- Page 1 ETA-C15D Power Conditioner ETA-C15D Power Conditioner 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 1 – ETAsys.com Specifications are subject to change without notice.
-
Page 2: Table Of Contents
ETA-C15D Power Conditioner TABLE OF CONTENTS Safety Instructions ...3 Introduction ...5 Key Features ...6 Applications...6 Front Panel Features...6 Rear Panel Features...8 Installation ...8 Troubleshooting Guide ...9 Specifications ...10 Warranty ...12 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 –... -
Page 3: Safety Instructions
16. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle. 17. The mains plug of the power supply cord shall remain readily operable. - Page 4 • Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the AC outlet and contact ETA Systems. Do not to attempt to continue operation of the product as this may cause fire or electric shock.
-
Page 5: Introduction
AC power distribution and equipment power protection. The 15A compact 1RU unit AC Mains Voltage can be monitored via the front panel from the precision Digital Volt Meter. To light your rack, the ETA-C15D has incorporated a front panel pull-out dimmable LED tube light. The rear of the rack can be illuminated by an optional Atlas Power 16" gooseneck LED lamp,... -
Page 6: Key Features
APPLICATIONS The ETA-C15D was designed to be flexible with features that allow it to be used in a variety of applications. The ETA-C15D can be used solely for protection against lightning strikes or voltage surges or for AC Mains Voltage Monitoring. If fuzzy video or frequent static pops occur, the AC power conditioning will eliminate or reduce those inconveniences. - Page 7 12. AC Mains Abnormal Voltage Indicator – This LED flashes under several AC Mains fault situations listed below. Normal operating voltages for AC Mains voltage is considered to be between 108VAC and 127VAC. Any voltages exceeding those parameters are considered a risk to damage equipment plugged into the ETA-C15D. High AC Line Mains – The Abnormal Voltage LED will flash between 128VAC – 132VAC indicating possible damage may occur to equipment due to high AC Mains voltage. The ETA-C15D outlets will remain active but the LED will stay flashing even if the...
-
Page 8: Rear Panel Features
Before installing we strongly suggest you read the entire manual to ensure you benefit from all the features of the ETA-C15D. The ETA-C15D can be placed on a shelf or rack mounted in a standard 19" width rack. Placement within a rack is not critical but the rack should be within 6' of a dedicated 15A AC outlet. -
Page 9: Troubleshooting Guide
In the rare instance that this occurs, the DCS circuit has been damaged during the suppression. If this happens, the ETA-C15D will shut off and the unit will need to be repaired or replaced. It is important to Action Needed: have all equipment that was connected to that AC Mains Line inspected for proper operation. -
Page 10: Specifications
8.5" (548.64mm) Weight 7.6 lbs (3.45kg) Power Consumption 12 watts Agency Listings MET (UL 1449 Code) 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. ETA-C15D Power Conditioner Telephone: 800-321-6699 • Fax: 800-996-3821 – 10 – Specifications are subject to change without notice. ETAsys.com... - Page 11 ETA-C15D Power Conditioner Notes 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800-321-6699 • Fax: 800-996-3821 – 11 – ETAsys.com Specifications are subject to change without notice.
-
Page 12: Limited Warranty
This warranty shall extend from the date of purchase for a period of one year. Additionally, fuses and lamps carry no warranty. ETA Systems will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions.
