Summary of Contents for ETA Systems ETA-S15
- Page 1 ETA-S15 Power Conditioner & Distribution Unit ETA-S15 Power Conditioner & Distribution Unit 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 1 – ETAsys.com Specifications are subject to change without notice.
-
Page 2: Table Of Contents
ETA-S15 Power Conditioner & Distribution Unit TABLE OF CONTENTS Safety Instructions ...3 Introduction ...5 Key Features ...5 Applications...5 Front Panel Features...6 Rear Panel Features...6 Installation ...6 Specifications ...7 Warranty ...8 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 –... -
Page 3: Safety Instructions
This appliance shall not be exposed to dripping or splashing water and that no object filled with liquids such as vases shall be placed on apparatus. 17. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle. 18. The mains plug of the power supply cord shall remain readily operable. - Page 4 • E nsure that the power supply plug is securely plugged into the wall outlet. Never allow dust to accumulate on the power plug or inside the wall outlet. • W hen cleaning the unit or the unit is not to be operated for an extended time period, unplug the power cord from the wall. 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. ETA-S15 ⁄ ” away from objects that may obstruct air flow to prevent the unit’s internal temperature Telephone: 800-321-6699 • Fax: 800-996-3821 –...
-
Page 5: Introduction
ETA-S15 Power Conditioner & Distribution Unit INTRODUCTION Thank you for purchasing the ETA Systems ETA-S15 AC Power Conditioner & Distribution Unit. The ETA-S15 has been designed to meet most installation requirements for AC power distribution and equipment power protection. The ETA-S15 features noise filtering for unwanted Radio Frequency Interference (RFI) that is commonly introduced into AC lines by nearby radio transmitters or wireless products. EMI filters are incorporated to reduce noise from Electromagnetic Interference (EMI) from such items as electric motors and switching power supplies. The benefit of these filters can be seen on video products or audibly by reducing static pops and external signal interference. -
Page 6: Front Panel Features
3. Power Switch – To turn the ETA-S15 on or off, press the switch to the ON or OFF position. The power switch will illuminate when in the “On” position. REAR PANEL FEATURES 1. AC Mains Input – Connect the 9' (3m) power cord to a 15A 120VAC outlet to provide power to the ETA-S15. 2. AC Switched Power Outlets – These six outlets are “Live” when the front panel power switch is activated. 3. AC Unswitched Power Outlets – These two outlets are always “Live” when the ETA-S15 is plugged into a 120VAC source. INSTALLATION Before installing, we strongly suggest you read the entire manual to ensure you benefit from all the features of the ETA-S15. The ETA-S15 can be placed on a shelf or rack mounted in a standard 19" width rack. When rack mounted, placement within the rack is flex- ible however the ETA-S15 should be within 6' of a dedicated 15A AC outlet. When rack mounting, use Rack Rail screw type Always make sure the 15A outlet is properly inspected by a certified electrician prior to connecting the ETA-S15. Make sure to inspect the equipment that is to be plugged into the ETA-S15 to ensure it does not exceed 15A total amperage draw. -
Page 7: Specifications
5 lbs (2.27kg) Power Consumption 6 watts Agency Listings MET (UL 1449 Code) 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. ETA-S15 Power Conditioner & Distribution Unit Telephone: 800-321-6699 • Fax: 800-996-3821 – 7 – Specifications are subject to change without notice. ETAsys.com... -
Page 8: Limited Warranty
Should your ETA-S15 require service, please contact the ETA Systems warranty department at 1-877-689-8055, ext. 277 to obtain an RA number. ETA Systems Tech Support can be reached at 1-800-321-6699. Visit our web site at www.ETAsys.com to see other ETA Systems products. ©2009 ETA Systems All rights reserved. ETA003561 RevA 05/09 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 8 – ETAsys.com Specifications are subject to change without notice.
