Table 3 Weight of typical P9500 system configurations
Dimension
System Min (lbs/kg)
Weight
Max (lbs/kg)

Storage requirements

If the equipment must be stored after delivery and prior to installation, the storage location must
meet the storage environmental requirements for the P9500 disk array. See the
19) in this chapter for environmental storage requirements.

Data center requirements

The data center must meet the following facilities requirements:
Table 4 Data center requirements
Item
General
ESD
Electrical interference
Contamination
Acoustics
User-supplied hardware

Data communication requirements

Route data communication cables away from areas of high static electric fields created by power
transformers and heavy foot traffic. Use shielded data communication cables that meet approved
industrial standards to reduce the effects of external fields.
The P9500 frames support top access and bottom access for hot cables. Routing the host cables
in a P9500 requires HP support personnel to install. The data communication infrastructure needed
for the P9500 disk array is described in
Single Rack
1 152/522 (Diskless)
1564/709
Description
The data center must provide appropriate power, air conditioning, cabling, and fire
protection.
The data center must provide adequate protection from electrostatic discharge (ESD).
The data center must provide adequate protection from electrical/radio frequency
interference.
The data center must provide adequate protection from dust, pollution, and particulate
contamination.
The data center must provide adequate acoustic insulation for operating the system.
This includes cables, connectors, and receptacles that must be available and ready
when the system is installed.
"Data communication requirements" (page
Single Module Dual Module
(3 racks) (6 racks)
2984/1354 5878/2666
4342/1970 8907/4040
Data center requirements
Table 1 1 (page
12).
1 1
