  • Page 1 CPC Series Conditioned Power Center RoHS Compliant Conditioned Power Center...
  • Page 2 SM5505 - March 1, 2006—Rev. A Conditioned Power Center...

  • Page 3: Table Of Contents

    Table of Contents Caution Notice.......................5 Section 1-General ......................6 Section 2 – Safety 2.1 ANSI Warning Notices ................7 2.2 Inherent Hazards..................7 2.3 Alerts and Labels..................7 2.4 Safety Interlocks..................9 2.5 Lockout/Tagout..................9 2.6 Conformance with Regulations ...............10 2.7 Product Liability ..................10 2.8 Emergency Contact Information .............10 Section 3 –...
  • Page 4 Table of Contents Section 8 - Troubleshooting/Maintenance 8.1 Troubleshooting Conditions ..............30 8.1.1 Source Circuit Breaker Trips Out .........30 8.1.2 Input Circuit Breaker Trips Out..........30 8.1.3 TVSS Fault LEDs Illuminate..........31 8.1.4 Harmonic Filter Circuit Breaker Trips Out ......32 8.2 Rountine Maintenance ................32 Section 9 - Service and Support 9.1 Technical Service Assistance ..............33 9.2 Customer Service ...................33...

  • Page 5: Caution Notice

    P L E A S E ! For maximum safety, reliability, and user satisfaction, please read all of the following important information carefully. When finished, If you are in doubt about any phase of the installation, operation, maintenance or use of this product contact the manufacturer immediately for additional assistance.

  • Page 6: Section 1-General

    Section 1 - General This manual describes the installation, connection, adjustment and operation of electrically powered equipment. For your convenience, this document has been divided into the following nine sections. Section 1 - General: The section which your are currently reading describes the manual’s structure and the location of pertinent information required to install, operate, troubleshoot, repair, and maintain the product.

  • Page 7: Section 2 - Safety

    Section 2 - Safety - IMPORTANT SAFETY INSTRUCTIONS - - SAVE THESE INSTRUCTIONS - 2.1 ANSI Warning Notices Failure to observe reasonable precautions in the use of this product may result in fire, injury, electrocution and/or death. Please observe all notices and warnings. This equipment must be installed in accordance with all applicable national, state, county, and/or municipal codes.
  • Page 8 Section 2 - Safety On both removable side panels, near the top of the panel and approximately in the middle are the following warn- ings. Each calls attention to a specific hazard requiring special attention. WARNING LINE VOLTAGE PRESENT WITH MACHINE POWER OFF. Risk of electric shock or burn.

  • Page 9: Safety Interlocks

    Section 2 - Safety 2.4 Safety Interlocks This product incorporates a safety interlock circuit that functions as a secondary means of protection for personnel. Protective side panels and hazard warning labels provide primary protection. However, in the event one or more side panels are removed from the product prior to being de- energized, the safety interlock system will de-energize the power conditioner.

  • Page 10: Conformance With Regulations

    Section 2 - Safety 2.6 Conformance with Applicable Laws and Regulations This equipment must be installed and used in accordance with all applicable local, county, state, provincial, and federal regulations. In the United States, these regulations include, but may not be limited to, those of the NFPA, NEC, and other regulating bodies.

  • Page 11: Section 3 - Product Overview

    Section 3 - Product Overview Welcome to the world of conditioned power. Electrical power users from around the world benefit from the use of clean, quality power. That's why we developed the Conditioned Power Center (CPC). The CPC Series is a low- impedance power conditioner that provides high peak-load capability.

  • Page 12: Standard Features

    Section 3 - Product Overview 3.2 Standard Features These include a “power on “ LED, TVSS Fault LEDs (one per phase), a lockout/tagout provision for the front panel input circuit breaker, safety interlocks, casters, and leveling feet. In addition, the CPC offers a range of options as described below.

  • Page 13: Feature/Model Matrix

    Section 3 - Product Overview complete monitoring of three phase voltages, currents, phase angles, power factor, demand, energy usage, event logs and more. If the CPC is equipped with the power management option, documentation prepared by Power Measurements Limited will accompany this manual. The table below illustrates a matrix of standard equipment and options for each model of GPI Series 2000.

