Summary of Contents for Frigidaire REG94BL
- Page 2 CONTENTS Before using the oven BUILT-IN OVEN Important safeguards Record in the space provided below the Model No. and Serial Energy-saving ideas No. of this appliance. These numbers are found on the serial General operating instructions plate located inside the oven door along the lower left corner Using the oven 8-13...
-
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS Be safety conscious. The preparation of food in an oven or on a range requires temperatures that could cause severe burns. Before using this new appliance, carefully read and follow the safety instructions below. Destroy the carton and plastic bags after the oven is °... - Page 4 IMPORTANT SAFEGUARDS (continued) 10. Keep the oven vent unobstructed. It is located on the top of the control panel trim. Touching the surfaces in this area when the oven is being operated may cause severe burns. 11. Clean the oven regularly to keep all parts free of grease which couM catch fire.
- Page 5 DONOT 10. Do not dean the door gasket. The door gasket is essential for a good seal. Care shonld be taken not to rub, damage or move the gasket. 11. Do not use oven cleaners. No commercial oven cleaner or oven liner protective coating of any kind should be used in or around any part of a self-clean oven.
-
Page 6: General Operating Instructions
GENERAL O PERATING INSTRUCTIONS OVEN The solid state touch panel provides precise control of all oven functions plus a lighted display window. READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various functions of the oven as described below, the location of the touch pads/controls on the control panel, and the in-... - Page 7 SET KNOB--Used along with the function pads to select oven temperature, cooking time, stop time (when program- ming an automatic stop time), time of day, clean time and the minute timer. After touching one of the function pads, turn the knob in a clockwise direction until the desired time or temperature appears in the display.
-
Page 8: Using The Oven
USING THEOVEN SETTING OVEN Before using the oven, arrange the oven rack(s) according CONTROLS the food being cooked. See "Arranging Oven Racks" under Oven Cooking. SETTING THECLOCK The time of day clock operates even when the oven is not in use. - Page 9 When setting the minute the time will appear in the timer for: display and increase one second to two minutes in five second increments two to ten minutes in ten second increments ten minutes to one hour in one minute increments one to two hours in five minute increments two hours to nine hours...
- Page 10 USING THEOVEN/coo oue l AUTOMATIC The OVEN TIME and STOP TIME pads control the Timed TIMEDOVEN Bake operation. The automatic timer will turn the oven on and off at the times you select in advance. Before setting the oven for the Timed Bake operation, be sure that the clock shows the correct time of day.
- Page 12 USING THEOVEN ! oot o,.,o l 7. Touch the STOP TIME pad. The time of day and the set baking time will appear in the display window. The words "STOP TIME" will _ow in the left side of the display. 8.
- Page 13 OVENLIGHT The oven light automatically turns on when the door is opened. There is a switch, located on the control panel, that turns the power to the oven on and off and also controls the oven light. Turn the switch to the OVEN LIGHT position to turn on the light.
-
Page 14: Baking
BAKING SELECTING To ensure good baking results, use the proper baking pan. BAKEWARE Cakes, meats loaves, quick breads, pies or yeast breads bake best in medium-weight aluminum or glass pans. When using glass pans, reduce the oven temperature by 25 °F. Cookies, biscuits or bake best on medium-weight cream... -
Page 15: Baking
Cookies and biscuits burn on the bottom PROBLEMS...CAUSES ANDCORRECTIONS Cookies and biscuits put into the oven before preheating time is completed; oven rack overcrowded; dark pan absorbs heat too fast... ;_ii ....::i.... :: ........;: i 10w ovento preheatto the selected temperature before _ placing food m 0yen S_ _B_e,! Under U_ing the Oven2 :Choose pan sizes t_at will permit about two_c_es... -
Page 16: Roasting
ROASTING Roasting is a dry heat method for cooking tender cuts of meat and poultry. Place roasts fat side up on a rack in a shallow, uncovered pan. Use the bottom or next-to-bottom rack posi- tion. Set the oven temperature for 300 °F-325 °F. -
Page 17: Braising
BRAISING Braising is a moist heat method for cooking less tender cuts of meat. First brown meat in an uncovered pan on the top of the range. Use only enough fat to prevent sticking. Then place browned meat in a pan with a tight-fitting cover. - Page 18 BROILING ( oo1 o°o ) 3. Turn the SET knob in a clockwise direction until the desired broiling doneness level appears in the display. The broiling temperature can be set for any of the six broiling levels. Refer to the chart below for recommended broiling doneness settings.
-
Page 19: Broiling
• Trim outer layer of fat from steaks and chops to reduce spattering. • To make cleaning easier, line the bottom of the broiler with aluminum foil. DO NOT cover the broiler grid with foil. • To prevent grease from baking on, remove the broiler... -
Page 20: Cleaning
CLEANING GENERAL C LEANING, Remove spillovers and stains as they occur using a soft cloth OUTSIDE and sudsy water. Clean the oven after each use to prevent soil build-up. Use a Before cleaning any part of the oven, mixture of mild detergent and hot water to remove light soil. be sure the controls are turned to OFF Rinse with a damp cloth and wipe dry. -
Page 21: Self-Cleaning Instructions
SELF-CLEANING INSTRUCTIONS high temperature to burn off baked-on spatters. Read the following instructions carefully. Allow about 3 ½ to 4 hours A self-cleaning oven cleans itself electrically. It heats to a very CLEAN for the complete cleaning process. PRECLEANING A certain amount of precleaning is necessary before setting the oven for the self-cleaning... - Page 22 SELF-CLEANING INSTRUCTIONS/ oo ooo l 4. Clean the inside window with hot, sudsy water and a nylon net scrubber. Rinse and dry. 5. Remove oven racks and clean by hand if you want to keep them shiny. If not, place the racks in upper glides and leave in the oven during self-cleaning.
- Page 23 Be sure to remove everything from the oven and complete suggested precleaning steps before setting the controls. The cleaning cycle can be programmed to begin immediately, or, at a delayed starting time. SETTING THE To set the controls for the cleaning cycle to start immediately and stop automatically:...
- Page 24 SELF-CLEANING INSTRUCTIONS (ooo, ouo ) The control will calculate backward from the set stop time to determine when the cleaning cycle should begin. The words "DELAY" and "CLEAN STOP TIME" will glow in the dis- play. To recall the time that the oven will come on, touch and hold the CLEAN pad for three seconds.
-
Page 25: Adjusting Oven Temperature
If it is necessary to interrupt or cancel the cleaning cycle: DO NOT TRY TO FORCE THE 1. Touch the CANCEL pad. OVEN DOOR. This can damage 2. Open the windows and doors to rid the room of smoke. the automatic door locking system. -
Page 26: Avoid Service Checklist
AVOID SERVICE CHECKLIST Before you call for service, review this list. It may save you time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. This oven is equipped with a state of the art electronic oven con- troller. -
Page 27: If You Need Service
Common occurrences and their solutions can be found in the checklist. 2. Call Frigidaire Service. If your problem cannot be solved by using the Avoid Service Checklist, call your Frigidaire dealer. If your dealer does not have a service department, call WCI Consumer Parts &... -
Page 28: Warranty
Your Frigidaire Wall Oven is protected by this warranty FULLONE-YEAR WARRANTY THESE WARP_NTIE$ gO _OT APPLY: Frigidaire C ompany,a Divisionof White Consolidated Industries, 1. To conditionsresultingfrom (A) improperinstallation,or (B)in- correct electriccurrent. Inc.,warrantsthat Frigidaire will repair,without charge, a nydefect or malfunctionoccurringin this WallOvenduringthefirst yearaf- 2.
