Prepare the Handheld Transmitter

Step
1
Charge the Handheld Transmitter
1. Lift the rubber dust cover protecting the Handheld
Transmitter Charging Jack.
2. Connect one of the charger connectors to the
Handheld Transmitter Charging Jack (1A).
3. Plug the charger into a standard wall outlet. The
Red LED will light up. When fully charged, the
LED will change to Green.
4. When charging is complete, be sure to replace
the rubber dust cover.
Note: Approximate battery life between charges is
40 to 60 hours, depending on frequency of use.
The Transmitter has two LED's used to indicate
the selected dog. The Dog 1 Red LED is on the
left when holding the unit with the LED's facing the
operator, and the Dog 2 Green LED is on the right.
The transmitter is factory set in single dog mode. To verify, press and release the Dog
Select Button multiple times. (The Red LED will blink once for each press and release.)
Transmitter Indicators
Condition
Normal Operation
Low Battery - press and release any
blue correction button
Dog 1—any blue correction button
Charging
Condition
Normal Operation
Dog 2—any blue correction button
Charging Complete

Operating Guide

www.petsafe.net
1A
Red LED
OFF
3 flashes every 5 seconds
ON length of any blue correction button
press. If a Static Stimulation button
is held up to 12 continuous seconds,
then a rapid flash will indicate a safety
time-out.
ON
Green LED
OFF
ON length of any blue correction button
press. If a Static Stimulation button
is held up to 12 continuous seconds,
then a rapid flash will indicate a safety
time-out.
ON