  • Page 14: Section 4 - Preparation

    Section 4 - Preparation IMPORTANT ! Each unit is fully inspected and tested prior to leaving the factory. CPC series products are packed carefully in approved shipping crates. However, since we cannot control handling during shipping, damage in transit is possible. Please retain all packing materials until the power conditioner is installed and operating satisfactorily.
  • Page 15 Section 4 - Preparation Step 2 - A packing block assembly rests on top of the power conditioner to secure it tightly inside the packing crate. Remove the packing block assembly by removing the screws that are driven through the crate front and back panels into the ends of the wooden struts.
  • Page 16 Section 4 - Preparation Figure D - Shipping Crate Disassembly - 10 to 20 kVA 1. Cardboard outer carton 2. Shipping pallet 3. 2 x 4 front cleat 4. Front skid After removing the front cleat and front skid, the pallet may be rocked for- ward on the middle skid and the power conditioner...

  • Page 17: Section 5 - Installation

    Section 5 - Installation 5.1 Location For best performance, the CPC series should be installed within fifty (50) wire feet maximum of the protected load. Refer to the dimensional information shown in the specifications sheet accompanying this document. Allow six inches of free space on all sides of the CPC series to provide for proper air circulation. The unit is designed to operate at high efficiency and is convection cooled.

  • Page 18: Outer Panel Removal

    Section 5 - Installation 5.3 Outer Panel Removal The side panels, the back panel, the top panel and the front panel have all been designed for easy removal prior to installation. The side panels must be removed first. Turn the quarter turn fasteners counterclockwise and remove the side panels.

  • Page 19: Programmable Circuit Breaker

    Section 5 - Installation 5.5.2 Programmable Circuit Breakers Before beginning installation, check the tag on the circuit breaker. The power conditioner has been manufactured and shipped according to the input voltage specified at the time the order was placed. If the input voltage information shown on the tag does not match the voltage available at your site, check the tag to determine the transformer primary configuration and circuit breaker type.

  • Page 20: 1Transformer Primary Voltage Adjustment

    Section 5 - Installation Transformers are designed to meet a variety of requirements. Some locations (Europe, for example) have standardized on a single input voltage. In other cases customers may specify multiple input voltages to accommodate the variety of voltages commonly found in the United States. The CPC series conditioner can accommodate either style of transformer - single voltage or multiple voltage primary.

  • Page 21: Output Voltage Fine Adjustment

    Section 5 - Installation 5.6.2 Output Voltage Fine Adjustment The transformer secondary of the power conditioners is a 5 wire Wye configuration (three phase conductors, one neutral and one safety ground). Output voltage can be adjusted plus-or-minus five percent ( + 5%) (as shown in Figure H to the right) to accommodate site-specific voltage differences .

  • Page 22: Lockout/Tagout

    Section 5 - Installation Specific locations for connecting the input and output safety ground conductors are discussed in Sections 5.9 and 5.10 that follow. These sections cover the information necessary to connect electrical wiring to both the main and to the load. Please review both sections carefully before beginning the actual electrical installation. A sophisticated electronic system will benefit greatly when all parts of the system and all system peripherals are powered from a single power source.

  • Page 23: Input Power Connections

    Section 5 - Installation 5.9 Input Power Connections The three-phase input connection is made at the lugs marked L1, L2, and L3 directly on the main circuit breaker shown in Figure K to the right. The safety ground connection is made at the dual lug marked “PE”...

  • Page 24: Section 6 - Operation

    Section 6 - Operation 6.1 Restoring For Service When wiring connections have been completed (or after maintenance or repair operations are finished) it will be necessary to perform several tasks before the power conditioner can be put into service. Take these steps in the following order: 1.

  • Page 25: Energizing The Load

    Section 6 - Operation (NOTE: Under "no load" conditions, the transformer in the power conditioner will "step up" the output voltage a few percent. This design characteristic compensates for losses within the transformer once actual load is applied. As a result, an output voltage that is slightly higher than the nominal input voltage is normal under unloaded conditions.) (NOTE: For further information on Power Measurements Limited meters or monitors, consult the separate owner’s manual.

  • Page 26: Section 7 - Options

    Section 7 - Options 7.1 Passive Harmonic Filter The passive harmonic filter package is located below the transformer secondary on the left side of the power conditioner. See Figure N to the left. This circuit is bi-directional. It will mitigate odd order harmonic currents originating from the load or the facility.

