Transport GS12
/ / /
B5103G12S2
Revision 1.00
Copyright © TYAN Computer Corporation, 2004. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from TYAN
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following:
TYAN, Transport GS12 B5103G12S2 are trademarks of TYAN Computer Corporation.
Intel, Xeon, and combinations thereof are trademarks of Intel Corporation.
Phoenix BIOS are trademarks of Phoenix Technology.
Microsoft, Windows are trademarks of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
Promise is a trademark of Promise Technology.
ATI, ATI RAGE is a trademark of ATI Technologies Incorporated.
Winbond is a trademark of Winbond Electronics Corporation.
Portable Document Format (PDF) is a trademark of Adobe Corporation.
Information contained in this document is furnished by TYAN Computer Corporation
and has been reviewed for accuracy and reliability prior to printing. TYAN assumes no
liability whatsoever, and disclaims any express or implied warranty, relating to sale
and/or use of TYAN products including liability or warranties relating to fitness for a
particular purpose or merchantability. TYAN retains the right to make changes to
product descriptions and/or specifications at any time, without notice. In no event will
TYAN be held liable for any direct or indirect, incidental or consequential damage, loss
of use, loss of data or other malady resulting from errors or inaccuracies of information
contained in this document.
1
http://www.TYAN.com
Advertisement
Table of Contents
Related Manuals for TYAN Transport GS12 (B5103G12S2
Summary of Contents for TYAN Transport GS12 (B5103G12S2
- Page 1 Portable Document Format (PDF) is a trademark of Adobe Corporation. Information contained in this document is furnished by TYAN Computer Corporation and has been reviewed for accuracy and reliability prior to printing. TYAN assumes no liability whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability.
-
Page 2: Table Of Contents
2.4 Setting Up the System ..............25 Placing the System................. 25 Making the Connection..............25 Software Installation ..................27 3.1 Installation Instructions for Windows..........29 Windows Installation Notes............29 Chipset Driver................29 VGA Driver ................... 29 LAN Driver..................30 USB v.2.0 Driver ................30 http://www.TYAN.com... - Page 3 Using RAID and ASF 2.0 ................... 57 6.1 About RAID................... 57 6.2 Creating an Array................58 Creating an Array for Performance (RAID 0) ....... 58 Creating a Security Array (RAID 1) ..........61 Creating RAID With an Existing Data Drive ........ 63 http://www.TYAN.com...
- Page 4 8.5 Replacing the USB Board.............. 80 8.6 Replacing the LCD Module ............80 8.7 Replacing the Power Supply............81 8.8 Replacing the Blower ..............82 8.9 Replacing the Motherboard ............82 Appendix ......................85 Caution Text Conserning Lithium Batteries ........85 Technical Support................86 http://www.TYAN.com...
-
Page 5: Before You Begin
1.2. Slots and openings in the cabinet are provided for ventilation. Do not block or cover these openings. Do not push objects of any kind into cabinet slots or openings. http://www.TYAN.com... -
Page 7: Introduction
P/N 411728700106 (pre-installed) 2× fan assembly 40*28 mm 1× USB board P/N 422707400033 (pre-installed) P/N 471172400027 (pre-installed) 1× fan assembly 50*10 mm / blower 1× power supply 1U ATX 300 W P/N 411715600014 (pre-installed) 1× riser board 32-bit / 33 MHz http://www.TYAN.com... -
Page 8: Product Description
2× SATA power cable 4× rubber feet 2× power cord (USA and Germany) 1× TYAN driver CD 1× B5103 User’s Manual Inspect all the items. If any item is damaged or missing, notify your dealer immediately. Keep the shipping carton and packing materials in case you need to ship or store the computer in the future. -
Page 9: Specifications
Weight: 7 kg – 2 x 16 digits – Connected via COM2 Power Supply – Four direction buttons plus one “Select” ATX12V 300W with PFC and one “Cancel” button Regulatory Two USB 2.0 ports FCC Class B CE (Declaration of Conformity) http://www.TYAN.com... -
Page 10: System View
