Champion MasterCool AD1C51 Owner's Manual

Champion MasterCool AD1C51 Owner's Manual

Contractor series
Hide thumbs Also See for MasterCool AD1C51:

Advertisement

Available languages

Available languages

Models
AD1C51
AS1C51
AD1C5112
AS1C5112
AD1C71
AS1C71
AD1C7112
AS1C7112
AU1C7112
Read Carefully All Of This Manual
Before Installing The Unit
Lea Con Cuidado Todo Este Manual Antes De
Instalar La Unidad
Safety Instructions .......................................................................1
Installation Instructions ............................................................ 2-3
Electrical Wiring Diagram ...........................................................3
Operation .................................................................................. 3-4
Maintenance Section ....................................................................4
Troubleshooting ...........................................................................5
Vea el Español en el interior.
Read And Save These Instructions

Safety Rules

1. Read instructions carefully.
2. Electrical hook up should be done by a qualifi ed electrician, so
that all electrical wiring will conform to your local standards.
3. Always DISCONNECT POWER and UNPLUG motor and
pump inside the cooler before installing or performing any
maintenance.
4. Motor and pump have a grounded, molded plug and an automatic
thermal overload switch which will shut motor off when it
overheats. The motor will restart automatically when it cools
down.
WARNING:
To reduce the risk of fi re or electric shock, do not
use this fan with any "solid-state fan speed control device."
110498-3
AD2C51
AS2C51
AD2C5112
AS2C5112
AD2C71
AS2C71
AD2C7112
AS2C7112
AU2C7112

Table Of Contents

www.championcooler.com
Circle the model of your cooler and
record the serial number below.
Encierrre con un circulo el modelo de su
enfriador y escribe el número de série abajo.
Serial #
Número De Série
Warranty .......................................................................................5
Parts List (Down Discharge Units) .......................................... 6-7
Parts List (Side Discharge Units) ............................................. 8-9
Parts List (Up Discharge Units) ........................................... 10-11
Specifi cation Tables (Tablas de Especifi caciones) .....................12
Instrucciones en Español ..................................................... 12-16

Evaporative Cooling

Evaporative cooling is nature's way of cooling. When air is moved
over a wet surface, water is evaporated and heat is absorbed. When
stepping out of swimming pool with the wind blowing, evaporative
cooling makes you feel cool, even though the air may be warm.
This unit works on the same principle. Air is drawn across wet
fi lter pads where the air is cooled by evaporation and then circulated
throughout the building. It is this combination of cooled air and the
movement of air over the skin which makes it feel cool.
Unlike refrigeration systems which recirculate the air, an evaporative
cooler continually brings in fresh air while exhausting old air. You
are completely replacing the air every 2 to 4 minutes by opening
windows or doors or a combination of both. The air is always fresh,
not stale, laden with smoke and odors as happens with refrigerated
air conditioning.
9-09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MasterCool AD1C51 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Champion MasterCool AD1C51

  • Page 1 The motor will restart automatically when it cools down. WARNING: To reduce the risk of fi re or electric shock, do not use this fan with any “solid-state fan speed control device.” 110498-3 AD2C51 AS2C51 AD2C5112...
  • Page 2: Electrical Installation

    Cooler Installation CAUTION: Make sure that the mounting surface is strong enough to support the operating weight of the cooler when in use. (For operating weight, see Specifi cation Table.) CAUTION: Never start cooler until installation is complete and unit has been tested for rigidity. CAUTION: Do not screw or drill within 5 inches of the bottom of the wet module.
  • Page 3: Wiring Diagrams

    LCD will display ‘Set’ rather than ‘Room’ temperature for a short time after pressing the ‘Up’ or ‘Down’ button. On starting, if the pads in the cooler are too dry, the fan may be delayed from starting until the pads have absorbed some water. This is called Pre-wet and lasts for 2 minutes, indicated by a fl...
  • Page 4 You should allow an opening of at least 2 square feet (288 square inches) for each 1000 CFM rating of your unit. Example: At 3790 CFM, model AD1C51 (3/4 hp) requires 7.6 square feet (1094 square inches) of opening (3790/1000 * 2 = 7.6). Multiply the number of windows by window width in inches and divide this into the number of square inches required for your size unit.
  • Page 5: Troubleshooting Guide

