Wharfedale Pro WLA-118SUBA Quick Start Manual

Your full user manual can also be downloaded from
www.wharfedalepro.com
Congratulations on the purchase of your WLA-118SUBA. We take great pride in engineering and building every Wharfedale Pro product
and wish to thank you for entrusting us with your audio.
From the time Gilbert Briggs built his first loudspeaker in 1932, to the present day, we have maintained the same standard of quality in
components, workmanship and performance.
Please take the time to read this guide completely in order to get the most from your new system.
Specifications
Model Name
System Typology
System Type
Configuration
Frequency Response (+/-3 dB)
Frequency Range (- 10 dB)
Sensitivity 2.83 V/1 m
Calculated Maximum SPL @ 1 m
System Peak SPL
level at 1 m under half space conditions using pink
*
noise with crest factor 2, with dedicated preset.
level at 1 m under half space conditions using pink
**
noise with crest factor 4, with dedicated preset.
Signal Processing
Preset list
Amplifiers
Amplifier Design
Power Rating:
Thermal Protection
Low Line Voltage Shut Down
Driver Protection
DC and Short Protection
Clip Limiter
Limiter Indicator
Signal Indicator
Power/Active Indicator
Find Function Indicator
Input Sensitivity
Maximum Input Level
Input Impedance
AC Power details - Power Supply High Efficiency Dual Switching Mode Power Supply
Connectors
Input
Link
UPDATE
NETWORK (RS485)
AC Power Options AC 100-120 V~ and 220-240 V~, 50/60 Hz Automatic
Special Features
Rigging & Hardware:
Vertical Splay angle range:
Horizontal Splay angle
Accessories:
Stand pole:
Handles:
Enclosure
Cabinet Type
Enclosure Material and finish
Colour
Grille Material & Finish
Dimensions - Unpacked:
Height Front
Height Rear
Width
Depth
Dimensions - Packed:
Height
Width Front
Width Rear
Depth
Weight
Net Weight
Gross Weight
Note : Specifications may be subject to change without notice.
WLA-118SUBA
Subwoofer
Active 18" Subwoofer
Single Subwoofer
35 Hz - 125 Hz
28 Hz – 160 Hz
103 dB*
136 dB*
142 dB**
DSP based,8 presets
A) 1 SPKR 80 Hz LPF
B) 1 SPKR 100 Hz LPF
C) >2 SPKR 80 Hz LPF
D) >2 SPKR 100 Hz LPF
E) CARDIOID AUDIENCE
F) CARDIOID STAGE
G) CUSTOM
H) CUSTOM
Class D
4400 W Peak,
2200 W Continuous
Amplifier Shut Down. Auto Reset
60% Nominal Line Voltage
RMS, Peak Limiters and DC
Yes
Yes
Red LED
Green LED
White LED
Blue LED
+4 dBu
+18 dBu
Balanced:10 KΩ
Balanced socket XLR
Balanced pin XLR
USB Type B
RJ45
Aluminium demodulating ring
Waterproof LF cone
Malt Cross® TCS
3 points for rigging
/
/
WLA-1 FLY FRAME
M20 Pole mount
1 side 2 pcs)
（
Rectangular
18 mm plywood / TOUGH-TONE
Black paint
Powder coated perforated steel
535 mm / 21.1"
/
566 mm / 23.4"
760 mm / 29.9"
630 mm / 24.8"
656 mm / 25.8"
/
850 mm / 33.5"
59.8 Kg
68 Kg
WLA-118SUBA
QUICK START GUIDE
Product Features
• Duo layer 18" Beyma driver
• Tough-Tone paint finish
• Integral side and back 3-point rigging system
• Premium Baltic birch construction
• .gll files available for download
• Internal DSP
• Versatile and practical
• Use in conjunction with the 21" sub for infrabass
AND punch
• EASE .gll files available for download
Overview
566.0
760.0