Indicator ‘ Each of the two ports connects a USB device. USB Ports ’ LCD Screen Displays messages and values entered. “ Control Buttons Allow you to enter network configuration information, reboot the system, and power down the system. http://www.TYAN.com... -
Page 11: Rear View
LAN2 Connector ‘ Serial Port Connects a serial device. ’ VGA Port Connects an external CRT monitor. “ USB Ports Each of the two ports connects a USB device. ” Expansion Slot Allow you to install a PCI card. http://www.TYAN.com... -
Page 13: Hardware Installation
Cabinet Cover CPU and Heatsink System Assembly Hard Disk Drive DIMM Start Cabinet Rails and Ears Rack Mounting Cabinet into the Rack Locking Tab http://www.TYAN.com... -
Page 14: System Assembly Flowchart
The following flowchart shows the basic procedures of system assembly: START CONNECT HARD DISK DRIVE CABLE AND POWER CORD REMOVE CABINET COVER CHECK IF ALL PARTS ARE PROPERLY CONNECTED INSTALL CPU AND HEATSINK REPLACE CABINET COVER INSTALL SYSTEM MEMORY FINISH INSTALL HARD DISK DRIVE http://www.TYAN.com... -
Page 15: System Assembly
2. To replace the cover, slide the cover forward and replace the two screws. Installing the CPU Your system supports Socket 478 Intel Pentium 4 processor. 1. Remove the cabinet cover (see previous section). 2. Locate the CPU socket. http://www.TYAN.com... - Page 16 You will feel some resistance while doing so. This is normal as the pressure starts to secure the CPU in place. 5. Place the heatsink assembly on top of the CPU and align the four points of the heatsink socket. Secure with four screws following a diagonal sequence. http://www.TYAN.com...
-
Page 17: Installing System Memory
4 GB. You must follow these requirements for the DIMM to be used with the system: Unbuffered DDR-SDRAM (Double Data Rate Synchronous DRAM) with ECC PC2100/PC2700/PC3200-compliant 2.5 V Follow this procedure to install a DIMM: 1. Open the cabinet cover (see previous section). 2. Locate the DIMM sockets. http://www.TYAN.com... -
Page 18: Installing A Hard Disk Drive
1. Remove the cabinet cover (see previous section). 2. Remove the screw from the hard disk drive bracket and detach the bracket from the cabinet. 3. Fit a hard disk drive to the bracket and secure with four screws. http://www.TYAN.com... - Page 19 (•) , connect the corresponding end of the Serial ATA power cord to the other end of the HDD power to pin header cable and the other end to the hard disk drive (Ž) . http://www.TYAN.com...
-
Page 20: Adding A Cd Drive
1. Remove the cabinet cover (see the previous section in this chapter). 2. Unplug the data cable and power cord from the rear of the secondary hard disk drive. 3. Connect the unplugged data cable (Œ) and power cord (•) to the rear of the CD drive. http://www.TYAN.com... -
Page 21: Without A Secondary Ultra Ata/100 Hard Disk Drive Installed
It is compatible with most 19” EIA standard 4 post racks with non-threaded holes. http://www.TYAN.com... -
Page 22: Cabinet Slides And Ears
Do the same for the other side. NOTE: For the correct orientation on mounting the inner slides to the cabinet, refer to the picture above. http://www.TYAN.com... - Page 23 Slide system cabinet Œ with the inner slides previously installed into the inner rails of the outer slides attached to the rack and press on the release latch • until the front panel is aligned with the front edge of the rack. http://www.TYAN.com...
-
Page 24: Cabinet Into The Rack
You can either place the system on a flat surface – a desk or shelf, for example – or install it in a standard 19-inch equipment rack. To place system on a flat surface, attach the rubber feet to the corners in the bottom of the case. http://www.TYAN.com... -
Page 25: Making The Connection
6. Switch on (I) the main power switch on the back of the system. NOTE: After the power switch is switched on for the first time, it can remain in the ON position. For later powering on and off, use the power button on the front of the system. http://www.TYAN.com... - Page 26 7. Press the power button to turn on the system. The hard disk drive spins up, the fan turns on, and the LCD screen lights up. A number of status messages are displayed on the screen during the boot process. CAUTION: It is important to follow the proper power-down procedure for turning off the system. http://www.TYAN.com...
