Page 1: Distribution Amplifiers
DISTRIBUTION AMPLIFIERS MANUAL PART NUMBER: 400-0067-003 PRODUCT REVISION: 1 DAV0106-V1A2 1-IN, 6-OUT VIDEO/AUDIO DISTRIBUTION AMPLIFIER USER’S GUIDE... -
Page 2: Table Of Contents
INTRODUCTION Altinex appreciates your purchase of the DAV0106- V1A2 Distribution Amplifier. We are sure you will find it to be a reliable and useful product. Superior performance for the right price backed by solid technical and customer support is what we have to offer. -
Page 3: Precautions / Safety Warnings
DAV0106-V1A2 Amplifier carefully because dropping or jarring can damage internal components. Do not place heavy objects on top of the DAV0106-V1A2. If the is to be mounted to a table or wall, use only Altinex made mounting accessories, such rack... -
Page 4: About Your Distribution Amplifier 2
It also has a bandwidth of 10Hz to 20kHz for audio signals. The DAV0106-V1A2 can pass NTSC, PAL or SECAM type video signals. The DAV0106-V1A2 can drive output signals up to 75 feet or more when it is used with high-quality coaxial cables. -
Page 5: Description Of Dav0106V1A2
Height (inches) Width (inches) 8.50in (216mm) Depth (inches) 4.93in (125mm) Weight Ship Weight T Operating T Maximum Humidity MTBF (calculations) DESCRIPTION OF DAV0106-V1A2 DISTRIBUTION AMPLIFIERS 90-140V/ 200-240V 10 watts max 0.1” Al Gray Lexan 1.75in (44mm) 2.0lbs. (0.91kg) 4.0lbs. (1.81kg) -
Page 6: Application Diagram
DISTRIBUTION AMPLIFIERS APPLICATION DIAGRAM... -
Page 7: Installing Your Distribution Amplifier
If you experience any problems, please call 1-800-258-4623 or 1-714-990-2300 for international calls. DISTRIBUTION AMPLIFIERS OPERATION The DAV0106-V1A2 will operate successfully as long as cables are attached properly and other technical specifications are met. 7.1 TERMINATION SWITCH The termination switch of the video amplifier, when set to the ON position, will provide 75 Ohms of termination to the input. -
Page 8: Accessories
(or) audio source needs to be connected to as many as six different display or recording devices. The DAV0106-V1A2 can pass composite video signals or high-resolution monochrome computer signals. All of the outputs are completely independent, and it is not necessary to terminate unused outputs. -
Page 9: Troubleshooting Guide
DISTRIBUTION AMPLIFIERS 11.2 RETURN POLICY It is very important to Altinex that you receive the products that you have ordered and that this product fulfills your need. In the unlikely event, that an Altinex product needs to be returned...
