Table 15. Installation of the palm rest (continued)
3. Push the front side of the palm rest
4. Close the LCD cover and turn the computer over. Then fasten the four screws to secure the palm rest.

1070 Digitizer pen case assembly

For access, remove these FRUs in order:

• "1010 Battery pack" on page 68
• "1020 Digitizer pen" on page 69
• "1040 Hard disk drive (HDD) cover, HDD and HDD rubber rails or solid state drive (SSD) and storage
converter" on page 70
• "1060 Palm rest or palm rest with fingerprint reader" on page 75
78
ThinkPad W700, W700ds, W701, and W701ds Hardware Maintenance Manual
4
and the areas marked
5
4
5
until it clicks into place.
5