-
Page 27: Software Installation
RedHat Linux 9.0 SuSE Linux 8.1 Not Available Turbo Linux 8 Not Available FreeBSD 4.7 Not Available ü ASF Alert Simulation Windows 2000 ü Windows 2000 SBS ü Windows 2003 ü Windows 2003 SBS ü Windows XP ü RedHat Linux 9.0 http://www.TYAN.com... - Page 28 NOTE: The driver CD may have been updated after this User’ s Manual was completed. If your CD is different from that described in this chapter, refer to the README files on the CD. These files contain the latest information from the software supplier. http://www.TYAN.com...
-
Page 29: Installation Instructions For Windows
When finished installing, choose the “Yes” option to reboot and click “Finish” to restart your system. The driver should now be loaded. VGA Driver NOTE: This driver supports Windows XP only. Insert the driver CD into the CD drive. http://www.TYAN.com... -
Page 30: Lan Driver
Insert the driver CD into the CD drive. Click on Start->Settings->Control Panel->Add/Remove Hardware->Add/Troubleshoot a device->Add a new device->No, I want to select the hardware from a list->System devices-> Click "Have Disk" button->"Browse..." button->point the folder to \LCD\GS12\Windows\driver\LCDDriverchecked.inf and click Open ->OK. http://www.TYAN.com... -
Page 31: Intel Application Accelerator
ASF Alert Simulation and Watchdog Drivers Insert the driver CD into the CD drive. Install ASF Simulation driver by clicking on Start->Settings->Control Panel->Add/ Remove Hardware->Add/Troubleshoot a device->Add a new device->No, I want to select the hardware from a list->System devices. http://www.TYAN.com... -
Page 32: Asf (Alert Standard Format) 2.0 Sdk
Run the alertSDK.msi file in the \ASF\AGENT\ directory. Then, copy the alertapp.exe file in the \ASF\AGENT\SDK\ directory to your Windows’ desktop. For ASF Tools – Run the ASFtools.msi file in the \ASF\AGENT\TOOLS\ directory. For ASF Version – Run the ASFver.msi file in the \ASF\AGENT\TOOLS\ directory. http://www.TYAN.com... -
Page 33: Installation Instructions For Linux (Red Hat/Suse/Turbo Linux)
Proceed with the normal installation of Turbo Linux 8 operating system and after installing, perform the following: Insert the driver CD into the CD drive. Go to /Linux/Turbo8-RPM/ directory. Install the following rpms : rpm -ivh kernel-headers-2.4.18-5.i586.rpm rpm –ivh kernel-source-2.4.18-5.i586.rpm rpm –ivh cpp-2.96-9.i586.rpm rpm –ivh glibc-devel-2.2.5-13.i586.rpm rpm –ivh gcc-2.96-9.i586.rpm. http://www.TYAN.com... -
Page 34: Lan Driver
<IP_address>. To ensure that the NICs function properly when system starts, add the following in the /etc/modules.conf directory: alias eth0 e1000 alias eth1 e1000. http://www.TYAN.com... -
Page 35: Lcd Driver
The ASF Alert Simulation program is required to enable your system to send out a SNMP trap when sensors (temperature, voltage, or fan speed) detect an abnormal condition. Insert the driver CD into the CD drive. Copy asfm-x.x.tar.gz of the /ASF/Linux/ASF_Simulation/ directory to the directory of your choice (where x.x refers to the version). http://www.TYAN.com... -
Page 36: Installation Instructions For Freebsd 4.7
FreeBSD 4.7’s default kernel has no apm function. In order to allow a complete system shutdown, please update the kernel by performing the following steps: cd /usr/src/sys/i386/conf mkdir /root/kernels cp GENERIC /root/kernels/MYKERNEL ln -s /root/kernels/MYKERNEL vi MYKERNEL Locate the line: devices apm0 at *********, change it to devices apm0. http://www.TYAN.com... -
Page 37: Lan Driver
1. Follow steps a and b above to compile and install the module 2. Edit /boot/loader.conf and add the following line: if_em_load=”YES” To compile the driver into the kernel: cd em-x.x.x/src cp if_em* /usr/src/sys/dev/em cp Makefile.kernel /usr/src/sys/modules/em/Makefile Edit the /usr/src/sys/conf/files.i386 file and add the following lines: dev/em/if_em.c optional em http://www.TYAN.com... -
