rack. 1. Turn off the power of the system. 2. Disconnect all power cords and cables from the system. 3. Remove two screws from the back of the system. Pull the cover backward to detach http://www.TYAN.com... -
Page 54: Removing The Front Bezel
( ) , and then lift up the top left latch ( ) . The leftmost side latch ( ) should detach easily. Then remove the front bezel. Reverse the above sequence when re-attaching the front bezel to prevent any of the latches from breaking. http://www.TYAN.com... -
Page 55: Replacing The Button Board
3. Remove the two screws securing the button board to the system chassis and unplug the button board to pin-header cable from the connector on the motherboard to detach the button board. Reverse the above sequence when installing the new button board. http://www.TYAN.com... -
Page 56: Replacing The Fan
Remove the fan (both single and dual fan) from the holder by prying open both sides of the holder and pushing from below to allow the fan to slide out. Reverse the above sequence when installing the new fan. http://www.TYAN.com... -
Page 57: Replacing The Usb Board
3. Remove the two screws securing the USB board to the system chassis and detach the USB board to pin-header cable from the connector on the motherboard. Then remove the USB board. Reverse the above sequence when installing the new USB board. http://www.TYAN.com... -
Page 58: Replacing The Lcd Module
3. Remove the three screws securing the LCD module to the system chassis and detach the LCD module to pin-header cable from the connector on the motherboard. Then remove the LCD module. Reverse the above sequence when installing the new LCD module. http://www.TYAN.com... -
Page 59: Replacing The Power Supply
20-pin connector from the ATX connector on the motherboard. Then, remove the two screws. 4. Remove the two screws securing the power supply to the system’s rear panel then remove the power supply. Reverse the above sequence when installing the new power supply. http://www.TYAN.com... -
Page 60: Replacing The Motherboard
8. Remove the four hex screws on the serial and VGA ports on the rear panel. 9. Remove the seven screws securing the motherboard to the system chassis. Then remove the motherboard. Reverse the above sequence when installing the new motherboard. http://www.TYAN.com... -
Page 61: Chapter 7 Appendix
Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers. http://www.TYAN.com... - Page 62 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. http://www.TYAN.com...
-
Page 63: Technical Support
Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed pre-paid. TYAN will pay to have the board shipped back to you. Document #: D1766-100...