  • Page 27: Phase Loss - Low Voltage Detect

    Section 7 - Options 7.4 Phase Loss/Low Voltage Detection and Protection When equipped with the power management option, the 7500 ION monitor also provides: 1. Protection from the loss of one or more input phases 2. Protection for a low-voltage condition occurring on one or more phases (Protection from a high-voltage conditions is also optionally available) Should a phase loss or low voltage occur, the 7500 ION will “shunt”...

  • Page 28: Semi S2-0200

    Section 7 - Options 7.7 SEMI S2-0200 Certification For use in semiconductor fabrication applications, the manufacturer offers a version of the power conditioner that incorporates special modifications of the basic product family that are required for the power conditioner to meet the safety requirements of the Semiconductor Equipment and Materials International (SEMI) safety standard S2- 0200.
  • Page 29 Section 7 - Options activated by the closure of an interlock switch or EMO button, provides a DC voltage to the over-voltage shunt trip coil of the input circuit breaker. In the standard EMO design, the DC voltage is derived via a full wave bridge rectifier powered from a 24 volt AC tap on the main transformer secondary winding.

  • Page 30: Section 8 - Troubleshooting/Maintenance

    Section 8 - Troubleshooting/Maintenance 8.1 Conditions Requiring Troubleshooting Four conditions may occur, which require operators or service personnel to troubleshoot the function of the power conditioner. Each may be individually evaluated. These four occurrences include: 1. Source circuit breaker (at switchgear or distribution panelboard) trips out 2.

  • Page 31: Tvss Fault Leds Illuminate

    Section 8 - Troubleshooting/Maintenance Prior to performing maintenance of any kind, lockout and tagout the electrical power at both the facility source and the input circuit breaker. Under these condi- tions, entering the equipment enclosure will be classified as a Type 1 task under SEMI S2-0200 guidelines.

  • Page 32: Harmonic Filter Circuit Breaker Trips Out

    Section 8 - Troubleshooting/Maintenance 8.1.4 Harmonic Filter Circuit Breaker Trips Out If equipped with a harmonic filter option, the power conditioner will incorporate a passive harmonic filter. One characteristic of such filters is that they tend to “sink” harmonics regardless of whether the source is the load or the facility. In some circumstances, it is possible that the load and the facility together may require more reactive current than the filter is rated to provide.

  • Page 33: Section 9 - Service And Support

    Section 9 - Service and Support 9.1 Technical and Service Assistance In North and South America, the manufacturer offers toll-free technical and customer service assistance by calling 800-321-6699. Business hours are Monday through Friday, 8:00 a.m. to 5:00 p.m. Central Time. In EMEA, contact the manufacturer’s international headquarters in the United Kingdom at +44 (0) 1793 553980.

  • Page 34: Section 10 - Specifications

    Section 10 - Specifications 10.1 CPC Series Schematic Conditioned Power Center...

  • Page 35: Standard Emo Circuit

    Section 10 - Specifications 10.2 GPI Series 2000 Standard EMO Conditioned Power Center...

  • Page 36: Semi S2-0200 Compliant Emo Circuit

    Section 10 - Specifications 10.3 GPI Series 2000 Semi S2 EMO Conditioned Power Center...

  • Page 37: Output Voltage Fine Adjustment

    Section 10 - Specifications 10.4 Output Voltage Fine Adjustment IMPORTANT: ALL WORK TO BE DONE BY A LICENSED ELECTRICIAN Nominal Nominal Nominal TRANSFORMER SECONDARY The output voltage of the transformer may be adjusted +5% from nominal using the taps shown above. First disconnect the power and all load equipment.

  • Page 38: Document Revision History

    Document Revision History Part # Title Rev. Letter Rel. Date Next Rev. Leve SM5505 Conditioned Rev. A 03/01/2006 Rev. B Power Center Conditioned Power Center...

  • Page 39: Detailed Specifications

    ETA Systems 1450 Lakeside Drive Waukegan, IL 60085 (800) 321-6699 Phone: (330) 677-4424 - Fax: (330) 677-4471 http://www.etasys.com Conditioned Power Center SM5505- Rev. A - 03/01/2006, © 2006 ETA Systems.