Page 38: Lcd Driver
Copy MiSM_FLCDxx.tar.gz of the /LCD/GS12/FreeBSD/ directory to the directory of your choice (where xx refers to the version). Untar/unzip archive: tar xfvz MiSM_FLCDxx.tar.gz. Change to the driver directory: cd MiSM_FLCDxx. Install the WatchDog driver: make make install. Restart your system. http://www.TYAN.com... -
Page 39: Usb Floppy Drive Usage
Solaris 9 installation kernel. Solaris 9 cannot be installed on a Serial ATA hard disk drive normally. LAN Driver Insert the driver CD into the CD drive. Copy INTCGigaE.pkg of the /LAN/Intel/LINUX/SOLARIS/ directory to the directory of your choice. Install the driver: pkgadd –d INTCGigaE.pkg. http://www.TYAN.com... -
Page 41: Using The Lcd Console
LCD screen. The Left arrow button moves the cursor to the left. The Right arrow button moves the cursor to the right. The Up arrow button increases the digit located at the cursor position. http://www.TYAN.com... -
Page 42: Setting The Configuration For Windows
Reset Admin Upon pressing the Right arrow, the following prompt Password appears, allowing you to reset the administrator Down arrow password: three (3) times Do you want to reset? (default is NULL) Press the Right arrow to reset the password. http://www.TYAN.com... - Page 43 (6) times under HW Monitor Display (down arrow fourth time – see above): Do you want to change? (default is Yes) CPU Temp Local Temperature System Temperature Fan1 Speed Fan2 Speed Fan3 Speed Vcc 2.6V VCCP Vcc 3.3V Vcc 5V http://www.TYAN.com...
- Page 44 Administrative Tools -> Event Viewer -> Application Log when an alert occur NOTE: If you press the C (Cancel) button at any time to cancel the configuration, you must go through the entry process for a particular setting again. http://www.TYAN.com...
-
Page 45: Setting The Configuration For Linux
For SuSE Linux 8.1, go to /etc/lcdscript/passchange Enable SSH Upon pressing the Right arrow, the following prompt Access appears, allowing you to enable SSH access: Down arrow SSH Access On? four (4) times Press S (Select) to enable SSH access. http://www.TYAN.com... - Page 46 Configure eight (8) times under HW Monitor Display (down arrow fifth time – see above): HWM Configure (default is Yes) VCC 2.6V VCCP VCC 3.3V VCC 5V Fan 1 Fan 2 Fan 3 CPU Temp Local Temp Sys Temp http://www.TYAN.com...
- Page 47 Press S (Select) to enable your choice of system alert method. You can check the file /LCD/alert_log_file when an alert occurs. NOTE: If you press the C (Cancel) button at any time to cancel the configuration, you must go through the entry process for a particular setting again. http://www.TYAN.com...
-
Page 48: Setting The Configuration For Freebsd
NOTE: The default root password is password. Enable SSH Upon pressing the Right arrow, the following prompt Access appears, allowing you to enable SSH access: Down arrow SSH Access On? four (4) times Press S (Select) to enable SSH access. http://www.TYAN.com... - Page 49 Upon each succeeding press of the Right arrow, the List following appears. Select which value(s) to display Down arrow Configure eight (8) times under HW Monitor Display (down arrow fifth time – see above): HWM Configure (default is Yes) Temp1 Temp2 Temp3 Rot1 Rot2 Rot3 V3.3 V5.0p http://www.TYAN.com...
- Page 50 Press S (Select) to enable your choice of system alert method. You can check the file /var/log/alert_log_file when an alert occurs. NOTE: If you press the C (Cancel) button at any time to cancel the configuration, you must go through the entry process for a particular setting again. http://www.TYAN.com...
