Manual Control Units
WC37 • N37W
WC44 • N44W
WC46 • N46W
WC50 • N50W
Remote Control Units
RWC35 • RN35W
RWC46 • RN46W
RWC50 • RN50W
Circle the model of your cooler and
record the serial number below.
Encierre con un circulo el modelo de su
enfriador y escribe el número de serie abajo.
Serial #
Número De Serie
Read And Save These Instructions
Vea el Español en el interior
Evaporative Cooling
Evaporative cooling is nature's way of cooling. When air is moved
over a wet surface, water is evaporated and heat is absorbed. When
stepping out of a swimming pool with the wind blowing, evaporative
cooling makes you feel cool, even though the air may be warm.
The human body itself is cooled primarily by the evaporation of
perspiration.
This unit works on the same principle. Air is drawn across wet
fi lter pads where the air is cooled by evaporation and then circulated
throughout the building. It is this combination of cooled air and the
movement of air over the skin which makes it feel cool.
Unlike refrigeration systems which recirculate the air, an evaporative
cooler continually brings in fresh air while exhausting old air. You
are completely replacing the air every 2 to 4 minutes by opening
windows or doors or a combination of both. The air is always fresh,
not stale, laden with smoke and odors as happens with refrigerated
air conditioning.
110496-1
C H A M P I O N • E S S I C K
Window Evaporative
Cooler Manual
www.championcooler.com
Read Carefully All Of This Manual
Before Installing The Unit.
Lea Con Cuidado Todo Este Manual Antes
De Instalar La Unidad.

Safety Rules

1. Read these instructions carefully.
2. Unit must be in the Off Position and Unplugged from power
receptacle when installing or performing any maintenance.
3. This cooler will run on 120 volt A.C., 60 Hz (cycle) current
only.
4. Motor and pump are grounded and have an automatic thermal
overload switch which will shut motor off when it overheats. The
motor will restart automatically when it cools down.
5. Pump receptacle is for grounded evaporative cooler pump only.
Do not plug anything else into receptacle.
WARNING
: To reduce the risk of fi re or electric shock, do not
use this fan with any "solid-state fan speed control device."
Convertible Kit Not Shipped With Cooler
Available Upon Request At No Additional Cost
9-09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESSICK N50W and is the answer not in the manual?

Questions and answers

Rau Richard
June 10, 2025

What size of belt do I use for a WC/N 50W champion

Summary of Contents for Champion ESSICK N50W

  • Page 1: Safety Rules

    5. Pump receptacle is for grounded evaporative cooler pump only. Do not plug anything else into receptacle. WARNING use this fan with any “solid-state fan speed control device.” www.championcooler.com Convertible Kit Not Shipped With Cooler Available Upon Request At No Additional Cost Safety Rules : To reduce the risk of fi...
  • Page 2: Operation

    The pump must be on while operating the fan for cooling. You may also want the pump turned off at times when just a fan is desired.
  • Page 3: Maintenance

    • Install window panel Window Fill-In retainers. Place two panel retainer strips onto bottom of neck flange Top Panel and position to the width Retainer of the window. Cut the strips to fi t if necessary. These strips hold the window fill-in panels (Fig.
  • Page 4: Wiring Diagrams

    • Cover grill. To help keep out cold air you can use the optional plastic grill cover. This cover may be purchased from your local distributor. To install the cover, line up the grill cover with the grill so that the tabs on the cover will slide over the center section of the grill.
  • Page 5: Troubleshooting

    Problem Possible Cause Failure to 1. No electrical power to start or no air unit delivery • Fuse blown • Circuit breaker tripped • Electric cord un- plugged or damaged 2. Belt too loose or tight 3. Motor overheated • Belt too tight •...
  • Page 6 Modelo Operating Seco Lleno RWC35, RN35W WC37, N37W WC44, N44W WC46, N46W RWC46, RN46W WC50, N50W, RWC50, RN50W Motor Specifi cations / Especifi caciones Del Motor Model No. Motor Part # Modelo Motor - Nº RWC35, RN35W 110442 WC37, N37W...
  • Page 7 110839-1† 110839-1 110839-2‡ ...322007-004‡ 322007-004‡ 110400‡ 110403‡ 110401-1‡ 110829** 110829** 310586** 310586** 322008-001§ 322008-001§ WC46, N46W RWC46, RN46W WC50, N50W RWC50, RN50W 220901-003 220902-002 110098 (3) 3PW-5 (9) See/Vea #3 224003-032 224003-047 224105-004 322120-001 324105-006 16BW 110183 110351 (2) 110275...
  • Page 8: Reglas De Seguridad

    Se puede apagar la bomba cuando se desea un ventilador solamente. • El Botón FAN. Este botón controla el ventilador. Al presionar este botón cuando el ventilador está apagado pondrá en marcha el ventilador a alta velocidad.
  • Page 9: Instalación

    ¿Cuanto Debe Abrir Las Ventanas? Un concepto a menudo entendido mal de enfriamiento por evapora- ción es la cantidad de aire que debe ser agotada. Cuánto debe usted abrir sus ventanas? El hecho es que la mayoría de la gente no abre sus ventanas bastante.
  • Page 10: Mantenimiento

    Conectar El Agua • Instale el montaje de desagüe. Quite la tuerca y pase la boquilla por el agujero de la bandeja, colocando la arandela de goma entre la bandeja y la cabeza de la boquilla (fi g. 4). Coloque la tuerca en la boquilla y atorníllela hasta que quede apretada contra la parte inferior de la bandeja.
  • Page 11: Control Manual

    Conversión Al Conducto Vertical Esta unidad se puede confi gurar de nuevo a una confi guración con el conducto vertical para la instalación en una abertura más pequeña de la anchura. Siga los pasos subsecuentes si se desea esta confi guración. Nota: Los tiras de metal usados para convertir el túnel no se envía con esta unidad.
  • Page 12: Garantía Limitada

    Problema Causa Posible No arranca o 1. No llega corriente no sale aire • Fusible fundido • Cortacircuito desac- tivado • Cable eléctrico dañado 2. Correa muy fl oja o apretada 3. Motor recalentado • Correa muy apretada • Cojinetes de la rueda están secos 4.
