Summary of Contents for Wharfedale Pro WH-S8
- Page 1 WH-S8 & WH-S10 subwoofer WH-S8 WH-S10...
-
Page 2: Important Safety Information
USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER IMPORTANT SAFETY INFORMATION Unplug the apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been exposed to rain or moisture, does not operate normally, or has been dropped. -
Page 3: Installation
230 volt products - 220 volts to 240 volts • 115 volt products - 100 volts to 120 volts If you move to an area with a different mains supply voltage, please consult your Wharfedale dealer to arrange the conversion of this product. Positioning the Subwoofer Although the unit may be placed almost anywhere in the room, we recommend that it be placed in front of the listener and as central to the listening position as possible. - Page 4 USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER Before Connecting the Subwoofer • Level the subwoofer taking care to make sure it sits squarely on all its spikes. • Switch off you amplifier and all connected source units at the mains. • Unplug the power cords to all system components if necessary.
- Page 5 USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER CONNECTING THE SUBWOOFER TO THE SYSTEM Control Panel of the WH-S10 Subwoofer ① Power Indicator ② Mains Power Switch Mains Power Fuse ③ IEC Mains Input Socket ④ Volume Control ⑤ Crossover Frequency Control ⑥...
- Page 6 USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER A/V Processor Connections AV AMPLIFIER Your subwoofer has been designed for optimum performance with a digital processor. If your A/V processor has a line level or LFE subwoofer output you should use this connection. You will RIGHT LEFT RIGHT...
-
Page 7: Operating Your Subwoofer
USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER OPERATING YOUR SUBWOOFER Check that all connections to the subwoofer have been properly made and that the main volume control is at minimum. Plug the supplied power cord into the mains socket on the rear panel. Initial Settings Volume Control: Set the subwoofer volume control to the minimum before proceeding. -
Page 8: Troubleshooting
USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER TROUBLESHOOTING Before investigating a problem, always switch off the system at mains. If your system is not working properly please work through this checklist before returning a unit to your dealer. Possible Cause Symptom No Sound System not switched on;... - Page 9 If you experience difficulties or there is no Wharfedale dealer in your area, contact the Wharfedale distributor for your country or the office below. IAG Service Dept.
-
Page 10: Specifications
USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER Specifications WH-S8 WH-S10 Description/Format Active Reflex subwoofer system Active Dynamic-Drive IB subwoofer system Drive Units 1 x (8")200mm cone long-throw 1 x (10")250mm cone long-throw Enclosure Type Vented box Closed box Frequency Response (±3dB) 30Hz - 200Hz 35Hz - 120Hz Bass Extension... - Page 11 USER INSTRUCTIONS: WH-S8 & WH-S10 SUBWOOFER...
- Page 12 IAG House, Sovereign Court, Ermine Business Park, Huntingdon, Cambs, PE XU, UK Tel: +(0)0 00 Fax: +(0)0 http://www.wharfedale.co.uk IAG reserves the right to alter the design and specifications without notice. All rights reserved IAG Group Ltd. Wharfedale is a member of the International Audio Group. CODE: WH-MNL00a...