-
Page 51: Bios Setup
A brief description of keyboard usage is listed next: Function Displays help information. Selects a menu title. Moves the highlight up or down among fields. Scrolls forward or backward among the values for the highlighted field. http://www.TYAN.com... -
Page 52: Main Menu
Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on device and the system reconfiguration has caused such a serious conflict of resources that the operating system cannot boot. Large Disk Access Mode Select DOS or Other. http://www.TYAN.com... -
Page 53: Security Menu
Setup program and boot the system while the User can only boot the system. Passwords are not case sensitive. Diskette Access sets the accessibility of the floppy disk drive. Fixed Disk Boot Sector protect the boot sector against any changed. http://www.TYAN.com... -
Page 54: Power Menu
Monitor Menu The following items on your system are monitored: VCC 5 V (Voltage) VCC 2.6 V (Voltage) VCC 3.3 V (Voltage) VCCP (Voltage) Vcore (Voltage) CPU Temperature Local Temperature (monitor chip) System Temperature http://www.TYAN.com... -
Page 55: Boot Menu
Exit Discarding Change exits the Setup program without saving any changes. Load Setup Defaults loads the default values for all Setup items. Discard Changes loads previous values for all Setup items. Save Changes saves the changes you have made. http://www.TYAN.com... -
Page 56: Resetting Bios Setup
CAUTION: Jumpers not described in this section are reserved for factory use only. Do not change the default settings. Jumper Definition Setting Description CMOS setting Normal (default) Clear CMOS To clear the RTC and CMOS RAM, set J2 to 2-3 for one second and set it back to 1-2 again. http://www.TYAN.com... -
Page 57: Using Raid And Asf 2.0
In this type, data are written to two drives. If either drive fails, no data is lost. This type is commonly referred to as mirroring. CAUTION: If creating a Security array using an existing hard drive, back up any necessary data. Failure to follow this could result in data loss. http://www.TYAN.com... -
Page 58: Creating An Array
2. Boot up with Windows 2000 or Windows XP. 3. Run the Intel Application Accelerator program. 4. Create your desired array. See the following subsections for details. Creating an Array for Performance (RAID 0) 1. Select RAID, then Create Volume Manually. http://www.TYAN.com... - Page 59 2. Select RAID 0 under the item Select RAID Level, then click on Next. 3. Click on Yes (Y) to continue. http://www.TYAN.com...
- Page 60 4. Click on Create to create the new RAID volume. 5. Click on OK to finish. http://www.TYAN.com...
-
Page 61: Creating A Security Array (Raid 1)
Creating a Security Array (RAID 1) 1. With the Intel Application Accelerator program running, select RAID, then click on Create Volume Manually. 2. Select RAID 1 under the item Select RAID Level, then click on Next. http://www.TYAN.com... - Page 62 3. Click on Yes (Y) to continue. 4. Click on Yes (Y) to continue. http://www.TYAN.com...
-
Page 63: Creating Raid With An Existing Data Drive
Creating RAID With an Existing Data Drive Use this method if you have a Serial ATA disk drive that already contains data or is the boot device in your system. You will need another Serial ATA disk drive of identical or larger storage capacity. http://www.TYAN.com... - Page 64 1. With the Intel Application Accelerator program running, select RAID, then click on Create Volume from Existing Disk. 2. Select a source disk, then click on Next. Then, follow the steps outlined in the previous sections Creating an Array for Performance (RAID 0) and Creating a Security Array (RAID 1). http://www.TYAN.com...
-
Page 65: About Asf 2.0
Run the setup.exe file in the \ASF\console\proxy\ directory. For Proxy SDK – Run the proxySDK.exe file in the \ASF\console\SDK\ directory. Then, copy the ASFMgmtConsole.exe file located in the \ASF\Console\SDK\ directory to your Windows’ desktop. For ASF Tools – Run the ASFtools.msi file in the \ASF\agent\tools\ directory. http://www.TYAN.com... -
Page 66: Check Agent And Management Console Link
Run the alertAPP.exe file located on the Agent’s system and log in directly without having to type anything, then check that the following configurations are set correctly: Check the option Enable ASF. Select the correct adapter. Enter the correct Management Console’s address. The Alerting Enabled Status indicator should light. http://www.TYAN.com... - Page 67 Run the ASFMgmtConsole.exe file on the Management Console, then check if the data from the Agent is correct. http://www.TYAN.com...
