Frigidaire PLCF489GC - 40 Inch Dual Fuel Range Installation Instructions Manual

40" DUAL FUEL RANGE INSTALLATION INSTRUCTIONS
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
If the information in this manual is not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
(101.9 cm Min.)
2 1/2" Min.
(6.4 cm Min.)
Both sides,
if there is a wall
E
F
Grounded
Wall Outlet
Do not pinch the power supply cord between the range
and the wall.
Do not seal the range to the side cabinets.
A. HEIGHT B. WITDH
48 1/8" (122.2 cm) 40 1/8" (101.9 cm)
Printed in United States
(Models with Electric Ovens and Gas Cooktop)
OBSERVE ALL GOVERNING CODES AND ORDINANCES.
40 1/8" Min.
See
note
18" Min.
(45.7 cm Min.) (33 cm Min.)
24" Min.
(61 cm Min.)
24 1/2" Max.
(62.2 cm Max.)
C. DEPTH TO FRONT
OF RANGE
25 7/8" (65.7 cm)
13" Min.
36" (91.4 cm)
with feet
extended
NOTE:
24" (61 cm)
minimum clearance between
the cooktop and the bottom of the cabinet
when the bottom of wood or metal cabinet is protected
by not less than 1/4" (0.64 cm) flame retardant millboard
covered with not less than No. 28 MSG sheet metal,
0.015" (0.4 mm) stainless steel, 0.024" (0.6 mm)
aluminum, or 0.020" (0.5 mm) copper.
30" (76.2 cm) minimum clearance when the cabinet is
unprotected.
D. DEPTH WITH
DOOR OPEN
43 3/4" (111.1 cm)
1
B
C
E. MINIMUM F. HEIGHT OF
CUTOUT WIDTH COUNTERTOP
40 1/4" (102.2 cm) 36" (91.4 cm) standard
35 3/8" (90 cm) min.
P/N 318201762 (0803) Rev. A
English - pages 1-10
Español - páginas 11-22
Wiring Diagram - page 23-24
A