    6. Poor connection to 6. Check connections to termi- Fan motor terminals 7. Unit control board or 7. Supply power to control box wall thermostat faulty and check DC voltage at wall thermostat •...
  • Page 6 ** Pump for 115V units - #110436, Pump for 230V units - #C60P-240 / Bomba de 115V - #110436, Bomba de 230V - #C60P-240 NOTE: Standard hardware items may be purchased from your local hardware store. NOTA: Artículos de uso corriente pueden comprarse en la ferretería de su localidad. AD1C51 AD1C5112 AD1C71...
  • Page 7 Replacement Parts / Piezas De Repuesto AD1C51, AD2C51, AD1C5112, AD2C5112, AD1C71, AD2C71, AD1C7112, AD2C7112 110498-3...
  • Page 8 Replacement Parts List / Lista De Piezas De Repuesto When ordering parts, please be sure to furnish the following information on all orders. Failure to do so may delay your order. / Al pedir piezas, incluya toda la información siquiente con su pedido. El no proporcionar toda esta información resultará en una demora. Cooler model number / El modelo de su enfriador Cooler serial number / Número de serie de la unidad Description and part number / Descripción y número de pieza...
  • Page 9 Replacement Parts / Piezas De Repuesto AS1C51, AS2C51, AS1C5112, AS2C5112 AS1C71, AS2C71, AS1C7112, AS2C7112 110498-3...
  • Page 10 Replacement Parts List / Lista De Piezas De Repuesto When ordering parts, please be sure to furnish the following information on all orders. Failure to do so may delay your order. / Al pedir piezas, incluya toda la información siquiente con su pedido. El no proporcionar toda esta información resultará en una demora. Cooler model number / El modelo de su enfriador Cooler serial number / Número de serie de la unidad Description and part number / Descripción y número de pieza...
  • Page 11 Replacement Parts / Piezas De Repuesto AU1C7112, AU2C7112 110498-3...
  • Page 12 General Specifi cations / Especifi caciones Generales Weight (lbs.) Peso (libras) Models Modelos Seco AD1C51, AD2C51, AS1C51, AS2C51 AD1C5112, AD2C5112, AS1C5112, AS2C5112 AD1C71, AD2C71, AS1C71, AS2C71 AD1C7112, AD2C7112, AS1C7112, AS2C7112, AU1C7112, AU2C7112 Motor Specifi cations / Especifi caciones Del Motor...
  • Page 13 Instalación Del Enfriador PRECAUCIÓN: La superfi cie en que ha de colocarse el en- friador deberá aguantar el peso completo de la unidad cuando ésta está en funcionamiento. (Para saber este peso, vea la tabla de especifi caciones.) PRECAUCIÓN: No conecte el enfriador hasta que la insta- lación esté...
  • Page 14 El botón ‘Timer’ (temporizador) está utilizado para determinar un retardo de 2, 4 o 8 horas, dependiendo en las veces que presione el botón. Si el enfriador está funcionando en el modo ‘Cool’ o ‘Fan’ cuando presiona el botón ‘Timer’, el periodo de retraso se determina cuando el enfriador apagará.
  • Page 15 Usted debe dejar una abertura de dos pies cuadrados por cada 1000 P.C.M. (pies cúbicos por minuto), según la capacidad de su modelo. Ejemplo: Un Modelo AD1C51 (3/4 c.v.) de 3790 P.C.M. requiere 7,6 pies cuadrados (1094 pulgadas cuadradas) de abertura (3790/1000 * 2 = 7,6). Ahora, multiplique el número de las ventanas por el ancho de las mismas;...
  • Page 16 Problema Causa Posible No arranca o 1. No llega corriente 1. Revise la corriente no sale aire/ • Fusible fundido No muestra • Cortacircuito desactiva- la pantalla 2. Motor recalentado 2. Determine la causa • Correa muy apretada • Cojinetes de la rueda están secos •...