-
Page 68: Obtain Traps And Push Messages
Obtain Traps and Push Messages Run AlertApp to set Heartbeat. Run ASFMgmtConsole to obtain Alert from the Agent. http://www.TYAN.com... -
Page 69: Remote Control
Remote Control To generate Key from Management Console, run ASFMgmtConsole to generate the Administrator Key. Save the Key from Management Console into a floppy disk. Run AlertApp to load the Security Key to the Agent. http://www.TYAN.com... - Page 70 Run AlertApp to select the Remote Control functions supported by the system. Run ASFMgmtConsole to select and execute Remote Control operations (send secured RMCP). http://www.TYAN.com...
-
Page 71: Expanding The System
Do not attempt to disassemble the system while it is still in the equipment rack. 1. Turn off the power of the system. 2. Disconnect all power cords and cables from the system. 3. Remove two screws from the back of the system. Pull the cover backward to detach http://www.TYAN.com... -
Page 72: Installing An Expansion Card
3. Remove the screw, lift the small retainer, and then the metal slot cover. Keep the cover for future use when you remove the card. Retainer 4. Firmly press the expansion card’s edge connector into the expansion slot and secure the retainer with the screw. http://www.TYAN.com... -
Page 73: Adding A Secondary Hard Disk Drive
1. Remove the cabinet cover (see the previous section in this chapter). 2. Locate the bracket for the secondary hard disk drive, next to the power supply. Remove the screw and slide the bracket off the metal tabs to detach it. http://www.TYAN.com... - Page 74 Serial ATA connector and the other end to the rear of the hard disk drive (Œ). Connect the corresponding end of the included Serial ATA power cord to the end of the existing power cord (•) and the other end to the hard disk drive (Ž). http://www.TYAN.com...
- Page 75 6. You can create RAID for the hard disk drives (see Chapter 6 for information). http://www.TYAN.com...
-
Page 77: System Parts Replacement
Do not attempt to disassemble the system while it is still in the equipment rack. 1. Turn off the power of the system. 2. Disconnect all power cords and cables from the system. 3. Remove two screws from the back of the system. Pull the cover backward to detach http://www.TYAN.com... -
Page 78: Removing The Front Bezel
2. Remove the front bezel (see the previous section in this chapter). 3. Remove the two screws securing the button board to the system chassis and detach the button board to pin-header cable from the connector on the motherboard. http://www.TYAN.com... -
Page 79: Replacing The Fan
Remove the heatsink screws following a diagonal sequence to detach the heatsink. Remove either side’s fan cable connector. Then remove the three screws securing each fan to the system chassis. Reverse the above sequence when installing the new fan. http://www.TYAN.com... -
Page 80: Replacing The Usb Board
3. Remove the secondary hard disk drive (see chapter 7 on Adding a Secondary Hard Disk Drive). 4. Remove the three screws securing the LCD module to the system chassis and detach the LCD module to pin-header cable from the connector on the motherboard. http://www.TYAN.com... -
Page 81: Replacing The Power Supply
3. Detach the 4-pin 12 V plug from the ATX 12 V connector on the motherboard as well as the 20-pin connector from the ATX connector on the motherboard. Then, remove the two screws. 4. Remove the two screws securing the power supply to the system’s rear panel. http://www.TYAN.com... -
Page 82: Replacing The Blower
2. Remove the primary hard disk drive (see chapter 2 on Installing a Hard Disk Drive). 3. Remove the secondary hard disk drive (see chapter 7 on Adding a Secondary Hard Disk Drive). 4. Remove the power supply (see the previous section in this chapter). http://www.TYAN.com... - Page 83 7. Detach the riser card from the PCI slot on the motherboard. 8. Remove the four hex screws on the serial and VGA ports on the rear panel. 9. Remove the eight screws securing the motherboard to the system chassis. Reverse the above sequence when installing the new motherboard. http://www.TYAN.com...
-
Page 85: Appendix
Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers. http://www.TYAN.com... -
Page 86: Technical Support
Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the system shipped back to you. http://www.TYAN.com... - Page 87 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D1582-100 http://www.TYAN.com...
